Category: HDD

HDD with Serial Number: WCAT00448033;
Model: WD5000AAKS-40V2B0;
Date: 20 SEP 2009;
DCM: HGNNHT2MBB;
Product of: Thailand;
PCB Sticker: 2061-771668-000 03P;
PCB Revision: 2060-771668-000 REV P1;
;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : A66/2662;
1   : 1   : 9AC/2476;
2   : 2   : 9D8/2520;
ROM F/W version……………………. : 0007000H;
Heads map…………………………. : 0,1,2;
Preamp vendor……………………. : 0x0000;
Preamp revision………………….. : 0x0002;

;

HDD #1 Specs:;
Serial Number: WCAWF4799988;
Model: WD5000AAKS-40V6A0;
Date: 30 APR 2010;
DCM: HBRNHTJAHN;
Product of: Thailand;
PCB Revision: 2060-771640-002 REV P2;

;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : C6D/3181;
1   : 1   : C9B/3227;
;
;

;

HDD #1 Specs:;
SN: WCAPW5192395;
Model: WD5000AAKS-40TMA0;
Date: 12 OCT 2007;
DCM: HBNCNV2AAB ;
Product of: Thailand;
PCB Sticker: 2061-701477-900 AB;
PCB Revision: 2060-701477-002 REV A;

;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 2 : 620/1568;
1 : 3 : 668/1640;
2 : 4 : 612/1554;
3 : 5 : 680/1664;
4 : 6 : 63A/1594;
5 : 7 : 68C/1676;

;

ROM F/W version……………………. : 0021007N;
Preamp vendor……………………… : 0x0000;
Preamp revision……………………. : 0x0001;

;

HDD with Serial Number: WCASZ0856891;
Model: WD5000AAKS-40V2B0;
Date: 07 FEB 2010;
DCM: HGRNHT2MAB;
Product of: Thailand;
PCB Sticker: 2061-771668-100 AB;
PCB Revision: 2060-771668-000 REV P1;
;

——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : 944/2372;
1   : 1   : A10/2576;
2   : 3   : A0E/2574;
;
ROM F/W Version: 0007000H;
Heads map: 0,1,3;
Preamp vendor: 0x0000;
Preamp revision: 0x0002

;

HDD with Serial Number: WCAWFC793892;
Model: WD5000AAKS-40V6A0;
Date: 06 MAR 2011;
DCM: HCRNNTJACN;
Product of: Thailand;
PCB Sticker: 771640-102 07P;
PCB Revision: 2060-771640-002 REV A;
;

ROM F/W version 0000004T;
Heads map:   0,1;
Preamp vendor: 0x0001;
Preamp revision: 0x0001;
;
Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : C87/3207;
1   : 1   : C44/3140

;

HDD with Serial Number: WCAPW5434699;
Model: WD5000AAKS-40TMA0;
Date: 16 OCT 2007;
DCM: HBNCNV2ABB;
Product of: Thailand;
PCB Sticker: 2061-701477-900 AB;
PCB Revision: 2060-701477-002 REV A;
;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 2   : 65C/1628;
1   : 3   : 670/1648;
2   : 4   : 660/1632;
3   : 5   : 654/1620;
4   : 6   : 62E/1582;
5   : 7   : 628/1576;
ROM F/W version……………………. : 0021007N;
Heads map…………………………. : 2,3,4,5,6,7;
Preamp vendor……………………. : 0x0000;
Preamp revision………………….. : 0x0001;
;
;

;

HDD with Serial Number: WCAT00427326;
Model: WD5000AAKS-40V2B0;
Date: 12 SEP 2009;
DCM: HGRNHT2MGB;
Product of: Thailand;
PCB Sticker: 2061-771668-000 03P;
PCB Revision: 2060-771668-000 REV P1;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 9E2/2530;
1 : 1 : A0A/2570;
2 : 2 : A06/2566;
ROM F/W version……………………. : 0007000H;
Heads map…………………………. : 0,1,2;
Preamp vendor……………………… : 0x0000;
Preamp revision……………………. : 0x0002;

;

HDD with Serial Number: WCAWFC318275;
Model: WD5000AAKS-40V6A0;
Date: 03 FEB 2011;
DCM: HGNNHTJAGN;
Product of: Thailand;
PCB Sticker: 771640-102 05P;
PCB Revision: 2060-771640-002 REV P2;
;

;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : BC7/3015;
1 : 1 : C4B/3147;

;

ROM F/W version: 0000004T;
Heads map: 0,1;
Preamp vendor: 0x0001;
Preamp revision: 0x0001;

;

HDD with  Serial Number: WCAWFC828699;
Model: WD5000AAKS-402AA0;
Date: 01 MAR 2011;
DCM: HGRNHTJCHN;
Product of: Thailand;
PCB Sticker: 771640-105 02PD1;
PCB Revision: 2060-771640-005 REV P1;

;

;

HDD with Serial Number: WCAWFC803729;
Model: WD5000AAKS-402AA0;
Date: 04 MAR 2011;
DCM: HGRNNTJAGN;
Product of: Thailand;
PCB Sticker: 771640-105 02PD1;
PCB Revision: 2060-771640-005 REV P1;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : C7C/3196;
1 : 1 : D4E/3406;

ROM F/W version……………………. : 00000070;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0001;

HDD with Serial Number: WCAWFC671960;
Model: WD5000AAKS-402AA0;
Date: 05 MAR 2011;
DCM: HGRNNTJAGN;
Product of: Thailand;
PCB Sticker: 771640-105 02PD1;
PCB Revision: 2060-771640-005 REV P1;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : C94/3220;
1 : 1 : D06/3334;

ROM F/W version……………………. : 00000070;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0001;

;
