Category: HDD

HDD with Serial Number: WXQ1A6040081;
Model: WD5000BEKT-60KA9T0;
Date: 18 JUL 2010;
DCM: HBCTJBBB;
Product of: Thailand;
PCB Sticker: 2061-771714-002 02P;
PCB Revision: 2060-771714-002 REV P1;
Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : 9F1/2545;
1   : 1   : A22/2594;
2   : 2   : 9C3/2499;
3   : 3   : 9CB/2507;
ROM F/W version……………………. : 0016000M;
Heads map…………………………. : 0,1,2,3;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0003;
;
;

;

Specifications:;
Model WD5000BEKT-60KA9T0;
SN WXM1A50H5164;
Date 21 JUL 2010;
DCM HBCTJBNB;
Product of Thailand;
PCB Sticker: 2061-771714-002 02P;
PCB Revision: 2060-771714-002 REV P1;

;

HDD #1 Specs:;
SN: WXA1AA0S0748;
Model: WD5000BEKT-60KA9T0;
Date: 01 NOV 2010;
DCM: HBNTJABB ;
Product of: Thailand;
PCB Sticker: 2061-771714-002 AC;
PCB Revision: 2060-771714-002 REV P1;

;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : A23/2595;
1   : 1   : A17/2583;
2   : 2   : A15/2581;
3   : 3   : A0E/2574;
;
ROM F/W version……………………. : 00160010;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0003;

;

HDD with Serial Number: WX31A70K7987;
Model: WD5000BEKT-60KA9T0;
Date: 01 AUG 2010;
DCM: HBNTJANB;
Product of: Thailand;
PCB Sticker: 2061-771714-002 02P;
PCB Revision: 2060-771714-002 REV P1;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 9B7/2487;
1 : 1 : A0B/2571;
2 : 2 : 9B3/2483;
3 : 3 : A56/2646;
ROM F/W version……………………. : 0016000P;
Heads map…………………………. : 0,1,2,3;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0003;

;

HDD with Serial Number: WXF1A51H1085;
Model: WD5000BEKT-60KA9T0;
Date: 27 JUN 2011;
DCM: HHCTJABB;
Product of: Thailand;
PCB Sticker: 771714-002 ACD24;
PCB Revision: 2060-771714-002 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : A44/2628;
1 : 1 : A5C/2652;
2 : 2 : A2A/2602;
3 : 3 : A73/2675;
ROM F/W version……………………. : 00160016;
Heads map…………………………. : 0,1,2,3;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0003;

HDD with Serial Number: WX71A41X7870;
Model: WD5000BEKT-60KA9T0;
Date: 20 JUN 2011;
DCM: HHCTJABB;
Product of: Thailand;
PCB Sticker: 771714-002 AC;
PCB Revision: 2060-771714-002 REV A;
;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : A11/2577;
1   : 1   : A89/2697;
2   : 2   : A3E/2622;
3   : 3   : A89/2697;
ROM F/W version……………………. : 00160016;
Heads map…………………………. : 0,1,2,3;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0003;

;

HDD with Serial Number: WX71A21C2237;
Model: WD5000BEKT-60KA9T0;
Date: 10 MAR 2011;
DCM: HHNTJABB;
Product of: Thailand;
PCB Sticker: 2061-771714-002 AC;
PCB Revision: 2060-771714-002 REV P1;

;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : AB0/2736;
1 : 1 : A95/2709;
2 : 2 : A48/2632;
3 : 3 : A41/2625;
ROM F/W version……………………. : 00160015?;
Heads map…………………………. : 0,1,2,3;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0003;

;

HDD with Serial Number: WXJ1AB069661;
Model: WD5000BEKT-60KA9T0;
Date: 11 DEC 2010;
DCM: HHNTJABB;
Product of: Thailand;
PCB Sticker: 2061-771714-002 AC;
PCB Revision: 2060-771714-002 REV P1;

;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : A7D/2685;
1 : 1 : AAE/2734;
2 : 2 : A73/2675;
3 : 3 : AB9/2745;

;

ROM F/W version: 00160015;
Heads map: 0,1,2,3;
Preamp vendor: 0x0001;
Preamp revision: 0x0003;

;

HDD with Serial Number: WX71A21C0610;
Model: WD5000BEKT-60KA9T0;
Date: 10 MAR 2011;
DCM: HHNTJBBB;
Product of: Thailand;
PCB Sticker: 2061-771714-002 AC;
PCB Revision: 2060-771714-002 REV P1;
;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : A58/2648;
1   : 1   : A0C/2572;
2   : 2   : A68/2664;
3   : 3   : 9F0/2544;
ROM F/W version……………………. : 00160015;
Heads map…………………………. : 0,1,2,3;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0003;

;

HDD with Serial Number: WX31A11D1286;
Model: WD5000BEKT-00KA9T0;
Date: 13 APR 2011;
DCM: HHCTJABB;
Product of: Thailand;
PCB Sticker: 771714-002 AC;
PCB Revision: 2060-771714-002 REV P1;
;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : A05/2565;
1   : 1   : A8A/2698;
2   : 2   : 9F0/2544;
3   : 3   : AB9/2745;
ROM F/W version……………………. : 00160016;
Heads map…………………………. : 0,1,2,3;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0003;

;

HDD with Serial Number: WX81C70C9279;
Model: WD5000BEKT-75KA9T0;
Date: 21 DEC 2010;
DCM: EANTJABB;
Product of: Thailand;
PCB Sticker: 2061-771714-002 AC;
PCB Revision: 2060-771714-002 REV P1;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : A79/2681;
1 : 1 : A98/2712;
2 : 2 : A5E/2654;
3 : 3 : A9A/2714;
ROM F/W version……………………. : 00160015;
Heads map…………………………. : 0,1,2,3;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0003;

;

HDD with Serial Number: WXR1AC0E1024;
Model: WD5000BEKT-00KA9T0;
Date: 18 APR 2011;
DCM: HHNTJABB;
Product of: Thailand;
PCB Sticker: 771714-002 AC;
PCB Revision: 2060-771714-002 REV P1;
;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : A8E/2702;
1   : 1   : A06/2566;
2   : 2   : ACC/2764;
3   : 3   : 9EB/2539;
ROM F/W version……………………. : 00160016;
Heads map…………………………. : 0,1,2,3;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0003;

;
