Category: HDD

WD5001AALS-00E3A0, DCM EBRNHTJABB, Western Digital 500GB SATA 3.5 Hard Drive

HDD with Serial Number: WCATR3493354;
Model: WD5001AALS-00E3A0;
Date: 13 SEP 2010;
DCM: EBRNHTJABB;
Product of: Thailand;
PCB Sticker: 2061-701640-D02 ACD14;
PCB Revision: 2060-701640-002 REV A;

;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : BB6/2998;
1   : 2   : BBA/3002;
2   : 3   : C33/3123;
ROM F/W version……………………. : 0001002G;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0001;
;
;
;
;

;

WD5001AALS-00J7B1, DCM HARNNT2AB, Western Digital 500GB SATA 3.5 Hard Drive

HDD with Serial Number: WMATV6601920;
Model: WD5001AALS-00J7B1;
Date: 17 MAR 2010;
DCM: HARNNT2AB;
Product of: Malaysia;
PCB Sticker: 2061-701567-400 AF;
PCB Revision: 2060-701567-000 REV A;
;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 3   : A35/2613;
1   : 5   : A0F/2575;
2   : 6   : 9C2/2498;
3   : 7   : A1F/2591;
ROM F/W version……………………. : 0009009W;
Heads map…………………………. : 3,5,6,7;
Preamp vendor……………………. : 0x0000;
Preamp revision………………….. : 0x0003;
;
;
;

;

WD5000YS-01MPB0, DCM HCHCAJAAB, Western Digital 500GB SATA 3.5 Hard Drive

HDD #1 Specs:;
Serial Number: WCANU1685127;
Model: WD5000YS-01MPB0;
Date: 19 DEC 2006;
DCM: HCHCAJAAB;
Product of: Thailand;
PCB Sticker: 2061-701383-E00 AJ;
PCB Revision: 2060-701383-001 REV A;

;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : 7E2/2018;
1   : 1   : 854/2132;
2   : 2   : 7BC/1980;
3   : 3   : 892/2194;
4   : 4   : 7E2/2018;
5   : 5   : 88A/2186;
6   : 6   : 7D4/2004;
7   : 7   : 836/2102;

;

ROM F/W version……………………. : 072CE;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0002;

;

WD5001AALS-00E3A0, DCM HANNHTJAAB, Western Digital 500GB SATA 3.5 Hard Drive

HDD with Serial Number: WCATR2940407;
Model: WD5001AALS-00E3A0;
Date: 13 SEP 2010;
DCM: HANNHTJAAB;
Product of: Thailand;
PCB Sticker: 771640-202 06P;
PCB Revision: 2060-771640-002 REV P2;

;

ROM F/W version……………………. : 0001002G;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0001;
Heads map…………………………. : 0,1,2,3;

;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : C36/3126;
1 : 1 : CF1/3313;
2 : 2 : C47/3143;
3 : 3 : D0E/3342;

;

;
;

;

WD5001AALS-00J7B1, DCM HBNNHT2CA, Western Digital 500GB SATA 3.5 Hard Drive

HDD with Serial Number: WMATV4479709;
Model: WD5001AALS-00J7B1;
Date: 08 DEC 2009;
DCM: HBNNHT2CA;
Product of: Malaysia;
PCB Sticker: 2061-701622-800 05P;
PCB Revision: 2060-701622-000 REV P1;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 3 : A10/2576;
1 : 4 : 9B5/2485;
2 : 5 : A3B/2619;
3 : 6 : 9D4/2516;
ROM F/W version……………………. : 0009009P;
Heads map…………………………. : 3,4,5,6;
Preamp vendor……………………… : 0x0000;
Preamp revision……………………. : 0x0003;

;

WD5000YS-01MPB0, DCM HCHCAJAHB, Western Digital 500GB SATA 3.5 Hard Drive

HDD with Serial Number: WCANU1702423;
Model: WD5000YS-01MPB0;
Date: 16 DEC 2006;
DCM: HCHCAJAHB;
Product of: Thailand;
PCB Sticker: 2061-701383-E00 AJ;
PCB Revision: 2060-701383-001 REV A;
;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : 7BE/1982;
1   : 1   : 844/2116;
2   : 2   : 784/1924;
3   : 3   : 860/2144;
4   : 4   : 75E/1886;
5   : 5   : 854/2132;
6   : 6   : 764/1892;
7   : 7   : 844/2116;
ROM F/W version……………………. : 072CE;
Heads map…………………………. : 0,1,2,3,4,5,6,7;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0002;

;

WD5001AALS-00E3A0, DCM HARNHTJAAB, Western Digital 500GB SATA 3.5 Hard Drive

HDD #1 Specs:;
SN WCATR3243051;
Model WD5001AALS-00E3A0;
Date 19 SEP 2010;
DCM HARNHTJAAB;
DCX 4005E3633;
Product of Thailand;
PCB Sticker: 2061-701640-D02 ACD14;
PCB Revision: 2060-701640-002 REV A;

;

ROM F/W version……………………. : 0001002G;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0001;
Heads map…………………………. : 0,1,2,3;

;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : D36/3382;
1   : 1   : CA6/3238;
2   : 2   : D0C/3340;
3   : 3   : CC5/3269;
;
;

;

WD5001AALS-00J7B1, DCM HBNNHT2CB, Western Digital 500GB SATA 3.5 Hard Drive

HDD with Serial Number: WMATV6651005;
Model: WD5001AALS-00J7B1;
Date: 17 MAR 2010;
DCM: HBNNHT2CB;
Product of: Malaysia;
PCB Sticker: 2061-701567-400 AF;
PCB Revision: 2060-701567-000 REV A;

;

ROM F/W version 0009009W Heads map 3,5,6,7 Preamp vendor: x0000 Preamp revision: x0003 Micro Jogs —————————— LH : PH : Micro Jog (Hex/Dec) —————————— 0 : 3 : 96B/2411 1 : 5 : 95D/2397 2 : 6 : 99A/2458 3 : 7 : 984/2436;

;

 ;

;
