Category: HDD

WD5000AAKS-00D2B0, DCM HHRNHTJMH, Western Digital 500GB SATA 3.5 Hard Drive

HDD with Serial Number: WMASY4728401;
Model: WD5000AAKS-00D2B0;
Date: 10 NOV 2008;
DCM: HHRNHTJMH;
Product of: Malaysia;
PCB Sticker: 2061-701537-U00 05PD1;
PCB Revision: 2060-701537-004 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 9DC/2524;
1 : 1 : A04/2564;
2 : 2 : 9EB/2539;
3 : 3 : 9F0/2544;
ROM F/W version……………………. : 00050054;
Heads map…………………………. : 0,1,2,3;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0001;

;

WD5000AAKS-00M9A0, DCM HHNCHTJAH, Western Digital 500GB SATA 3.5 Hard Drive

HDD with Serial Number: WMAVC0167581;
Model: WD5000AAKS-00M9A0;
Date: 30 JUL 2009;
DCM: HHNCHTJAH;
Product of: Malaysia;
PCB Sticker: 2061-701640-F00 03P;
PCB Revision: 2060-701640-000 REV P1;

;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : C0F/3087;
1 : 1 : CF1/3313;

;

ROM F/W version……………………. : 0010001J;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0001;

;

HDD with Serial Number: WMAVC0323784;

;

Model: WD5000AAKS-00M9A0;
Date: 28 AUG 2009;
DCM: HHNCHTJAH;
Product of: Malaysia;
PCB Sticker: 2061-701640-W00 04P;
PCB Revision: 2060-701640-001 REV A;

;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : C8C/3212;
1   : 1   : C72/3186;

;

ROM F/W version……………………. : 0010002M;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0001;
;
;
;
;

;

WD5000AAKS-00D2B0, DCM DBRNHT2MHN, Western Digital 500GB SATA 3.5 Hard Drive

HDD with Serial Number: WCASY2463515;
Model: WD5000AAKS-00D2B0;
Date: 03 OCT 2008;
DCM: DBRNHT2MHN;
Product of: Thailand;
PCB Sticker: 2061-701537-U00 10PD1;
PCB Revision: 2060-701537-004 REV A;
;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : A59/2649;
1   : 1   : A6B/2667;
2   : 2   : 9FC/2556;
3   : 3   : 9BA/2490;
ROM F/W version……………………. : 00050054;
Heads map…………………………. : 0,1,2,3;
Preamp vendor……………………. : 0x0000;
Preamp revision………………….. : 0x0002;

;

WD5000AAKS-00D2B0, DCM HHRNNT2MHN, Western Digital 500GB SATA 3.5 Hard Drive

HDD with Serial Number: WCASY2309212;
Model: WD5000AAKS-00D2B0;
Date: 03 OCT 2008;
DCM: HHRNNT2MHN;
Product of: Thailand;
PCB Sticker: 2061-701537-U00 05PD1;
PCB Revision: 2060-701537-004 REV A;
;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : A08/2568;
1   : 1   : A7D/2685;
2   : 2   : 9F7/2551;
3   : 3   : 9AA/2474;
ROM F/W version……………………. : 00050054;
Heads map…………………………. : 0,1,2,3;
Preamp vendor……………………. : 0x0000;
Preamp revision………………….. : 0x0002;

;

WD5000AAKS-00M9A0, DCM HHNCNTJAA, Western Digital 500GB SATA 3.5 Hard Drive

HDD with Serial Number: WMAVC0253053;
Model: WD5000AAKS-00M9A0;
Date: 03 AUG 2009;
DCM: HHNCNTJAA;
Product of: Malaysia;
PCB Sticker: 2061-701640-F00 03P;
PCB Revision: 2060-701640-000 REV P1;

;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : C9C/3228;
1   : 1   : CC3/3267;
ROM F/W version……………………. : 0010001J;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0001;
;
;
;
;

;

WD5000AAKS-00D2B0, DCM DGRNHT2MHB, Western Digital 500GB SATA 3.5 Hard Drive

HDD with Serial Number: WCASY2504796;
Model: WD5000AAKS-00D2B0;
Date: 02 OCT 2008;
DCM: DGRNHT2MHB;
Product of: Thailand;
PCB Sticker: 2061-701537-U00 05PD1;
PCB Revision: 2060-701537-004 REV A;
;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : A0B/2571;
1   : 1   : A11/2577;
2   : 2   : A01/2561;
3   : 3   : 9C8/2504;
ROM F/W version……………………. : 00050054;
Heads map…………………………. : 0,1,2,3;
Preamp vendor……………………. : 0x0000;
Preamp revision………………….. : 0x0002;

;

WD5000AAKS-00E4A0, DCM EBNNHTJCBB, Western Digital 500GB SATA 3.5 Hard Drive

Specifications;
SN: WCATR6232940;
Model: WD5000AAKS-00E4A0;
Date: 03 MAR 2011;
DCM: EBNNHTJCBB ;
Product of: Thailand;
PCB Sticker: 2061-771640-303 ABD2;
PCB Revision: 2060-771640-003 REV A;

;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : C54/3156;
1   : 2   : C5F/3167;
2   : 3   : C8C/3212;
ROM F/W version……………………. : 0001003C;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0001;
;
;
;
;
;

;

WD5000AAKS-00A7B2, DCM HBRNHT2CH, Western Digital 500GB SATA 3.5 Hard Drive

HDD with Serial Number: WMASY3667853;
Model: WD5000AAKS-00A7B2;
Date: 24 SEP 2008;
DCM: HBRNHT2CH;
Product of: Malaysia;
PCB Sticker: 2061-701590-L00 01P;
PCB Revision: 2060-701590-000 REV A;
;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : A10/2576;
1   : 1   : A1E/2590;
2   : 2   : 9F6/2550;
3   : 3   : A0E/2574;
ROM F/W version……………………. : 000500AM;
Heads map…………………………. : 0,1,2,3;
Preamp vendor……………………. : 0x0000;
Preamp revision………………….. : 0x0002;
;
;
;

;

WD5000AAKS-00A7B2, DCM HHRNNTJMGN, Western Digital 500GB SATA 3.5 Hard Drive

HDD with Serial Number: WCASY3106812;
Model: WD5000AAKS-00A7B2;
Date: 20 NOV 2008;
DCM: HHRNNTJMGN;
Product of: Thailand;
PCB Sticker: 2061-701590-L00 01P;
PCB Revision: 2060-701590-000 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 9F0/2544;
1 : 1 : 9F6/2550;
2 : 2 : 9B2/2482;
3 : 3 : A32/2610;
ROM F/W version……………………. : 000500AP;
Heads map…………………………. : 0,1,2,3;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0001;

;
