Category: HDD

Specifications;
SN: WCAWFA123728;
Model: WD5000AAKS-00V0A0;
Date: 18 NOV 2010;
DCM: HGNNNTJAAN ;
Product of: Thailand;
PCB Sticker: 2061-771640-L03 AB;
PCB Revision: 2060-771640-003 REV P1;

;

;

HDD with Serial Number: WCASZ0591397;
Model: WD5000AAKS-00V2B0;
Date: 06 OCT 2009;
DCM: HBNNHT2MBN;
Product of: Thailand;
PCB Sticker: 2061-771668-000 03P;
PCB Revision: 2060-771668-000 REV P1;

;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 9FE/2558;
1 : 1 : A16/2582;
2 : 3 : A30/2608;

;

ROM F/W version……………………. : 0007000H;
Preamp vendor……………………… : 0x0000;
Preamp revision……………………. : 0x0002;

;

HDD with Serial Number: WCAWF0387553;
Model: WD5000AAKS-00V0A0;
Date: 01 JUN 2011;
DCM: HGRCHTJMG;
Product of: Thailand;
PCB Sticker: 2061-701640-K02 05PD4;
PCB Revision: 2060-701640-002 rev a;

;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : CB8/3256;
1 : 1 : C77/3191;

;

ROM F/W version……………………. : 00110058;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0001;

;

HDD #1 Specs:;
SN: WCAT00330472;
Model: WD5000AAKS-00V2B0;
Date: 21 SEP 2009;
DCM: HGNNHT2MBB ;
Product of: Thailand;
PCB Sticker: 2061-771668-000 03P;
PCB Revision: 2060-771668-000 REV P1;

;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : 9BA/2490;
1   : 1   : 9D4/2516;
2   : 2   : 9B0/2480;
;
;

;

HDD with Serial Number: WCAWFC934225;
Model: WD5000AAKS-00V0A0;
Date: 16 MAR 2011;
DCM: HGRNNTJAGN;
Product of: Thailand;
PCB Sticker: 2061-771640-L03 AD;
PCB Revision: 2060-771640-003 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : C4B/3147;
1 : 1 : CA6/3238;
ROM F/W version……………………. : 0012004G;
Heads map…………………………. : 0,1;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0001;

;

HDD #1 Specs:;
SN: WCASZ0848027;
Model: WD5000AAKS-00V2B0;
Date: 14 MAY 2010;
DCM: HHNNNT2MBB ;
Product of: Thailand;
PCB Sticker: 2061-771668-100 AB;
PCB Revision: 2060-771668-000 REV P1;

;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : 9D6/2518;
1   : 1   : 9E0/2528;
2   : 3   : 9EA/2538;
ROM F/W version……………………. : 0007000H;
Preamp vendor……………………… : 0x0000;
Preamp revision……………………. : 0x0002;
;
;
;
;
;
;

;

HDD with Serial Number: WCAWF1405022;
Model: WD5000AAKS-00V1A0;
Date: 14 JAN 2010;
DCM: HANNHTJAAN;
Product of: Thailand;
PCB Sticker: 2061-701640-K02 05PD6;
PCB Revision: 2060-701640-002 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : BAC/2988;
1 : 1 : D47/3399;
ROM F/W version……………………. : 00110058;
Heads map…………………………. : 0,1;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0001;

;

HDD #1 Specs:;
Serial Number: WCAWFC854944;
Model: WD5000AAKS-00V6A0;
Date: 06 MAR 2011;
DCM: HHRNNTJACN;
Product of: Thailand;
PCB Sticker: 771640-105 02PD1;
PCB Revision: 2060-771640-005 REV P1;

Micro Jogs
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;

;

;

HDD with Serial Number: WCAYU8710519;
Model: WD5000AAKS-00UU3A0;
Date: 07 DEC 2010;
DCM: HBNNHTJMHN;
Product of: Thailand;
PCB Sticker: 2061-771640-503 ABD10;
PCB Revision: 2060-771640-003 REV P1;

;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : C31/3121;
1   : 1   : CCC/3276;
ROM F/W version……………………. : 00000026;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0001;
;
;
;
;

;

HDD with Serial Number: WCAWF1993012;
Model: WD5000AAKS-00V1A0;
Date: 24 JAN 2010;
DCM: HBRNHTJMGN;
Product of: Thailand;
PCB Sticker: 2061-701640-K02 05PD6;
PCB Revision: 2060-701640-002 REV A;

;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : BE8/3048;
1   : 1   : C3D/3133;
ROM F/W version……………………. : 00110058;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0001;
;
;
;
;

;
