Category: HDD

HDD with Serial Number: WCAYU7994352;
Model: WD5000AAKS-00UU3A0;
Date: 04 NOV 2010;
DCM: DBRNHTJMGN;
Product of: Thailand;
PCB Sticker: 2061-771640-503 AB;
PCB Revision: 2060-771640-003 REV P1;

;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : CCC/3276;
1 : 1 : CBB/3259;

;

ROM F/W version……………………. : 00000022;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0001;

;

HDD with Serial Number: WCAYUJ807469;
Model: WD5000AAKS-00UU3A0;
Date: 11 MAR 2011;
DCM: DGNNHT2AHN;
Product of: Thailand;
PCB Sticker: 2061-771640-S03 04P;
PCB Revision: 2060-771640-003 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : C35/3125;
1 : 1 : C8E/3214;
ROM F/W version……………………. : 0003000C;
Heads map…………………………. : 0,1;
Preamp vendor……………………. : 0x0000;
Preamp revision………………….. : 0x0004;

;

HDD with Serial Number: WCAYU5743505;
Model: WD5000AAKS-00UU3A0;
Date: 25 JUL 2010;
DCM: DGNNHTJMGN;
Product of: Thailand;
PCB Sticker: 2061-701640-V02 AA;
PCB Revision: 2060-701640-002 REV A;
Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : C77/3191;
1 : 1 : C91/3217;
ROM F/W version……………………. : 0000001G;
Heads map…………………………. : 0,1;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0001;

;

HDD with Serial Number: WCAYUF613135;
Model: WD5000AAKS-00UU3A0;
Date: 09 FEB 2011;
DCM: DGNNHTJMHN;
Product of: Thailand;
PCB Sticker: 2061-771640-S03 03P;
PCB Revision: 2060-771640-003 REV A;
;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : BCF/3023;
1   : 1   : C49/3145;
;
ROM F/W version……………………. : 00000026;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0001;

;

HDD with Serial Number: WCAYU6716567;
Model: WD5000AAKS-00UU3A0;
Date: 15 AUG 2010;
DCM: DGRNHTJMHN;
Product of: Thailand;
PCB Sticker: 2061-701640-V02 AA;
PCB Revision: 2060-701640-002 REV A;

;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : C19/3097;
1 : 1 : C35/3125;

;

ROM F/W version……………………. : 0000001G;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0001;

;

HDD with Serial Number: WCAYU8000487;
Model: WD5000AAKS-00UU3A0;
Date: 04 NOV 2010;
DCM: EBRNHTJAGN;
Product of: Thailand;
PCB Sticker: 2061-771640-503 AB;
PCB Revision: 2060-771640-003 REV P1;

;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : CB0/3248;
1   : 1   : C5F/3167;
ROM F/W version……………………. : 00000022;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0001;
;
;
;
;

;

HDD with Serial Number: WCAYUH121694;
Model: WD5000AAKS-00UU3A0;
Date: 16 FEB 2011;
DCM: EGNNHT2AHN;
Product of: Thailand;
PCB Sticker: 2061-771640-S03 04P;
PCB Revision: 2060-771640-003 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : C39/3129;
1 : 1 : CC3/3267;
ROM F/W version……………………. : 00000026;
Heads map…………………………. : 0,1;
Preamp vendor……………………… : 0x0000;
Preamp revision……………………. : 0x0004;

;

HDD with Serial Number: WCAYU7966446;
Model: WD5000AAKS-00UU3A0;
Date: 04 NOV 2010;
DCM: EGRNHTJAHN;
Product of: Thailand;
PCB Sticker: 2061-771640-503 AB;
PCB Revision: 2060-771640-003 REV P1;

;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : C66/3174;
1   : 1   : D07/3335;
ROM F/W version……………………. : 00000022;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0001;
;
;
;
;

;

HDD with Serial Number: WCASY2459646;
Model: WD5000AAKS-00D2B0;
Date: 02 OCT 2008;
DCM: DGRNNV2MGB;
Product of: Thailand;
PCB Sticker: 2061-701537-U00 05PD1;
PCB Revision: 2060-701537-004 REV A;
;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : 8C1/2241;
1   : 1   : 8F0/2288;
2   : 2   : 8E0/2272;
3   : 3   : 975/2421;
ROM F/W version……………………. : 00050054;
Heads map…………………………. : 0,1,2,3;
Preamp vendor……………………. : 0x0000;
Preamp revision………………….. : 0x0002;

;

HDD with Serial Number: WCATR6244234;
Model: WD5000AAKS-00E4A0;
Date: 07 MAR 2011;
DCM: HARNHTJAAB;
Product of: Thailand;
PCB Sticker: 2061-771640-K03 AC;
PCB Revision: 2060-771640-003 REV A;
Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 2   : C47/3143;
1   : 3   : CD0/3280;
ROM F/W version……………………. : 0001005M;
Heads map…………………………. : 2,3;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0001;
;
;
;
;

;
