Category: HDD

HDD with Serial Number: WX11E61RF700;
Model: WD5000BPVT-24HXZT3;
Date: 09 SEP 2011;
DCM: DHOTJHBB;
Product of: Thailand;
PCB Sticker: 771820-200 03P;
PCB Revision: 2060-771820-000 REV P1;
;

ROM F/W 00650009;
Heads map  1,2,3;
Preamp vendor:x0001;
preamp revision:x0003;
;
Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 1   : AE4/2788;
1   : 2   : B30/2864;
2   : 3   : AEA/2794

;

HDD with Serial Number: WXK1A71X3264;
Model: WD5000BPVT-35HXZT1;
Date: 22 AUG 2011;
DCM: HBOT2BB;
Product of: Malaysia;
PCB Sticker: 771692-905 AAD23;
PCB Revision: 2060-771692-005 REV A;
;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 1   : B0C/2828;
1   : 2   : AA0/2720;
2   : 3   : B52/2898;
ROM F/W version……………………. : 00100018;
Heads map…………………………. : 1,2,3;
Preamp vendor……………………. : 0x0000;
Preamp revision………………….. : 0x0009;

;

HDD with Serial Number: WXH1A91P5611;
Model: WD5000BPVT-22HXZT3;
Date: 30 NOV 2011;
DCM: HHOTJVN;
Product of: Malaysia;
PCB Sticker: 771820-800 AB;
PCB Revision: 2060-771820-000 REV P1;

;



;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 1 : BB2/2994;
1 : 2 : B1E/2846;
2 : 3 : B54/2900;

;



;

ROM F/W version……………………. : 0065000A;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0003;

;

HDD with Serial Number: WXB1EA1CUSL3;
Model: WD5000BPVT-24HXZT3;
Date: 23 MAR 2012;
DCM: EAOT2AB;
Product of: Malaysia;
PCB Sticker: 771820-200 03P;
PCB Revision: 2060-771820-000 REV P1;

;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 1 : A52/2642;
1 : 2 : AF6/2806;
2 : 3 : AC6/2758;

;

ROM F/W version: 0065000P;
Heads map: 1,2,3;
Preamp vendor: 0x0000;
Preamp revision: 0x0009;

;

HDD with Serial Number: WX41EA1YHL07;
Model: WD5000BPVT-24HXZT3;
Date: 23 MAR 2012;
DCM: EAOT2AB;
Product of: Malaysia;
PCB Sticker: 771820-800 AF;
PCB Revision: 2060-771820-000 REV A;

;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : AB0/2736;
1 : 1 : B0E/2830;
2 : 2 : AB2/2738;

;

ROM F/W version: 0065000P;
Heads map: 0,1,2;
Preamp vendor: 0x0000;
Preamp revision: 0x0009;

;

HDD with Serial Number: WX31CC1D8326;
Model: WD5000BPVT-22HXZT3;
Date: 26 JAN 2012;
DCM: HVOT2BBB;
Product of: Thailand;
PCB Sticker: 771820-200 AB;
PCB Revision: 2060-771820-000 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : A86/2694;
1 : 1 : AEC/2796;
2 : 2 : A66/2662;
ROM F/W version……………………. : 0065000N;
Heads map…………………………. : 0,1,2;
Preamp vendor……………………. : 0x0000;
Preamp revision………………….. : 0x0009;

;

HDD #1 Specs:;
Serial Number: WX41EA1THP26;
Model: WD5000BPVT-24HXZT3;
Date: 23 MAR 2012;
DCM: EAOTJAB;
Product of: Malaysia;
PCB Sticker: 771820-900 AF;
PCB Revision: 2060-771820-000 REV A;

;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 1   : A7F/2687;
1   : 2   : A8E/2702;
2   : 3   : A78/2680;
ROM F/W version……………………. : 0065000P;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0003;
;
;
;
;

;

HDD with Serial Number: WX41CC1C5461;
Model: WD5000BPVT-22HXZT3;
Date: 17 JAN 2012;
DCM: HVOTJBNB;
Product of: Thailand;
PCB Sticker: 771820-200 AB;
PCB Revision: 2060-771820-000 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : B3A/2874;
1 : 1 : AF8/2808;
2 : 2 : B34/2868;

;

ROM F/W version: 0065000G;
Heads map: 0,1,2;
Preamp vendor: 0x0001;
Preamp revision: 0x0003;

;

HDD #1 Specs:;
Serial Number: WXB1E62RLY81;
Model: WD5000BPVT-24HXZT3;
Date: 02 SEP 2012;
DCM: EBCT2HB;
Product of: Malaysia;
PCB Sticker: 771820-B00 AA;
PCB Revision: 2060-771820-000 REV A;

;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 1   : ABC/2748;
1   : 2   : A9E/2718;
2   : 3   : AE8/2792;
ROM F/W version……………………. : 00650018;
Preamp vendor……………………… : 0x0000;
Preamp revision……………………. : 0x0009;
;
;
;
;

;

HDD with Serial Number: WXN1E32MRYSF;
Model: WD5000BPVT-22A1YT0;
Date: 14 JUL 2012;
DCM: EHCVJHB;
Product of: Malaysia;
PCB Sticker: 771823-300 AG;
PCB Revision: 2060-771823-000 REV A;
;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 1   : 1075/4213;
1   : 2   : F8C/3980;
2   : 3   : 1045/4165

;

HDD with Serial Number: WXC1A31W8509;
Model: WD5000BPVT-22HXZT1;
Date: 14 MAY 2011;
DCM: HHOT2HB;
Product of: Malaysia;
PCB Sticker: 771692-905 01P;
PCB Revision: 2060-771692-005 REV A;
;

——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : AFE/2814;
1   : 1   : ABE/2750;
2   : 2   : AEA/2794;
3   : 3   : ACC/2764;
;
ROM F/W Version: 0009001S;
Heads map: 0,1,2,3;
Preamp vendor: 0x0000;
Preamp revision: 0x0009

;
