Category: HDD

HDD with Serial Number: WCAPW5743536;
Model: WD5000AAKS-40TMA0;
Date: 06 DEC 2007;
DCM: DBNCHV2CBB;
Product of: Thailand;
PCB Sticker: 2061-701477-900 AD;
PCB Revision: 2060-701477-002 REV A;
;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 2   : 70C/1804;
1   : 3   : 662/1634;
2   : 4   : 6C8/1736;
3   : 5   : 666/1638;
4   : 6   : 70A/1802;
5   : 7   : 674/1652;
ROM F/W version……………………. : 0021007N;
Heads map…………………………. : 2,3,4,5,6,7;
Preamp vendor……………………. : 0x0000;
Preamp revision…………………. : 0x0002;
;
;
;

;

HDD #1 Specs:;
Serial Number: WCAWFC915431;
Model: WD5000AAKS-402AA0;
Date: 07 MAR 2011;
DCM: HCNNHTJAGN;
Product of: Thailand;
PCB Sticker: 771640-105 02PD1;
PCB Revision: 2060-771640-005 REV P1;

;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : C97/3223;
1   : 1   : C55/3157;
Preamp Vendor……………………… : 0001;
Preamp Rev………………………… : 0001;
;
;
;

;

HDD with Serial Number: WCAWFC845130;
Model: WD5000AAKS-402AA0;
Date: 06 MAR 2011;
DCM: HCNNHTJAHN;
Product of: Thailand;
PCB Sticker: 771640-105 02PD1;
PCB Revision: 2060-771640-005 REV P1;

;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : BC8/3016;
1 : 1 : D16/3350;

;

ROM F/W version……………………. : 00000070;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0001;

;

HDD #1 Specs:;
Serial Number: WCAWFE183196;
Model: WD5000AAKS-402AA0;
Date: 11 SEP 2011;
DCM: HCRNHTJACN;
Product of: Thailand;
PCB Sticker: 771640-105 AC;
PCB Revision: 2060-771640-005 REV P1;

;

;
Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : B93/2963;
1   : 1   : C01/3073;
;
;

;

HDD with Serial Number: WCAWFC856227;
Model: WD5000AAKS-402AA0;
Date: 06 MAR 2011;
DCM: HCRNHTJAGN;
Product of: Thailand;
PCB Sticker: 771640-105 02PD1;
PCB Revision: 2060-771640-005 REV P1;

;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : C8A/3210;
1 : 1 : C8C/3212;

;

ROM F/W version……………………. : 00000070;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0001;

;

HDD with Serial Number: WCAWFE303341;
Model: WD5000AAKS-402AA0;
Date: 09 OCT 2011;
DCM: HGNNHTJAGN;
Product of: Thailand;
PCB Sticker: 771640-105 AC;
PCB Revision: 2060-771640-005 REV A;

;

HDD with Serial Number: WCAWFC756301;
Model: WD5000AAKS-402AA0;
Date: 01 MAR 2011;
DCM: HGNNNTJCGN;
Product of: Thailand;
PCB Sticker: 771640-105 02PD1;
PCB Revision: 2060-771640-005 REV P1;
;
Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : D76/3446;
1 : 1 : D30/3376;
;
ROM F/W version……………………. : 00000070;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0001;

;

HDD with Serial Number: WCAWFE303990;
Model: WD5000AAKS-402AA0;
Date: 08 OCT 2011;
DCM: HGRNHTJAGN;
Product of: Thailand;
PCB Sticker: 771640-105 AC;
PCB Revision: 2060-771640-005 REV A;

;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : BCF/3023;
1 : 1 : B76/2934;
ROM F/W version……………………. : 00000070;
Heads map…………………………. : 0,1;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0001

;

HDD with Serial Number: WMASY4944730;
Model: WD5000AAKS-22A7B2;
Date: 18 NOV 2008;
DCM: HANNNT2CA;
Product of: Malaysia;
PCB Sticker: 2061-701590-L00 AA;
PCB Revision: 2060-701590-000 REV A;

;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : ABC/2748;
1 : 1 : A50/2640;
2 : 2 : A28/2600;
3 : 3 : A00/2560;

;

ROM F/W version……………………. : 000500AP;
Preamp vendor……………………… : 0x0000;
Preamp revision……………………. : 0x0002;

HDD with Serial Number: WMASY4942244;
Model: WD5000AAKS-22A7B2;
Date: 18 NOV 2008;
DCM: HANNNT2CA;
Product of: Malaysia;
PCB Sticker: 2061-701590-L00 AA;
PCB Revision: 2060-701590-000 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : A06/2566;
1 : 1 : AE4/2788;
2 : 2 : A10/2576;
3 : 3 : AD2/2770;

;

ROM F/W: 000500AP;
Heads map: 0,1,2,3;
Preamp vendor: 0x0000;
Preamp revision: 0x0002;

;

HDD with Serial Number: WCAPW1973676;
Model: WD5000AAKS-22TMA0;
Date: 01 MAY 2007;
DCM: HANCHV2CBB;
Product of: Thailand;
PCB Sticker: 2061-701477-800 AC;
PCB Revision: 2060-701477-001 REV A;

;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 2   : 656/1622;
1   : 3   : 66C/1644;
2   : 4   : 66C/1644;
3   : 5   : 674/1652;
4   : 6   : 650/1616;
5   : 7   : 6B4/1716;

;

ROM F/W version……………………. : 0011008P;
Preamp Vendor……………………… : 0000;
Preamp Rev………………………… : 0001;

;
