Category: HDD

HDD with Serial Number: WX11A13E2155;
Model: WD5000LPVT-22G33T0;
Date: 24 JAN 2013;
DCM: HBOTJANB;
Product of: Thailand;
PCB Sticker: 771852-201 AC;
PCB Revision: 2060-771852-001 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 1090/4240;
1 : 1 : 101D/4125;

;

;
ROM F/W version: 0002004P;
Heads map: 0,1;
Preamp vendor: 0x0001;
Preamp revision: 0x0001;

;

HDD with Serial Number: WX91C4235335;
Model: WD5000LPVT-08G33T1;
Date: 31 AUG 2012;
DCM: HHCVJHBB;
Product of: Thailand;
PCB Sticker: 771852-204 AA;
PCB Revision: 2060-771852-004 REV P1;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : FF8/4088;
1 : 1 : 101D/4125;
ROM F/W version……………………. : 0002004C;
Heads map…………………………. : 0,1;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0001;

;

HDD with Serial Number: WX11AB233933;
Model: WD5000LPVT-22G33T0;
Date: 11 JAN 2013;
DCM: HBOTJHB;
Product of: Malaysia;
PCB Sticker: 771852-201 AD;
PCB Revision: 2060-771852-001 REV A;
;

ROM F/W version 0002004P;
Heads map: :  0,1;
Preamp vendor: x001;
Preamp revision: x0001;
;
Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : 1046/4166;
1   : 1   : 106F/4207

;

HDD #1 Specs:;
SN: WXB1A4321019;
Model: WD5000LPVT-16G33T0;
Date: 25 MAY 2013;
DCM: HA0TJABB ;
Product of: Thailand;
PCB Sticker: 771852-204 AHD27;
PCB Revision: 2060-771852-004 REV A;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : F37/3895;
1   : 1   : 10AE/4270;

ROM F/W version……………………. : 00020066;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0001;

;

HDD #1 Specs:;
Serial Number: WX41A13F0696;
Model: WD5000LPVT-22G33T0;
Date: 02 FEB 2013;
DCM: HBOTJHBB;
Product of: Thailand;
PCB Sticker: 771852-201 AF;
PCB Revision: 2060-771852-001 REV A;

;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : 10C4/4292;
1   : 1   : 1010/4112;
;
;
;

;

HDD #2 Specs:;
SN: WXB1A4320823;
Model: WD5000LPVT-16G33T0;
Date: 25 MAY 2013;
DCM: HA0TJBBB ;
Product of: Thailand;
PCB Sticker: 771852-204 AHD27;
PCB Revision: 2060-771852-004 REV A;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : 1093/4243;
1   : 1   : F6D/3949;
;
ROM F/W version……………………. : 00020066;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0001;

;

HDD with Serial Number: WX41AC2V4415;
Model: WD5000LPVT-16G33T0;
Date: 04 JAN 2013;
DCM: HBCVJHB;
Product of: Malaysia;
PCB Sticker: 771852-204 AB;
PCB Revision: 2060-771852-004 REV P1;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 101C/4124;
1 : 1 : 1006/4102;

;
ROM F/W version: 0002004P;
Heads map: 0,1;
Preamp vendor: 0x0001;
Preamp revision: 0x0001;

;

;
;
HDD #1 Specs:;
SN: WXC1A43A9291;
Model: WD5000LPVT-16G33T0;
Date: 25 MAY 2013;
DCM: HHOTJABB ;
Product of: Thailand;
PCB Sticker: 771852-204 AHD27;
PCB Revision: 2060-771852-004 REV A;

;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : 1090/4240;
1   : 1   : FFE/4094;
ROM F/W version……………………. : 00020066;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0001;

;

HDD with Serial Number: WX71C32M9903;
Model: WD5000LPVT-00G33T0;
Date: 12 MAY 2012;
DCM: HACVJHBB;
Product of: Thailand;
PCB Sticker: 771852-201 05P;
PCB Revision: 2060-771852-001 REV P1;
;

ROM F/W versionn 00020010;
Heads map:  0,1;
Preamp vendor: x001;
Preamp revision: x0001;
;
Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : FC4/4036;
1   : 1   : 106E/4206

;

HDD with Serial Number: WXA1C42T1957;
Model: WD5000LPVT-00G33T0;
Date: 09 AUG 2013;
DCM: HAOVJHB;
Product of: Thailand;
PCB Sticker: 771852-201 AC;
PCB Revision: 2060-771852-001 REV P1;
;

;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 1062/4194;
1 : 1 : 1046/4166;

;

ROM F/W version: 0002004C;
Heads map: 0,1;
Preamp vendor: 0x0000;
Preamp revision: 0x0000;

;
