Category: HDD

HDD with Serial Number: WXA1AA0N7683;
Model: WD800BEVE-00A0HT0;
Date: 08 NOV 2010;
DCM: HHYT2BNB;
Product of: Thailand;
PCB Sticker: 2061-701532-000 AL;
PCB Revision: 2060-701532-000 REV A;

;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 1   : 940/2368;
Preamp vendor……………………… : 0x0002;
Preamp revision……………………. : 0x0001;
ROM F/W version……………………. : 0000000M;
;
;
;
;
;

;

HDD with Serial Number: WXH1E30CM504;
Model: WD800BEVE-00A0HT0;
Date: 27 JUN 2010;
DCM: DANT2ANB;
Product of: Thailand;
PCB Sticker: 2061-701532-000 AL;
PCB Revision: 2060-701532-000 REV A;
;

;

HDD with Serial Number: WXH708659151;
Model: WD800BEVE-00UYT0;
Date: 02 AUG 2008;
DCM: DAYTJANB;
Product of: Thailand;
PCB Sticker: 2061-701510-000 AD;
PCB Revision: 2060-701510-000 REV A;

;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 994/2452;
1 : 1 : 988/2440;
ROM F/W version……………………. : 0001008P;
Preamp vendor……………………… : 0x0004;
Preamp revision……………………. : 0x0001;

;

HDD with Serial Number: WXE1E10EJ428;
Model: WD800BEVE-00A0HT0;
Date: 11 MAR 2010;
DCM: DBNT2BBB;
Product of: Thailand;
PCB Sticker: 2061-701532-000 AL;
PCB Revision: 2060-701532-000 REV A;
;

;

HDD with Serial Number: WXHY08479745;
Model: WD800BEVE-00UYT0;
Date: 15 JAN 2009;
DCM: DAYTJHBB;
Product of: Thailand;
PCB Sticker: 2061-701510-000 AF;
PCB Revision: 2060-701510-000 REV A;
;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : 9B4/2484;
1   : 1   : 9A4/2468;
ROM F/W version……………………. : 0001008P;
Heads map…………………………. : 0,1;
Preamp vendor……………………. : 0x0004;
Preamp revision………………….. : 0x0001;

;

HDD with Serial Number: WXS1E20UT599;
Model: WD800BEVE-00A0HT0;
Date: 27 APR 2010;
DCM: DBNTJHNB;
Product of: Thailand;
PCB Sticker: 2061-701532-000 AL;
PCB Revision: 2060-701532-000 REV A;
;

;

Specifications:;
Model WD800BEVE-00UYT0;
SN WXR0E69FEY08;
DATE 09 SEP 2009;
DCM FACTJHBB;
Product of Thailand;
PCB Sticker: 2061-701510-000 AG;
PCB Revision: 2060-701510-000 REV A;

;

HDD with Serial Number: WMAM9H967050;
Model: WD800BD-22LRA0;
Date: 18 NOV 2005;
DCM: HSBHNTJCH;
Product of: Malaysia;
PCB Sticker: 2061-701335-000 AG;
PCB Revision: 2060-701335-003 REV B;

;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : 44E/1102;
1   : 1   : 454/1108;

;

ROM F/W version……………………. : 06BTD;
Preamp Vendor……………………… : 0001;
Preamp Rev………………………… : 0004;

;

HDD with Serial Number: WXM1E40FE057;
Model: WD800BEVE-00A0HT0;
Date: 17 OCT 2010;
DCM: DBYT2ABB;
Product of: Thailand;
PCB Sticker: 2061-701532-000 AL;
PCB Revision: 2060-701532-000 REV A;
;

;

HDD with Serial Number: WXC408K78143;
Model: WD800BEVE-00UYT0;
Date: 14 MAY 2008;
DCM: FANTJBBB;
Product of: Thailand;
PCB Sticker: 2061-701510-000 AD;
PCB Revision: 2060-701510-000 REV A;

;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 93A/2362;
1 : 1 : 924/2340;

;

ROM F/W version……………………. : 0001008P;
Preamp vendor……………………… : 0x0004;
Preamp revision……………………. : 0x0001;

;
