Category: HDD

WD5000KS-00MNB0, DCM HBHCAJAH, Western Digital 500GB SATA 3.5 Hard Drive

HDD with Serial Number: WMANU1030677;
Model: WD5000KS-00MNB0;
Date: 26 JAN 2006;
DCM: HBHCAJAH;
Product of: Malaysia;
PCB Sticker: 2061-701383-E00 AA;
PCB Revision: 2060-701383-001 REV P1;
;

HDD with Serial Number: WMANU1030677;
Model: WD5000KS-00MNB0;
Date: 26 JAN 2006;
DCM: HBHCAJAH;
Product of: Malaysia;
PCB Sticker: 2061-701383-E00 AA;
PCB Revision: 2060-701383-001 REV P1;
;

Micro Jogs ;
—————————— ;
LH : PH : Micro Jog (Hex/Dec) ;
—————————— ;
0 : 0 : 84E/2126 ;
1 : 1 : 828/2088 ;
2 : 2 : 862/2146 ;
3 : 3 : 874/2164 ;
4 : 4 : 880/2176 ;
5 : 5 : 838/2104 ;
6 : 6 : 86C/2156 ;
7 : 7 : 854/2132 ;
;
;
ROM F/W version: 0619E ;
Heads map: 0,1,2,3,4,5,6,7 ;
Preamp vendor: 0x0001 ;
Preamp revision: 0x0002

;

WD20NMVW-11AV3S2, DCM EHKTJBKB, Western Digital 2TB USB 2.5 Hard Drive

HDD with Serial Number: WXC1E843SEEM;
Model: WD20NMVW-11AV3S2;
Date: 18 NOV 2014;
DCM: EHKTJBKB;
Product of: Thailand;
PCB Sticker: 771961-G01 AF;
PCB Revision: 2060-771961-001 REV B;

;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 00/0;
1 : 1 : 00/0;
2 : 2 : 00/0;
3 : 3 : 00/0;
4 : 4 : 00/0;
5 : 5 : 00/0;
6 : 6 : 00/0;
7 : 7 : 00/0;
ROM F/W version……………………. : 00210016;
Heads map…………………………. : 0,1,2,3,4,5,6,7;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0001;

;

WD600BB-53CAA1, DCM DSFACV2AA, Western Digital 60GB IDE 3.5 Hard Drive

HDD with Serial Number: WMA8F1214053;
Model: WD600BB-53CAA1;
Date: 14 SEP 2002;
DCM: DSFACV2AA;
Product of: Malaysia;
PCB Sticker: 0000 001092-200 J;
PCB Revision: 2060-001092-007 REV A;

;

;
ROM version……………………….. : 17.2A W;
Head map………………………….. : 0,1,3;
;
;
;

;

WD20NMVW-11EDZS7, DCM EBMTJHKB, Western Digital 2TB USB 2.5 Hard Drive

HDD with Serial Number: WXM1E66ECS21;
Model: WD20NMVW-11EDZS7;
Date: 01 JUN 2017;
DCM: EBMTJHKB;
Product of: Thailand;
PCB Sticker: 771961-R01 AE;
PCB Revision: 2060-771961-001 REV B;
;

HDD with Serial Number: WXM1E66ECS21;
Model: WD20NMVW-11EDZS7;
Date: 01 JUN 2017;
DCM: EBMTJHKB;
Product of: Thailand;
PCB Sticker: 771961-R01 AE;
PCB Revision: 2060-771961-001 REV B;
;

——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 00/0;
1 : 1 : 00/0;
2 : 2 : 00/0;
3 : 3 : 00/0;
4 : 4 : 00/0;
5 : 5 : 00/0;
6 : 6 : 00/0;
7 : 7 : 00/0;
ROM F/W version……………………. : 00210016;
Heads map…………………………. : 0,1,2,3,4,5,6,7

;

WD30EFRX-68EUZN0, DCM HHRNNT2CH, Western Digital 3TB SATA 3.5 Hard Drive

HDD with Serial Number: WMC4N0JASU2S;
Model: WD30EFRX-68EUZN0;
Date: 17 JAN 2015;
DCM: HHRNNT2CH;
Product of: Malaysia;
PCB Sticker: 771945-102 AD;
PCB Revision: 2060-771945-002 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 00/0;
1 : 1 : 00/0;
2 : 2 : 00/0;
3 : 3 : 00/0;
4 : 4 : 00/0;
5 : 5 : 00/0;

;

ROM F/W version: 0001006A;
Heads map: 0,1,2,3,4,5;
Preamp vendor: 0x0000;
Preamp revision: 0x0002;

HDD with Serial Number: WMC4N0JASU2S;
Model: WD30EFRX-68EUZN0;
Date: 17 JAN 2015;
DCM: HHRNNT2CH;
Product of: Malaysia;
PCB Sticker: 771945-102 AD;
PCB Revision: 2060-771945-002 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 00/0;
1 : 1 : 00/0;
2 : 2 : 00/0;
3 : 3 : 00/0;
4 : 4 : 00/0;
5 : 5 : 00/0;

;

;
ROM F/W version: 0001006A;
Heads map: 0,1,2,3,4,5;
Preamp vendor: 0x0000;
Preamp revision: 0x0002;

;

WD30EZRX-00D8PB0, DCM DARNNTJCA, Western Digital 3TB SATA 3.5 Hard Drive

HDD with Serial Number: WMC4N1590272;
Model: WD30EZRX-00D8PB0;
Date: 11 MAR 2014;
DCM: DARNNTJCA;
Product of: Malaysia;
PCB Sticker: 771945-001 AB;
PCB Revision: 2060-771945-001 REV A;

;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 00/0;
1 : 1 : 00/0;
2 : 2 : 00/0;
3 : 3 : 00/0;
4 : 4 : 00/0;
5 : 5 : 00/0;
ROM F/W version……………………. : 0001004Q;
Heads map…………………………. : 0,1,2,3,4,5;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0003;

;
