Category: HDD

HDD with Serial Number: WCAS81782177;
Model: WD5000AAKS-75YGA0;
Date: 14 OCT 2007;
DCM: HANCHT2AAB;
Product of: Thailand;
PCB Sticker: 2061-701477-900 AB;
PCB Revision: 2060-701477-002 REV A;

;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 2   : A20/2592;
1   : 3   : A4C/2636;
2   : 4   : 9E0/2528;
3   : 5   : A2C/2604;
4   : 6   : 9AE/2478;
5   : 7   : A34/2612;
ROM F/W version……………………. : 00580076;
Preamp vendor……………………… : 0x0000;
Preamp revision……………………. : 0x0002;
;
;
;
;

;

HDD with Serial Number: WCAPW1945148;
Model: WD5000AAKS-75TMA0;
Date: 03 MAY 2007;
DCM: HHRCHV2CHB;
Product of: Thailand;
PCB Sticker: 2061-701477-800 AC;
PCB Revision: 2060-701477-001 REV A;

;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 2   : 656/1622;
1   : 3   : 64E/1614;
2   : 4   : 662/1634;
3   : 5   : 684/1668;
4   : 6   : 67A/1658;
5   : 7   : 66C/1644;
ROM F/W version……………………. : 0011008P;
Preamp vendor……………………… : 0x0000;
Preamp revision……………………. : 0x0001;
;
;
;
;

;

HDD with Serial Number: WCAWF7759340;
Model: WD5000AAKS-75V0A0;
Date: 31 AUG 2010;
DCM: DANNNTJCHN;
Product of: Thailand;
PCB Sticker: 2061-701640-L02 AB;
PCB Revision: 2060-701640-002 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : C62/3170;
1 : 1 : C86/3206;
ROM F/W version……………………. : 00120024;
Heads map…………………………. : 0,1;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0001;

;

HDD with Serial Number: WCAWFC586761;
Model: WD5000AAKS-75V0A0;
Date: 22 FEB 2011;
DCM: DARNNTJAAN;
Product of: Thailand;
PCB Sticker: 2061-771640-L03 AD;
PCB Revision: 2060-771640-003 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : C1D/3101;
1 : 1 : D48/3400;
ROM F/W version……………………. : 0012004G;
Heads map…………………………. : 0,1;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0001;

;

HDD with Serial Number: WCAWFD368305;
Model: WD5000AAKS-75V0A0;
Date: 20 MAR 2011;
DCM: DARNNTJAGN;
Product of: Thailand;
PCB Sticker: 2061-771640-L03 AD;
PCB Revision: 2060-771640-003 REV A;

;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : C7F/3199;
1 : 1 : D10/3344;

;

ROM F/W version……………………. : 00120064;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0001;

;

HDD with Serial Number: WCAWF7707475;
Model: WD5000AAKS-75V0A0;
Date: 23 AUG 2010;
DCM: DGRNNTJMHN;
Product of: Thailand;
PCB Sticker: 2061-701640-L02 AB;
PCB Revision: 2060-701640-002 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : B72/2930;
1 : 1 : CAF/3247;
ROM F/W version……………………. : 00120024;
Heads map…………………………. : 0,1;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0001;

;

HDD with Serial Number: WCAWF0245851;
Model: WD5000AAKS-75V0A0;
Date: 15 DEC 2009;
DCM: HARCHTJMHN;
Product of: Thailand;
PCB Sticker: 2061-701640-K02 05PD2;
PCB Revision: 2060-701640-002 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : C7A/3194;
1 : 1 : C90/3216;
ROM F/W version……………………. : 00110054;
Heads map…………………………. : 0,1;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0001;

HDD with Serial Number: WCAWF0417526;
Model: WD5000AAKS-75V0A0;
Date: 17 DEC 2009;
DCM: HARCHTJMHN;
Product of: Thailand;
PCB Sticker: 2061-701640-K02 05PD2;
PCB Revision: 2060-701640-002 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : CB5/3253;
1 : 1 : BF1/3057;

;

ROM F/W version:00110054;
Preamp vendor:0x0001;
Preamp revision:0x0001;

;

HDD with Serial Number: WMAWF1313188;
Model: WD5000AAKS-75V0A0;
Date: 16 NOV 2009;
DCM: HARNHTJAA;
Product of: Malaysia;
PCB Sticker: 2061-701640-202 04PD1;
PCB Revision: 2060-701640-002 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : D7F/3455;
1 : 1 : C3F/3135;
ROM F/W version……………………. : 0011003G;
Heads map…………………………. : 0,1;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0001;

;

HDD #1 Specs:;
Serial Number: WCAS82974648;
Model: WD5000AAKS-65YGA0;
Date: 07 DEC 2007;
DCM: HHRNHT2AHB;
Product of: Thailand;
PCB Sticker: 2061-701444-700 AD;
PCB Revision: 2060-701444-004 REV A;

;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 2   : 9F8/2552;
1   : 3   : A16/2582;
2   : 4   : A18/2584;
3   : 5   : A0E/2574;
4   : 6   : 9EE/2542;
5   : 7   : A2C/2604;
ROM F/W version……………………. : 0058007M;
Preamp vendor……………………… : 0x0000;
Preamp revision……………………. : 0x0002;
;
;
;
;
;
;

;

HDD with Serial Number: WMASY1158377;
Model: WD5000AAKS-75A7B0;
Date: 23 APR 2008;
DCM: HBRNNV2CA;
Product of: Malaysia;
PCB Sticker: 2061-701537-E00 04P;
PCB Revision: 2060-701537-003 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 8B9/2233;
1 : 1 : 8BD/2237;
2 : 2 : 884/2180;
3 : 3 : 8A7/2215;
ROM F/W version……………………. : 00050041;
Heads map…………………………. : 0,1,2,3;
Preamp vendor……………………. : 0x0000;
Preamp revision………………….. : 0x0002;

;
