Category: HDD

HDD with Serial Number: WMAM99408966;
Model: WD800JD-75LSA0;
Date: 24 JUN 2005;
DCM: HSBHYTJCH;
Product of: Malaysia;
PCB Sticker: 2061-701335-A00 AC;
PCB Revision: 2060-701335-003 REV B;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 478/1144;
1 : 1 : 42C/1068;
ROM F/W version……………………. : 06BBD;
Heads map…………………………. : 0,1;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0004;

;

HDD #1 Specs:;
Serial Number: WMAM9HE53460;
Model: WD800JD-75MSA3;
Date: 02 DEC 2006;
DCM: ESBHNTJEA;
Product of: Malaysia;
PCB Sticker: 2061-701335-E00 AK;
PCB Revision: 2060-701335-005 REV A;

;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 43E/1086;
1 : 1 : 488/1160;

;

ROM F/W version……………………. : 109DE;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0004;

;

HDD #1 Specs:;
Serial Number: WMAM99837243;
Model: WD800JD-75LSA0;
Date: 09 JUL 2005;
DCM: HSCACVJCH;
Product of: Malaysia;
PCB Sticker: 2061-701335-A00 ACD24;
PCB Revision: 2060-701335-003 REV A;

;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 3C6/966;
1 : 1 : 40E/1038;

;

ROM F/W version……………………. : 06BGD;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0004;

;

HDD with Serial Number: WMAM9JL61982;
Model: WD800JD-75MSA3;
Date: 20 JAN 2007;
DCM: ESBHYTJCH;
Product of: Malaysia;
PCB Sticker: 2061-701335-E00 AK;
PCB Revision: 2060-701335-005 REV A;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : 48C/1164;
1   : 1   : 4F8/1272;
ROM F/W version……………………. : 109KE;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0004;
;
;

HDD with Serial Number: WMAM9JL61984;
Model: WD800JD-75MSA3;
Date: 20 JAN 2007;
DCM: ESBHYTJCH;
Product of: Malaysia;
PCB Sticker: 2061-701335-E00 AK;
PCB Revision: 2060-701335-005 REV A;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : 448/1096;
1   : 1   : 4BA/1210;
ROM F/W version……………………. : 109KE;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0004;
;
;

;

HDD with Serial Number: WMAM9H823815;
Model: WD800JD-75MSA1;
Date: 16 NOV 2005;
DCM: DSBANTJAA;
Product of: Malaysia;
PCB Sticker: 2061-701335-A00 AH;
PCB Revision: 2060-701335-003 REV B;
;

——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : 44A/1098;
1   : 1   : 446/1094;
;
ROM F/W Version: 108SE;
Heads map: 0,1;
Preamp vendor: 0x0001;
Preamp revision: 0x0004

;

HDD with Serial Number: WMAM9KC98567;
Model: WD800JD-75MSA3;
Date: 28 JAN 2007;
DCM: ESCANTJEA;
Product of: Malaysia;
PCB Sticker: 2061-701335-E00 AK;
PCB Revision: 2060-701335-005 REV A;
;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : 4AE/1198;
1   : 1   : 4CA/1226;
ROM F/W version……………………. : 109KE;
Heads map…………………………. : 0,1;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0004;

;

HDD #1 Specs:;
SN: WMAM9K254374;
Model: WD800JD-75MSA1;
Date: 17 DEC 2005;
DCM: DSBHYTJCH ;
Product of: Malaysia;
PCB Sticker: 2061-701335-E00 AA;
PCB Revision: 2060-701335-005 REV A;

;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : 4A6/1190;
1   : 1   : 4A0/1184;
;
ROM F/W version……………………. : 100SE;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0004;

;

;

HDD #1 Specs:;
SN: WMAM9AEL5454;
Model: WD800JD-75MSA3;
Date: 23 FEB 2008;
DCM: HBBANTJCA ;
Product of: Malaysia;
PCB Sticker: 2061-701335-E00 AM;
PCB Revision: 2060-701335-005 REV A;

;

Micro Jogs
——————————
LH  : PH  : Micro Jog (Hex/Dec)
——————————
0   : 0   : 480/1152;
1   : 1   : 44A/1098;

;

ROM F/W version……………………. : 109KE;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0004;
;
;

;

HDD with Serial Number: WMAM9CJY4397;
Model: WD800JD-75MSA3;
Date: 01 JUL 2008;
DCM: HBBANTJCA;
Product of: Malaysia;
PCB Sticker: 2061-701335-Q00 ABD8;
PCB Revision: 2060-701335-006 REV A;

;

HDD with Serial Number: WMAM93191543;
Model: WD800JD-75JNA0;
Date: 08 DEC 2004;
DCM: HSBAYTJCA;
Product of: Malaysia;
PCB Sticker: 2061-001293-B00 AG;
PCB Revision: 2060-001293-000 REV A;
;

;

Specifications:;
SN WMAM9A032308;
Model WD800JD-75LSA0;
Date 16 JUL 2005;
DCM DSBANTJAA ;
Product of Malaysia;
PCB Sticker: 2061-701335-A00 AC;
PCB Revision: 2060-701335-003 REV B;

;

;
