Category: HDD

HDD with Serial Number: WCAWF7832145;
Model: WD5000AAKS-08V0A0;
Date: 02 SEP 2010;
DCM: HGNNHTJCHN;
Product of: Thailand;
PCB Sticker: 2061-701640-L02 AB;
PCB Revision: 2060-701640-002 REV A;

;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : C3B/3131;
1   : 1   : CDE/3294;
ROM F/W version……………………. : 00120024;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0001;
;
;
;
;

;

HDD with Serial Number: WCAWF4131721;
Model: WD5000AAKS-08V0A0;
Date: 21 MAR 2010;
DCM: HGRCHTJCAN;
Product of: Thailand;
PCB Sticker: 2061-701640-L02 02PD3;
PCB Revision: 2060-701640-002 REV A;

;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : D63/3427;
1   : 1   : CF8/3320;
ROM F/W version……………………. : 00120016;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0001;
;
;
;
;

;

HDD with Serial Number: WCAWFD188203;
Model: WD5000AAKS-08V0A0;
Date: 13 APR 2011;
DCM: HHNNHTJAHN;
Product of: Thailand;
PCB Sticker: 2061-771640-L03 AD;
PCB Revision: 2060-771640-003 REV A;

;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : C0A/3082;
1   : 1   : C92/3218;
ROM F/W version……………………. : 00120064;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0001;
;
;
;
;

;

HDD #1 Specs:;
SN: WCAT00144275;
Model: WD5000AAKS-08A7B2;
Date: 10 JUN 2009;
DCM: HANNNT2MAB ;
Product of: Thailand;
PCB Sticker: 2061-701590-L00;
PCB Revision: 2060-701590-000;

;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : A54/2644;
1   : 1   : A14/2580;
2   : 2   : A52/2642;
ROM F/W version……………………. : 000500CT;
Preamp vendor……………………… : 0x0000;
Preamp revision……………………. : 0x0002;
;
;
;
;
;
;

;

HDD with Serial Number: WCAWF7832649;
Model: WD5000AAKS-08V0A0;
Date: 02 SEP 2010;
DCM: HHNNHTJCHN;
Product of: Thailand;
PCB Sticker: 2061-701640-L02 AB;
PCB Revision: 2060-701640-002 REV A;

;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : CCA/3274;
1   : 1   : C8B/3211;
ROM F/W version……………………. : 00120024;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0001;
;
;
;
;

;

HDD with Serial Number: WCASZ0910540;
Model: WD5000AAKS-08A7B2;
Date: 02 MAR 2010;
DCM: HANNNT2MGN;
Product of: Thailand;
PCB Sticker: 2061-701590-L01 04P;
PCB Revision: 2060-701590-001 REV A;

;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 9E2/2530;
1 : 1 : 9E2/2530;
2 : 3 : A04/2564;

;

ROM F/W version……………………. : 000500DG;
Preamp vendor……………………… : 0x0000;
Preamp revision……………………. : 0x0002;

;

HDD with Serial Number: WCAWF5875726;
Model: WD5000AAKS-08V0A0;
Date: 05 JUN 2010;
DCM: HHRNHTJAHN;
Product of: Thailand;
PCB Sticker: 2061-701640-L02 03P;
PCB Revision: 2060-701640-002 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : CD1/3281;
1 : 1 : C2F/3119;
ROM F/W version……………………. : 0012001R;
Heads map…………………………. : 0,1;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0001;

;

HDD #1 Specs:;
SN: WCASZ0336560;
Model: WD5000AAKS-08A7B2;
Date: 10 JUN 2009;
DCM: HARNNT2CAB ;
Product of: Thailand;
PCB Sticker: 2061-701590-L00 AD;
PCB Revision: 2060-701590-000 REV A;

;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : 9C8/2504;
1   : 1   : 9FC/2556;
2   : 3   : 9E8/2536;
;

;

ROM F/W version……………………. : 000500CT;
Preamp vendor……………………… : 0x0000;
Preamp revision……………………. : 0x0002;

;

HDD with Serial Number: WCAYUX617864;
Model: WD5000AAKS-08WWPA0;
Date: 24 JUN 2011;
DCM: DGRNNTJMHN;
Product of: Thailand;
PCB Sticker: 2061-771640-S13 AA;
PCB Revision: 2060-771640-003 REV A;

;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : C0B/3083;
1 : 1 : C57/3159;

;

ROM F/W version……………………. : 00030010;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0001;

;

HDD #1 Specs:;
SN: WCASZ0334690;
Model: WD5000AAKS-08A7B2;
Date: 10 JUN 2009;
DCM: HARNNT2MAB ;
Product of: Thailand;
PCB Sticker: 2061-701590-L00 AD;
PCB Revision: 2060-701590-000 REV A;

;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : 9E2/2530;
1   : 1   : A0E/2574;
2   : 3   : A18/2584;

;

ROM F/W version……………………. : 000500CT;
Preamp vendor……………………… : 0x0000;
Preamp revision……………………. : 0x0002;

;
