Category: HDD

HDD #1 Specs:;
SN: WMAM9AT45378;
Model: WD800JD-00MSA1;
Date: 05 AUG 2006;
DCM: ESCHCTJCH ;
Product of: Malaysia;
PCB Sticker: 2061-701335-E00 AE;
PCB Revision: 2060-701335-005 REV A;

;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : 44E/1102;
1   : 1   : 476/1142;
ROM F/W version……………………. : 109DE;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0004;
;
;
;
;

;

HDD #1 Specs:;
Serial Number: WCAMD4114827;
Model: WD800JD-00JRC0;
Date: 24 AUG 2005;
DCM: HSBAYTJCA;
Product of: Thailand;
PCB Sticker: 2061-701293-B00 AN;
PCB Revision: 2060-701293-001 REV A;

;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 480/1152;
1 : 1 : 45A/1114;

;

ROM F/W version……………………. : 0892C;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0004;

;

HDD with Serial Number: WMAM9KU64083;
Model: WD800JD-00MSA1;
Date: 22 FEB 2007;
DCM: HSBAYTJCH;
Product of: Malaysia;
PCB Sticker: 2061-701335-E00 AL;
PCB Revision: 2060-701335-005 REV A;

;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 4BE/1214;
1 : 1 : 544/1348;

;

ROM F/W version……………………. : 109KE;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0004;

;

HDD with Serial Number: WMAM9PX65742;
Model: WD800JD-00LSA0;
Date: 01 JUN 2007;
DCM: DBBANTJAH;
Product of: Malaysia;
PCB Sticker: 2061-701335-E00 AM;
PCB Revision: 2060-701335-005 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 49C/1180;
1 : 1 : 4FA/1274;
ROM F/W version……………………. : 06BWD;
Heads map…………………………. : 0,1;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0004;

;

HDD with Serial Number: WMAM9DZH7799;
Model: WD800JD-00MSA1;
Date: 18 JUN 2009;
DCM: HSBHNTJCA;
Product of: Malaysia;
PCB Sticker: 2061-701335-T00 AB;
PCB Revision: 2060-701335-007 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 4C8/1224;
1 : 1 : 4C8/1224;

;

ROM F/W: 101KE;
Heads map: 0,1;
Preamp vendor: 0x0001;
Preamp revision: 0x0004;

;

HDD with Serial Number: WMAM9Z014000;
Model: WD800JD-00LSA0;
Date: 26 JUN 2006;
DCM: DSBHNTJAH;
Product of: Malaysia;
PCB Sticker: 2061-701335-E00 AE;
PCB Revision: 2060-701335-005 REV A;
;

——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : 4AE/1198;
1   : 1   : 4EA/1258;
;
ROM F/W Version: 06BUD;
Heads map: 0,1;
Preamp vendor: 0x0001;
Preamp revision: 0x0004

;

HDD with Serial Number: WMAM9XZ80963;
Model: WD800JD-00MSA1;
Date: 30 NOV 2007;
DCM: HSBHNTJEH;
Product of: Malaysia;
PCB Sticker: 2061-701335-E00 AM;
PCB Revision: 2060-701335-005 REV A;
;

ROM F/W versionn 109KE;
Heads map:  :0,1;
Preamp vendor: x001;
Preamp revision: x0004;
;
;
Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : 4B4/1204;
1   : 1   : 48A/1162

;

HDD with Serial Number: WMAM9DMV1312;
Model: WD800JB-22JJC0;
Date: 14 FEB 2009;
DCM: HSBANTJCA;
Product of: Malaysia;
PCB Sticker: 2061-701292-A00 BE;
PCB Revision: 2060-701292-002 REV A;
;

;

HDD with Serial Number: WMAM9H154900;
Model: WD800JD-00LSA0;
Date: 08 NOV 2005;
DCM: DSCANTJCH;
Product of: Malaysia;
PCB Sticker: 2061-701335-A00 AH;
PCB Revision: 2060-701335-003 REV B;

;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 4A2/1186;
1 : 1 : 450/1104;

;

ROM F/W Version: 06BTD;
Heads Map: 0,1;
Preamp Vendor: 0x0001;
Preamp Revision: 0x0004;

;

HDD with Serial Number: WMAM9APX4636;
Model: WD800JD-00MSA1;
Date: 02 APR 2008;
DCM: HSCANTJCH;
Product of: Malaysia;
PCB Sticker: 2061-701335-E00 AM;
PCB Revision: 2060-701335-005 REV A;
;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : 49C/1180;
1   : 1   : 488/1160;
ROM F/W version……………………. : 109KE;
Heads map…………………………. : 0,1;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0004;

;
