Category: HDD

WD800JD-75MSA1, DCM HSBHNTJAH, Western Digital 80GB SATA 3.5 Hard Drive

HDD #1 Specs:;
Serial Number: WMAM9N461608;
Model: WD800JD-75MSA1;
Date: 21 JAN 2006;
DCM: HSBHNTJAH;
Product of: Malaysia;
PCB Sticker: 2061-701335-E00 AB;
PCB Revision: 2060-701335-005 REV A;

;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : 43A/1082;
1   : 1   : 44C/1100;
ROM F/W version……………………. : 1097E;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0004;
;
;
;
;

;

WD800JD-75MSA3, DCM HBBHNTJCH, Western Digital 80GB SATA 3.5 Hard Drive

HDD #1 Specs:;
Serial Number: WMAM9CMF2680;
Model: WD800JD-75MSA3;
Date: 08 JUL 2008;
DCM: HBBHNTJCH;
Product of: Malaysia;
PCB Sticker: 2061-701335-E00 AC;
PCB Revision: 2060-701335-006 REV A;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 4B6/1206;
1 : 1 : 48E/1166;

HDD with Serial Number: WMAM9VE28413;
Model: WD800JD-75MSA3;
Date: 15 SEP 2007;
DCM: HBBHNTJCH;
Product of: Malaysia;
PCB Sticker: 2061-701335-E00 AM;
PCB Revision: 2060-701335-005 REV A;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : 474/1140;
1   : 1   : 4A8/1192;
ROM F/W version……………………. : 109KE;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0004;

;
;

HDD #3 Specs:;
Serial Number: WMAM9CLD7328;
Model: WD800JD-75MSA3;
Date: 08 JUL 2008;
DCM: HBBHNTJCH;
Product of: Malaysia;
PCB Sticker: 2061-701335-E00 AN;
PCB Revision: 2060-701335-005 REV A;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 4B6/1206;
1 : 1 : 48E/1166;
ROM F/W version……………………. : 109KE;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0004;
;
;
;
;

;
;

;

WD800JD-75LSA0, DCM DSBHCTJCA, Western Digital 80GB SATA 3.5 Hard Drive

HDD #1 Specs:;
Serial Number: WMAM98995934;
Model: WD800JD-75LSA0;
Date: 10 JUL 2005;
DCM: DSBHCTJCA;
Product of: Malaysia;
PCB Sticker: 2061-701335-A00 ACD24;
PCB Revision: 2060-701335-003 REV A;

;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 47E/1150;
1 : 1 : 460/1120;

;

ROM F/W version……………………. : 06BGD;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0004;

;

WD800JD-75MSA1, DCM HSBHNTJCH, Western Digital 80GB SATA 3.5 Hard Drive

HDD with Serial Number: WMAM9S489367;
Model: WD800JD-75MSA1;
Date: 03 MAR 2006;
DCM: HSBHNTJCH;
Product of: Malaysia;
PCB Sticker: 2061-701335-E00 AD;
PCB Revision: 2060-701335-005 REV A;
;

;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 4A0/1184;
1 : 1 : 45C/1116;

;

ROM F/W version: 10.8SE;
Heads map: 0,1;
Preamp vendor: 0x0001;
Preamp revision: 0x0004;

;

WD800JD-75LSA0, DCM DSBHCTJCH, Western Digital 80GB SATA 3.5 Hard Drive

HDD with Serial Number: WMAM99949738;
Model: WD800JD-75LSA0;
Date: 12 JUL 2005;
DCM: DSBHCTJCH;
Product of: Malaysia;
PCB Sticker: 2061-701335-A00 AC;
PCB Revision: 2060-701335-003 REV B;
Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : 4CC/1228;
1   : 1   : 446/1094;
ROM F/W version……………………. : 06BGD;
Heads map…………………………. : 0,1;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0004;

;

WD800JD-75MSA2, DCM HSBANTJCH, Western Digital 80GB SATA 3.5 Hard Drive

HDD with Serial Number: WMAM9S765314;
Model: WD800JD-75MSA2;
Date: 18 MAR 2006;
DCM: HSBANTJCH;
Product of: Malaysia;
PCB Sticker: 2061-701335-E00 AD;
PCB Revision: 2060-701335-005 REV A;
;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : 45E/1118;
1   : 1   : 460/1120;
ROM F/W version……………………. : 1097E;
Heads map…………………………. : 0,1;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0004;
;
;
;

;

WD800JD-75MSA3, DCM HSBANTJCH, Western Digital 80GB SATA 3.5 Hard Drive

HDD Specs:;
SN: WMAM9CMV1117;
Model: WD800JD-75MSA3;
Date: 13 JUL 2008;
DCM: HSBANTJCH ;
Product of: Malaysia;
PCB Sticker: 2061-701335-Q00 AC;
PCB Revision: 2060-701335-006 REV A;
;
Micro Jogs;

;

——————————
LH  : PH  : Micro Jog (Hex/Dec)
——————————
0   : 0   : 4C4/1220
1   : 1   : 480/1152;

;

ROM F/W version……………………. : 101KE;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x000;

HDD with Serial Number: WMAM9DSV8435;
Model: WD800JD-75MSA3;
Date: 07 APR 2009;
DCM: HSBANTJCH;
Product of: Malaysia;
PCB Sticker: 2061-701335-T00 AA;
PCB Revision: 2060-701335-007 REV A;
;

——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : 4F2/1266;
1   : 1   : 4BA/1210;
;
ROM F/W Version: 101KE;
Heads map: 0,1;
Preamp vendor: 0x0001;
Preamp revision: 0x0004

;

WD800JD-75LSA0, DCM DSBHCVJCH, Western Digital 80GB SATA 3.5 Hard Drive

HDD with Serial Number: WMAM99047039;
Model: WD800JD-75LSA0;
Date: 03 JUL 2005;
DCM: DSBHCVJCH;
Product of: Malaysia;
PCB Sticker: 2061-701335-A00 ACD24;
PCB Revision: 2060-701335-003 REV A;
;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : 426/1062;
1   : 1   : 4AC/1196;
ROM F/W version……………………. : 06BBD;
Heads map…………………………. : 0,1;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0004;

HDD with Serial Number: WMAM98889275;
Model: WD800JD-75LSA0;
Date: 03 JUL 2005;
DCM: DSBHCVJCH;
Product of: Malaysia;
PCB Sticker: 2061-701335-A00 ACD24;
PCB Revision: 2060-701335-003 REV A;
;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : 3C6/966;
1   : 1   : 434/1076;
ROM F/W version……………………. : 06BBD;
Heads map…………………………. : 0,1;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0004;

HDD with Serial Number: WMAM98899125;
Model: WD800JD-75LSA0;
Date: 03 JUL 2005;
DCM: DSBHCVJCH;
Product of: Malaysia;
PCB Sticker: 2061-701335-A00 ACD24;
PCB Revision: 2060-701335-003 REV A;
;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : 424/1060;
1   : 1   : 40E/1038;
ROM F/W version……………………. : 06BBD;
Heads map…………………………. : 0,1;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0004;

HDD with Serial Number: WMAM98889835;
Model: WD800JD-75LSA0;
Date: 03 JUL 2005;
DCM: DSBHCVJCH;
Product of: Malaysia;
PCB Sticker: 2061-701335-A00 ACD24;
PCB Revision: 2060-701335-003 REV A;
;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : 3C8/968;
1   : 1   : 43A/1082;
ROM F/W version……………………. : 06BBD;
Heads map…………………………. : 0,1;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0004;

HDD with Serial Number: WMAM98889511;
Model: WD800JD-75LSA0;
Date: 03 JUL 2005;
DCM: DSBHCVJCH;
Product of: Malaysia;
PCB Sticker: 2061-701335-A00 ACD24;
PCB Revision: 2060-701335-003 REV A;
;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : 416/1046;
1   : 1   : 454/1108;
ROM F/W version……………………. : 06BBD;
Heads map…………………………. : 0,1;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0004;

HDD with Serial Number: WMAM98888653;
Model: WD800JD-75LSA0;
Date: 03 JUL 2005;
DCM: DSBHCVJCH;
Product of: Malaysia;
PCB Sticker: 2061-701335-A00 AC;
PCB Revision: 2060-701335-003 REV B;
;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : 3EE/1006;
1   : 1   : 444/1092;
ROM F/W version……………………. : 06BBD;
Heads map…………………………. : 0,1;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0004;

HDD with Serial Number: WMAM98888879;
Model: WD800JD-75LSA0;
Date: 03 JUL 2005;
DCM: DSBHCVJCH;
Product of: Malaysia;
PCB Sticker: 2061-701335-A00 ACD24;
PCB Revision: 2060-701335-003 REV A;
;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : 3D4/980;
1   : 1   : 474/1140;
ROM F/W version……………………. : 06BBD;
Heads map…………………………. : 0,1;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0004;

;
