HDD with Serial Number: WCAT00068234;
Model: WD5000AAKS-65A7B2;
Date: 29 APR 2009;
DCM: HGRNNT2MAB;
Product of: Thailand;
PCB Sticker: 2061-701590-L00 AD;
PCB Revision: 2060-701590-000 REV A;
;
Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : A52/2642;
1 : 1 : 9CE/2510;
2 : 2 : A58/2648;
ROM F/W version……………………. : 000500BU;
Heads map…………………………. : 0,1,2;
Preamp vendor……………………. : 0x0000;
Preamp revision………………….. : 0x0002;
;
HDD with Serial Number: WCAPW0650357;
Model: WD5000AAKS-65TMA0;
Date: 15 MAR 2007;
DCM: HBNCHV2AAB;
Product of: Thailand;
PCB Sticker: 2061-701477-800 AB;
PCB Revision: 2060-701477-001 REV A;
;
Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 2 : 670/1648;
1 : 3 : 67E/1662;
2 : 4 : 664/1636;
3 : 5 : 6A8/1704;
4 : 6 : 65E/1630;
5 : 7 : 67C/1660;
ROM F/W version……………………. : 0011008P;
Heads map…………………………. : 2,3,4,5,6,7;
Preamp vendor……………………. : 0x0000;
Preamp revision………………….. : 0x0001;
;
HDD with Serial Number: WCASY0947024;
Model: WD5000AAKS-65A7B0;
Date: 10 JUN 2008;
DCM: HHNNHT2CHB;
Product of: Thailand;
PCB Sticker: 2061-701537-E00 07P;
PCB Revision: 2060-701537-003 REV A;
;
Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 9A5/2469;
1 : 1 : AA0/2720;
2 : 2 : 99E/2462;
3 : 3 : AC1/2753;
;
ROM F/W version: 00050060;
Preamp vendor:0x0000;
Preamp revision:0x0002;
;
HDD #1 Specs:;
Serial Number: WCAT00108509;
Model: WD5000AAKS-65A7B2;
Date: 21 MAY 2009;
DCM: HHNNHT2MGB;
Product of: Thailand;
PCB Sticker: 2061-701590-L00 AD;
PCB Revision: 2060-701590-000 REV A;
;
Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 992/2450;
1 : 1 : A14/2580;
2 : 2 : 9C2/2498;
ROM F/W version……………………. : 000500BU;
Preamp vendor……………………… : 0x0000;
Preamp revision……………………. : 0x0002;
;
;
;
;
;
HDD #1 Specs:;
SN: WCAPW1030637;
Model: WD5000AAKS-65TMA0;
Date: 20 APR 2007;
DCM: HBNCHV2CAB ;
Product of: Thailand;
PCB Sticker: 2061-701477-800 AC;
PCB Revision: 2060-701477-001 REV A;
;
Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 2 : 69C/1692;
1 : 3 : 686/1670;
2 : 4 : 69C/1692;
3 : 5 : 68E/1678;
4 : 6 : 6A2/1698;
5 : 7 : 6A4/1700;
ROM F/W version……………………. : 0011008P;
Preamp vendor……………………… : 0x0000;
Preamp revision……………………. : 0x0001;
;
;
HDD with Serial Number: WCASY0924728;
Model: WD5000AAKS-65A7B0;
Date: 09 JUN 2008;
DCM: HHNNNT2CHB;
Product of: Thailand;
PCB Sticker: 2061-701537-E00 07P;
PCB Revision: 2060-701537-003 REV A;
;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : A42/2626;
1 : 1 : ABA/2746;
2 : 2 : A5F/2655;
3 : 3 : A9D/2717;
;
ROM F/W Version: 01.03B01;
Heads map: 0,1,2,3;
Preamp vendor: 0x0000;
Preamp revision: 0x0002
;
HDD with Serial Number: WCAT00412999;
Model: WD5000AAKS-65A7B2;
Date: 09 SEP 2009;
DCM: HHNNHT2MGN;
Product of: Thailand;
PCB Sticker: 2061-701590-L00 AD;
PCB Revision: 2060-701590-000 REV A;
;
Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 9AC/2476;
1 : 1 : A44/2628;
2 : 2 : 9B0/2480;
ROM F/W version……………………. : 000500CT;
Preamp vendor……………………… : 0x0000;
Preamp revision……………………. : 0x0002;
;
;
;
;
;
HDD #1 Specs:;
SN: WCAPW1004247;
Model: WD5000AAKS-65TMA0;
Date: 18 APR 2007;
DCM: HBNCNV2CAB ;
Product of: Thailand;
PCB Sticker: 2061-701477-800 AC;
PCB Revision: 2060-701477-001 REV A;
;
Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 2 : 6D8/1752;
1 : 3 : 6B2/1714;
2 : 4 : 6DE/1758;
3 : 5 : 6E4/1764;
4 : 6 : 6B4/1716;
5 : 7 : 6BE/1726;
;
;
;
HDD with Serial Number: WCAWFC202422;
Model: WD5000AAKS-60Z1A0;
Date: 24 JAN 2011;
DCM: DGRNNTJAAN;
Product of: Thailand;
PCB Sticker: 2061-771640-L03 AC;
PCB Revision: 2060-771640-003 REV A;
;
Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : CF0/3312;
1 : 1 : CFF/3327;
;
ROM F/W version:00120024;
Preamp vendor:0x0001;
Preamp revision:0x0001;
;
;
HDD with Serial Number: WCAWF8840807;
Model: WD5000AAKS-60Z1A0;
Date: 03 OCT 2010;
DCM: DHRNNTJAHN;
Product of: Thailand;
PCB Sticker: 2061-771640-L03 02P;
PCB Revision: 2060-771640-003 REV P1;
Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : BF9/3065;
1 : 1 : C58/3160;
ROM F/W version……………………. : 00120024;
Heads map…………………………. : 0,1;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0001;
;
