Category: HDD

HDD with Serial Number: WCC2EAV98143;
Model: WD5000AAKX-08ERMA0;
Date: 24 MAR 2013;
DCM: EBRNHT2MHB;
Product of: Thailand;
PCB Sticker: 2061-771640-103 AH;
PCB Revision: 2060-771640-003 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : AFF/2815;
1 : 1 : A34/2612;
ROM F/W version……………………. : 0005000K;
Heads map…………………………. : 0,1;
Preamp vendor……………………. : 0x0000;
Preamp revision………………….. : 0x0005;

;

HDD with Serial Number: WCC2EHS74329;
Model: WD5000AAKX-08ERMA0;
Date: 16 JUN 2013;
DCM: EGNNKTJMGB;
Product of: Thailand;
PCB Sticker: 771640-103 AJ;
PCB Revision: 2060-771640-003 REV A;
;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : B1F/2847;
1   : 1   : A70/2672;
ROM F/W version……………………. : 0005000U;
Heads map…………………………. : 0,1;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0001;

;

HDD with Serial Number: WCC2EAV69107;
Model: WD5000AAKX-08ERMA0;
Date: 24 MAR 2013;
DCM: EGRNHTJMHB;
Product of: Thailand;
PCB Sticker: 2061-771640-103 AH;
PCB Revision: 2060-771640-003 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : AAF/2735;
1 : 1 : A20/2592;
ROM F/W version……………………. : 0005000K;
Heads map…………………………. : 0,1;
Preamp vendor…………………… : 0x0001;
Preamp revision…………………. : 0x0001;

;

HDD with Serial Number: WMAYUX726005;
Model: WD5000AAKX-083CA1;
Date: 14 JUN 2012;
DCM: HHRNNT2CH;
Product of: Malaysia;
PCB Sticker: 2061-771640-S13 AD;
PCB Revision: 2060-771640-003 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : D1F/3359;
1 : 1 : D80/3456;
ROM F/W version……………………. : 00030036;
Heads map…………………………. : 0,1;
Preamp vendor……………………. : 0x0000;
Preamp revision………………….. : 0x0005;

HDD with Serial Number: WMAYUY357099;
Model: WD5000AAKX-083CA1;
Date: 13 JUN 2012;
DCM: HHRNNT2CH;
Product of: Malaysia;
PCB Sticker: 2061-771640-S13 AD;
PCB Revision: 2060-771640-003 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : CCB/3275;
1 : 1 : CF7/3319;
ROM F/W version……………………. : 00030036;
Heads map…………………………. : 0,1;
Preamp vendor……………………. : 0x0000;
Preamp revision………………….. : 0x0005;

;

HDD with Serial Number: WCC2EH868094;
Model: WD5000AAKX-08ERMA0;
Date: 23 OCT 2012;
DCM: EHRNKT2CHB;
Product of: Thailand;
PCB Sticker: 2061-771640-103 AA;
PCB Revision: 2060-771640-003 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : DD0/3536;
1 : 1 : D80/3456;
ROM F/W version……………………. : 00050003;
Heads map…………………………. : 0,1;
Preamp vendor……………………. : 0x0000;
Preamp revision………………….. : 0x0005;

;

HDD with Serial Number: WMAYUS030268;
Model: WD5000AAKX-083CA1;
Date: 15 APR 2012;
DCM: HHRNNV2CH;
Product of: Malaysia;
PCB Sticker: 2061-771640-S13 AD;
PCB Revision: 2060-771640-003 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : BD8/3032;
1 : 1 : B81/2945;

;

ROM F/W version: 00030036;
Preamp vendor: 0x0000;
Preamp revision: 0x0005;

;

HDD with Serial Number: WCC2ED189038;
Model: WD5000AAKX-08ERMA0;
Date: 07 SEP 2012;
DCM: HARNHTJMHB;
Product of: Thailand;
PCB Sticker: 2061-771640-103 AA;
PCB Revision: 2060-771640-003 REV A;

;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : CA5/3237;
1   : 1   : CE1/3297;
ROM F/W version……………………. : 00050003;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0001;
;
;
;
;

;

HDD with Serial Number: WMAYU9514112;
Model: WD5000AAKX-083CA1;
Date: 27 DEC 2011;
DCM: HHRNNVJCH;
Product of: Malaysia;
PCB Sticker: 2061-771640-S13 AC;
PCB Revision: 2060-771640-003 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : BC5/3013;
1 : 1 : BC4/3012;
ROM F/W version……………………. : 0003002T;
Heads map…………………………. : 0,1;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0001;

;

HDD #1 Specs:;
Serial Number: WCC2EH515922;
Model: WD5000AAKX-08ERMA0;
Date: 21 OCT 2012;
DCM: HARNKT2CGB;
Product of: Thailand;
PCB Sticker: 2061-771640-103 AC;
PCB Revision: 2060-771640-003 REV A;

;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : D20/3360;
1   : 1   : D2F/3375;
Preamp Vendor……………………… : 0000;
Preamp Rev………………………… : 0005;
ROM F/W version……………………. : 00050009;
;
;
;
;
;

;

HDD with Serial Number: WCC2E5FK8J0F;
Model: WD5000AAKX-08ANVA0;
Date: 08 OCT 2015;
DCM: HANNKTJCHB;
Product of: Thailand;
PCB Sticker: 771640-113 AA;
PCB Revision: 2060-771640-003 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : B65/2917;
1 : 1 : BA0/2976;
ROM F/W version……………………. : 00050044;
Heads map…………………………. : 0,1;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0001;

;
