Category: HDD

HDD with Serial Number: WXF1EB0P5861;
Model: WD5000BMVW-11AMCS0;
Date: 11 MAR 2011;
DCM: DACVJAN;
Product of: Malaysia;
PCB Sticker: 771737-300 08P;
PCB Revision: 2060-771737-000 REV P1;
;

;

Specifications;
SN: WX11E3145424;
Model: WD5000BMVW-11AMCS0;
Date: 12 APR 2011;
DCM: DACVJBB ;
Product of: Malaysia;
PCB Sticker: 771737-300 08P;
PCB Revision: 2060-771737-000 REV A;

;

;

HDD with Serial Number: WXF1EB0P6243;
Model: WD5000BMVW-11AMCS0;
Date: 11 MAR 2011;
DCM: DACVJHB;
Product of: Malaysia;
PCB Sticker: 771737-300 08P;
PCB Revision: 2060-771737-000 REV P1;

;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : B4B/2891;
1 : 1 : B19/2841;
2 : 2 : BE4/3044;
3 : 3 : AFB/2811;

;

ROM F/W version……………………. : 0006002E;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0003;

;

HDD #1 Specs:;
SN: WXH1A61D5480;
Model: WD5000BMVW-11AMCS0;
Date: 11 JUL 2011;
DCM: EA0TJCB ;
Product of: Malaysia;
PCB Sticker: 771737-300 ACD5;
PCB Revision: 2060-771737-000 REV A;

;
;
;
;

;

HDD with Serial Number: WXN1A6111691;
Model: WD5000BMVW-11AMCS0;
Date: 21 JUL 2011;
DCM: EACTJHB;
Product of: Malaysia;
PCB Sticker: 771737-300 AC;
PCB Revision: 2060-771737-000 REV A;

;

;
ROM F/W version……………………. : 0010000W;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0003;
;
;

;

HDD #1 Specs:;
SN: WXD1E70EE899;
Model: WD5000BMVW-11AMCS0;
Date: 14 FEB 2011;
DCM: EACVJBB ;
Product of: Thailand;
PCB Sticker: 771737-300 05P;
PCB Revision: 2060-771737-000 REV P1;

;

;

HDD #1 Specs:;
SN: WXM1E60VK389;
Model: WD5000BMVW-11AMCS0;
Date: 03 SEP 2010;
DCM: EACVJVBB ;
Product of: Thailand;
PCB Sticker: 771737-300 02P;
PCB Revision: 2060-771737-000 REV P1;

;
;
;

;

HDD with Serial Number: WXB1A87AFRNE;
Model: WD5000BMVW-11AJGS4;
Date: 12 SEP 2017;
DCM: HBNTJHB;
Product of: Malaysia;
PCB Sticker: 771961-S01 AD;
PCB Revision: 2060-771961-001 REV B;
;

ROM F/W version 00160094;
Heads map  0,1,2;
Preamp vendor: x001;
Preamp revision: x000;
Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : 00/0;
1   : 1   : 00/0;
2   : 2   : 00/0

;

HDD with Serial Number: WX31E51T3417;
Model: WD5000BMVW-11AMCS0;
Date: 17 JUL 2011;
DCM: EAOTJBB;
Product of: Malaysia;
PCB Sticker: 771737-300 AC;
PCB Revision: 2060-701737-000 REV A;

;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : A1A/2586;
1 : 1 : B3B/2875;
2 : 2 : A2C/2604;
3 : 3 : AAF/2735;

;

ROM F/W version……………………. : 0010000W;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0003;

;

HDD with Serial Number: WXW1A67C44EV;
Model: WD5000BMVW-11AJGS4;
Date: 08 SEP 2017;
DCM: HBNTJHN;
Product of: Malaysia;
PCB Sticker: 771961-S01 AD;
PCB Revision: 2060-771961-001 REV B;
;

ROM F/W version 00160094;
Heads map:  0,1,3;
Preamp vendor: x001;
Preamp revision: x000;
Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : 00/0;
1   : 1   : 00/0;
2   : 3   : 00/0

;
