Category: HDD

HDD with Serial Number: WXD1E71HZKE6;
Model: WD5000BPKT-80PK4T0;
Date: 04 SEP 2011;
DCM: EACTJBBB;
Product of: Thailand;
PCB Sticker: 771629-106 ABD34;
PCB Revision: 2060-771629-006 REV A;
;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : A3E/2622;
1   : 2   : A66/2662;
2   : 3   : B66/2918;
ROM F/W version……………………. : 0009002D;
Heads map…………………………. : 0,2,3;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0003;

;

HDD with Serial Number: WXL1E92LUVP9;
Model: WD5000BPKT-75PK4T0;
Date: 21 MAR 2013;
DCM: EBOTJHB;
Product of: Malaysia;
PCB Sticker: 771629-106 AH;
PCB Revision: 2060-771629-006 REV A;
;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 1   : B7A/2938;
1   : 2   : B4C/2892;
2   : 3   : B6E/2926;
ROM F/W version……………………. : 00090030;
Heads map…………………………. : 1,2,3;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0003;

;

HDD with Serial Number: WX21E42UP111;
Model: WD5000BPKT-75PK4T0;
Date: 21 NOV 2012;
DCM: EHOTJHB;
Product of: Malaysia;
PCB Sticker: 771629-106 AH;
PCB Revision: 2060-771629-006 REV A;

;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : A96/2710;
1 : 2 : AB4/2740;
2 : 3 : B12/2834;

;

ROM F/W version……………………. : 0009002V;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0003;

;

HDD with Serial Number: WXK1E72HXRX8;
Model: WD5000BPKT-75PK4T0;
Date: 17 OCT 2012;
DCM: EHOTJHB;
Product of: Malaysia;
PCB Sticker: 771629-106 AH;
PCB Revision: 2060-771629-006 REV A;

;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 1 : AE4/2788;
1 : 2 : B22/2850;
2 : 3 : ABC/2748;

;

ROM F/W version……………………. : 0009002V;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0003;

;

HDD with Serial Number: WXK1E72ECDE9;
Model: WD5000BPKT-75PK4T0;
Date: 26 FEB 2013;
DCM: EHOTJHN;
Product of: Malaysia;
PCB Sticker: 771629-106 AH;
PCB Revision: 2060-771629-006 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 1 : B26/2854;
1 : 2 : B18/2840;
2 : 3 : B16/2838;
ROM F/W version……………………. : 00090030;
Heads map…………………………. : 1,2,3;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0003;

HDD with Serial Number: WXK1E72CZKE1;
Model: WD5000BPKT-75PK4T0;
Date: 16 NOV 2012;
DCM: EHOTJHN;
Product of: Malaysia;
PCB Sticker: 771629-106 AH;
PCB Revision: 2060-771629-006 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : B42/2882;
1 : 1 : B26/2854;
2 : 2 : B64/2916;
3 : 3 : B66/2918;
ROM F/W version……………………. : 0009002V;
Heads map…………………………. : 0,1,2,3;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0003;

;

HDD #1 Specs:;
SN: WX71A82J4779;
Model: WD5000BPKT-75PK4T0;
Date: 08 OCT 2012;
DCM: HA0TJHB ;
Product of: Malaysia;
PCB Sticker: 771629-106 AH;
PCB Revision: 2060-771629-006 REV A;

;
;

;

HDD with Serial Number: WX31CC1N5307;
Model: WD5000BPKT-75PK4T0;
Date: 03 MAY 2012;
DCM: HACTJAB;
Product of: Malaysia;
PCB Sticker: 771629-106 AG;
PCB Revision: 2060-771629-006 REV P1;
Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : AF0/2800;
1 : 2 : AC6/2758;
2 : 3 : B26/2854;
ROM F/W version……………………. : 0009002J;
Heads map…………………………. : 0,2,3;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0003;

;

HDD with Serial Number: WXJ1A11E4438;
Model: WD5000BPKT-75PK4T0;
Date: 09 MAR 2011;
DCM: HACTJANB;
Product of: Thailand;
PCB Sticker: 771629-106 01P;
PCB Revision: 2060-771629-006 REV P1;

;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : AAC/2732;
1 : 1 : AF8/2808;
2 : 3 : B9E/2974;

;

ROM F/W version: 00020014;
Heads map: 0,1,3;
Preamp vendor: 0x0001;
Preamp revision: 0x0003;

;

HDD with Serial Number: WXL1A81P0855;
Model: WD5000BPKT-75PK4T0;
Date: 14 MAY 2012;
DCM: HACTJHB;
Product of: Malaysia;
PCB Sticker: 771629-106 AG;
PCB Revision: 2060-771629-006 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : AD0/2768;
1 : 1 : B1E/2846;
2 : 2 : AC6/2758;
3 : 3 : B7A/2938;
ROM F/W version……………………. : 0009002S;
Heads map…………………………. : 0,1,2,3;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0003;

;

HDD #1 Specs:;
Serial Number: WXB1A9175701;
Model: WD5000BPKT-00PK4T0;
Date: 23 FEB 2012;
DCM: HHNTJBB;
Product of: Malaysia;
PCB Sticker: 771629-106 AED34;
PCB Revision: 2060-771629-006 REV A;

;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : B16/2838;
1   : 1   : B76/2934;
2   : 2   : ABC/2748;
3   : 3   : ADC/2780;

;

Preamp Vendor……………………… : 0001;
Preamp Rev………………………… : 0003;
;

;

HDD with Serial Number: WXL1A8163736;
Model: WD5000BPKT-22PK4T0;
Date: 26 DEC 2011;
DCM: HHNTJHN;
Product of: Malaysia;
PCB Sticker: 771629-106 ACD34;
PCB Revision: 2060-771629-006 REV A;
;

——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 1   : BAA/2986;
1   : 2   : AE8/2792;
2   : 3   : BA4/2980;
;
ROM F/W Version: 0009002C;
Heads map: 1,2,3;
Preamp vendor: 0x0001;
Preamp revision: 0x0003

;
