Category: HDD

HDD with Serial Number: WX10AC9T7988;
Model: WD5000BEVT-22A0RT0;
Date: 23 DEC 2009;
DCM: HHCTJHB;
Product of: Malaysia;
PCB Sticker: 2061-771672-001 AE;
PCB Revision: 2060-771672-001 REV P1;
;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : 9F0/2544;
1   : 1   : A02/2562;
2   : 2   : 9E0/2528;
3   : 3   : A16/2582

;

HDD with Serial Number: WXD1EC0EF578;
Model: WD5000BEVT-22A0RT0;
Date: 22 FEB 2011;
DCM: EBOT2BB;
Product of: Malaysia;
PCB Sticker: 2061-771672-F04 AD;
PCB Revision: 2060-771672-004 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : A22/2594;
1 : 1 : A3E/2622;
2 : 2 : A2C/2604;
3 : 3 : A96/2710;

;

ROM F/W version: 0016000F;
Heads map: 0,1,2,3;
Preamp vendor: 0x0000;
Preamp revision: 0x0009;

;

HDD with Serial Number: WX60AC9D4130;
Model: WD5000BEVT-22A0RT0;
Date: 23 DEC 2009;
DCM: HHCTJHBB;
Product of: Thailand;
PCB Sticker: 2061-771674-001 AC;
PCB Revision: 2060-771672-001 REV P1;
;

——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : A4A/2634;
1   : 1   : 9F2/2546;
2   : 2   : 9FE/2558;
3   : 3   : 9DE/2526;
;
ROM F/W Version: 001300CC;
Heads map: 0,1,2,3;
Preamp vendor: 0x0001;
Preamp revision: 0x0003

;

HDD with Serial Number: WXL1E4026399;
Model: WD5000BEVT-22A0RT0;
Date: 05 JUN 2010;
DCM: EHCVJAB;
Product of: Malaysia;
PCB Sticker: 2061-771672-F04 AA;
PCB Revision: 2060-771672-004 REV A;
;

ROM F/W versionn 00140025;
Heads map:  0,1,2,3;
Preamp vendor: x001;
Preamp revision: x0003;
;
Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : B37/2871;
1   : 1   : B78/2936;
2   : 2   : B33/2867;
3   : 3   : B41/2881

;

HDD with Serial Number: WX80AB9H8972;
Model: WD5000BEVT-22A0RT0;
Date: 09 DEC 2009;
DCM: HHCVJBBB;
Product of: Thailand;
PCB Sticker: 2061-771672-001 AC;
PCB Revision: 2060-771672-001 REV P1;
;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : BD4/3028;
1   : 1   : BAC/2988;
2   : 2   : B9F/2975;
3   : 3   : B86/2950;
ROM F/W version……………………. : 001300CB;
Heads map…………………………. : 0,1,2,3;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0003;

;

HDD with Serial Number: WX81C90W5585;
Model: WD5000BEVT-22A0RT0;
Date: 24 OCT 2010;
DCM: EHNTJAN;
Product of: Malaysia;
PCB Sticker: 2061-771672-F04 AC;
PCB Revision: 2060-771672-004 REV A;
;

——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : A28/2600;
1   : 1   : A70/2672;
2   : 2   : A34/2612;
3   : 3   : A32/2610;
;
ROM F/W Version: 0014003R;
Heads map: 0,1,2,3;
Preamp vendor: 0x0001;
Preamp revision: 0x0003

;

HDD with Serial Number: WXH0AA9X5220;
Model: WD5000BEVT-22A0RT0;
Date: 02 DEC 2009;
DCM: HACTJBB;
Product of: Malaysia;
PCB Sticker: 2061-771672-001 AC;
PCB Revision: 2060-771672-001 REV P1;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : A52/2642;
1 : 1 : A32/2610;
2 : 2 : A50/2640;
3 : 3 : A4C/2636;
ROM F/W version……………………. : 001300CB;
Heads map…………………………. : 0,1,2,3;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0003;

HDD with Serial Number: WX10AC9W9669;
Model: WD5000BEVT-22A0RT0;
Date: 23 DEC 2009;
DCM: HACTJBB;
Product of: Malaysia;
PCB Sticker: 2061-771672-001 AE;
PCB Revision: 2060-771672-001 REV P1;
;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : A0C/2572;
1   : 1   : A04/2564;
2   : 2   : A42/2626;
3   : 3   : 9D6/2518

;

HDD with Serial Number: WX20AA9T2491;
Model: WD5000BEVT-22A0RT0;
Date: 17 NOV 2009;
DCM: HACTJHB;
Product of: Malaysia;
PCB Sticker: 2061-771672-001 AC;
PCB Revision: 2060-771672-001 REV P1;

;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : A6A/2666;
1 : 1 : 9DC/2524;
2 : 2 : A0A/2570;
3 : 3 : 9AE/2478;
ROM F/W version……………………. : 001300CA;
Heads map…………………………. : 0,1,2,3;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0003;

;

HDD with Serial Number: WXNX08LU1358;
Model: WD5000BEVT-00ZAT0;
Date: 14 APR 2009;
DCM: HHCVJHB;
Product of: Thailand;
PCB Sticker: 2061-701572-400 AA;
PCB Revision: 2060-701572-002 REV A;

;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : 923/2339;
1   : 1   : 920/2336;
2   : 2   : 940/2368;
3   : 3   : 979/2425;
ROM F/W version……………………. : 000600AT;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0002;
;
;
;
;

;

HDD with Serial Number: WXM1E11KLMS7;
Model: WD5000BEVT-16A0RT0;
Date: 09 JUL 2011;
DCM: DHOT2BB;
Product of: Malaysia;
PCB Sticker: 2061-771672-F04 ADD28;
PCB Revision: 2060-771672-004 REV A;
;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : A06/2566;
1   : 1   : 95A/2394;
2   : 2   : A04/2564;
3   : 3   : 982/2434;
ROM F/W version……………………. : 0016001D;
Heads map…………………………. : 0,1,2,3;
Preamp vendor……………………. : 0x0000;
Preamp revision………………….. : 0x0009;

;
