Category: HDD

HDD with Serial Number: WCAS87796026;
Model: WD5000AAKS-40YGA1;
Date: 24 JUN 2008;
DCM: HHRNHT2CHB;
Product of: Thailand;
PCB Sticker: 2061-701477-900 AGD10;
PCB Revision: 2060-701477-002 REV A;

;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 2   : A94/2708;
1   : 3   : AC0/2752;
2   : 4   : A60/2656;
3   : 5   : ADE/2782;
4   : 6   : A6E/2670;
5   : 7   : AC4/2756;
ROM F/W version……………………. : 005800AF;
Preamp vendor……………………… : 0x0000;
Preamp revision……………………. : 0x0002;
;
;
;
;

;

HDD with Serial Number: WCAS88602377;
Model: WD5000AAKS-40YGA1;
Date: 30 NOV 2008;
DCM: DHNNHT2MHB;
Product of: Thailand;
PCB Sticker: 2061-701477-900 AGD10;
PCB Revision: 2060-701477-002 REV A;
;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 2   : 9F4/2548;
1   : 3   : 9D4/2516;
2   : 4   : 9E0/2528;
3   : 5   : 9EE/2542;
4   : 6   : 9F0/2544;
5   : 7   : 9E6/2534;
ROM F/W version……………………. : 005800BF;
Heads map…………………………. : 2,3,4,5,6,7;
Preamp vendor……………………. : 0x0000;
Preamp revision………………….. : 0x0002;

;

HDD with Serial Number: WCAS88233088;
Model: WD5000AAKS-40YGA1;
Date: 09 AUG 2008;
DCM: HANNHT2CAB;
Product of: Thailand;
PCB Sticker: 2061-701477-900 AGD10;
PCB Revision: 2060-701477-002 REV A;
;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 2   : A6E/2670;
1   : 3   : 9CE/2510;
2   : 4   : A6A/2666;
3   : 5   : A92/2706;
4   : 6   : A7C/2684;
5   : 7   : A2A/2602;
ROM F/W version……………………. : 005800B5;
Heads map…………………………. : 2,3,4,5,6,7;
Preamp vendor……………………. : 0x0000;
Preamp revision………………….. : 0x0002;
;
;
;

;

HDD with Serial Number: WCAS88539703;
Model: WD5000AAKS-40YGA1;
Date: 28 OCT 2008;
DCM: HANNHT2MAB;
Product of: Thailand;
PCB Sticker: 2061-701477-900 AG;
PCB Revision: 2060-701477-002 REV A;
;

;

Specifications;
SN: WCAS88335530;
Model: WD5000AAKS-40YGA1;
Date: 26 AUG 2008;
DCM: HANNHT2MBB ;
Product of: Thailand;
PCB Sticker: 2061-701477-900 AGD10;
PCB Revision: 2060-701477-002 REV A;

;

;

HDD with Serial Number: WCAS88581580;
Model: WD5000AAKS-40YGA1;
Date: 22 NOV 2008;
DCM: HANNNT2MBB;
Product of: Thailand;
PCB Sticker: 2061-701477-900 AGD10;
PCB Revision: 2060-701477-002 REV A;
;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 2   : A6C/2668;
1   : 3   : A28/2600;
2   : 4   : A6E/2670;
3   : 5   : A1C/2588;
4   : 6   : A7E/2686;
5   : 7   : A3C/2620;
ROM F/W version……………………. : 005800BF;
Heads map…………………………. : 2,3,4,5,6,7;
Preamp vendor……………………. : 0x0000;
Preamp revision………………….. : 0x0002;

;

HDD with Serial Number: WCAS87261629;
Model: WD5000AAKS-40YGA1;
Date: 01 MAY 2008;
DCM: HARNNT2MAN;
Product of: Thailand;
PCB Sticker: 2061-701477-900 AE;
PCB Revision: 2060-701477-002 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 2 : A66/2662;
1 : 3 : A50/2640;
2 : 4 : A62/2658;
3 : 5 : A4A/2634;
4 : 6 : A5E/2654;
5 : 7 : A58/2648;
ROM F/W version……………………. : 005800AF;
Heads map…………………………. : 2,3,4,5,6,7;
Preamp vendor……………………. : 0x0000;
Preamp revision………………….. : 0x0002;

;

HDD with Serial Number: WCAS87942034;
Model: WD5000AAKS-40YGA1;
Date: 08 JUL 2008;
DCM: HBNNHT2CBB;
Product of: Thailand;
PCB Sticker: 2061-701477-900 AE;
PCB Revision: 2060-701477-002 REV A;

;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 2 : A64/2660;
1 : 3 : AA8/2728;
2 : 4 : A56/2646;
3 : 5 : A9C/2716;
4 : 6 : A46/2630;
5 : 7 : A9A/2714;

;

ROM F/W version……………………. : 005800AF;
Preamp vendor……………………… : 0x0000;
Preamp revision……………………. : 0x0002;

;

HDD with Serial Number: WCAS83855504;
Model: WD5000AAKS-40YGA0;
Date: 18 DEC 2007;
DCM: HARCHT2MBB;
Product of: Thailand;
PCB Sticker: 2061-701477-900 AD;
PCB Revision: 2060-701477-002 REV A;

;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 2   : A90/2704;
1   : 3   : A04/2564;
2   : 4   : A88/2696;
3   : 5   : A0C/2572;
4   : 6   : A7C/2684;
5   : 7   : A12/2578;
ROM F/W version……………………. : 0058007R;
Preamp vendor……………………… : 0x0000;
Preamp revision……………………. : 0x0002;
;
;
;
;

;

HDD with Serial Number: WCAWFA051579;
Model: WD5000AAKS-40V6A0;
Date: 16 NOV 2010;
DCM: HGNNNTJAAN;
Product of: Thailand;
PCB Sticker: 771640-102 05P;
PCB Revision: 2060-771640-002 REV A;
;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : C6B/3179;
1   : 1   : CD9/3289;
ROM F/W version……………………. : 0000004T;
Heads map…………………………. : 0,1;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0001;
;
;
;

;
