Category: HDD

HDD with Serial Number: WMAYP3394357;
Model: WD5003ABYX-01WERA1;
Date: 21 MAR 2012;
DCM: HGRCKVJCG;
Product of: Malaysia;
PCB Sticker: 2061-771702-C01 AB;
PCB Revision: 2060-771702-001 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : BC5/3013;
1 : 1 : B45/2885;
ROM F/W version……………………. : 0005008U;
Heads map…………………………. : 0,1;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0001;

;

HDD with Serial Number: WMAYP3417016;
Model: WD5003ABYX-01WERA1;
Date: 21 MAR 2012;
DCM: HGRCKVJCH;
Product of: Malaysia;
PCB Sticker: 2061-771702-C01 AB;
PCB Revision: 2060-771702-001 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : B6D/2925;
1 : 1 : B55/2901;
ROM F/W version……………………. : 0005008U;
Heads map…………………………. : 0,1;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0001;

;

HDD #1 Specs:;
Serial Number: WMAYP1715197;
Model: WD5003ABYX-01WERA0;
Date: 18 JUL 2011;
DCM: HGRNHTJCGN;
Product of: Thailand;
PCB Sticker: 2061-771702-501 AG;
PCB Revision: 2060-771702-001 REV A;

;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : C78/3192;
1   : 1   : D2C/3372;

;

Preamp Vendor……………………… : 0001;
Preamp Rev………………………… : 0001;
;

;

HDD with Serial Number: WMAYP4082285;
Model: WD5003ABYX-01WERA1;
Date: 26 MAY 2012;
DCM: HGRNKTJCG;
Product of: Malaysia;
PCB Sticker: 2061-771702-C01 AB;
PCB Revision: 2060-771702-001 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : D58/3416;
1 : 1 : D80/3456;
ROM F/W version……………………. : 0005009G;
Heads map…………………………. : 0,1;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0001;

;

HDD with Serial Number: WMAYP0589302;
Model: WD5003ABYX-01WERA0;
Date: 10 FEB 2011;
DCM: HHRCHTJAH;
Product of: Malaysia;
PCB Sticker: 2061-771702-501 AD;
PCB Revision: 2060-771702-001 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : C98/3224;
1 : 1 : CB8/3256;
ROM F/W version……………………. : 0005000Q;
Heads map…………………………. : 0,1;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0001;

;

HDD with Serial Number: WMAYP4161524;
Model: WD5003ABYX-01WERA1;
Date: 26 MAY 2012;
DCM: HGRNNTJCG;
Product of: Malaysia;
PCB Sticker: 2061-771702-C01 AB;
PCB Revision: 2060-771702-001 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : C5C/3164;
1 : 1 : CCC/3276;
ROM F/W version……………………. : 0005009G;
Heads map…………………………. : 0,1;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0001;

;

HDD #1 Specs:;
SN: WMAYP0557066;
Model: WD5003ABYX-01WERA0;
Date: 24 FEB 2011;
DCM: HHRCHTJAHB ;
Product of: Thailand;
PCB Sticker: 2061-771702-501 AF;
PCB Revision: 2060-771702-001 REV A;

;

;

HDD with Serial Number: WMAYP3339279;
Model: WD5003ABYX-01WERA1;
Date: 01 MAR 2012;
DCM: HHNCHTJCG;
Product of: Malaysia;
PCB Sticker: 2061-771702-C01 AB;
PCB Revision: 2060-771702-001 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : CC4/3268;
1 : 1 : D60/3424;
ROM F/W version……………………. : 0005008H;
Heads map…………………………. : 0,1;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0001;

;

HDD with Serial Number: WCASY5786196;
Model: WD5002ABYS-01B1B0;
Date: 15 JUN 2009;
DCM: HBRNNV2MBB;
Product of: Thailand;
PCB Sticker: 2061-701537-U00 08P;
PCB Revision: 2060-701537-004 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 8A1/2209;
1 : 1 : 8E0/2272;
2 : 2 : 8EB/2283;
3 : 3 : 8F6/2294;

;

ROM F/W version:0005008T;
Preamp vendor:0x0000;
Preamp revision:0x0002;

;

HDD with Serial Number: WCASYE543993;
Model: WD5002ABYS-02B1B0;
Date: 14 AUG 2010;
DCM: HARNHT2MAB;
Product of: Thailand;
PCB Sticker: 2061-701537-U00 10PD1;
PCB Revision: 2060-701537-004 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 9DB/2523;
1 : 1 : 98C/2444;
2 : 2 : 9B4/2484;
3 : 3 : 9C4/2500;
ROM F/W version……………………. : 0005009N;
Heads map…………………………. : 0,1,2,3;
Preamp vendor……………………. : 0x0000;
Preamp revision………………….. : 0x0002;

;
