Category: HDD

HDD with Serial Number: WMASY5905855;
Model: WD5000AAKS-00A7B2;
Date: 05 JAN 2009;
DCM: EANNNTJCA;
Product of: Malaysia;
PCB Sticker: 2061-701590-L00 AC;
PCB Revision: 2060-701590-000 REV A;

;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : A44/2628;
1 : 1 : A58/2648;
2 : 2 : A5E/2654;
3 : 3 : A40/2624;

;

ROM F/W version……………………. : 000500AP;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0001;

HDD with Serial Number: WMASY5898803;
Model: WD5000AAKS-00A7B2;
Date: 02 JAN 2009;
DCM: EANNNTJCA;
Product of: Malaysia;
PCB Sticker: 2061-701590-L00 AC;
PCB Revision: 2060-701590-000 REV A;
;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : 9DA/2522;
1   : 1   : A66/2662;
2   : 2   : A02/2562;
3   : 3   : A5A/2650;
ROM F/W version……………………. : 000500AP;
Heads map…………………………. : 0,1,2,3;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0001;

;

HDD with Serial Number: WCASZ0003666;
Model: WD5000AAKS-00A7B2;
Date: 21 JAN 2009;
DCM: EARNHT2MHB;
Product of: Thailand;
PCB Sticker: 2061-701590-L00 AC;
PCB Revision: 2060-701590-000 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : A26/2598;
1 : 1 : 9D0/2512;
2 : 3 : 988/2440;
ROM F/W version……………………. : 000500AP;
Heads map…………………………. : 0,1,3;
Preamp vendor…………………… : 0x0000;
Preamp revision…………………. : 0x0002;

;

HDD #1 Specs:;
SN: WMASY5752919;
Model: WD5000AAKS-00A7B0;
Date: 31 DEC 2008;
DCM: HARNHVJCB ;
Product of: Malaysia;
PCB Sticker: 2061-771577-900 03P;
PCB Revision: 2060-771577-001 REV A;

;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 8D4/2260;
1 : 1 : 8D0/2256;
2 : 2 : 8C4/2244;
3 : 3 : 88A/2186;

;

ROM F/W version……………………. : 000500AP;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0001;

;

HDD with Serial Number: WMASY5360992;
Model: WD5000AAKS-00A7B2;
Date: 13 OCT 2010;
DCM: EBRNHTJCA;
Product of: Malaysia;
PCB Sticker: 2061-701590-L00 AC;
PCB Revision: 2060-701590-000 REV A;
;

;

HDD with Serial Number: WMASY5163071;
Model: WD5000AAKS-00A7B0;
Date: 23 NOV 2008;
DCM: HBNNHT2CH;
Product of: Malaysia;
PCB Sticker: 2061-701537-E00 07PD3;
PCB Revision: 2060-701537-003 REV A;

;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : 9DA/2522;
1   : 1   : 9FC/2556;
2   : 2   : A0A/2570;
3   : 3   : 9EA/2538;
ROM F/W version……………………. : 000500AP;
Preamp vendor……………………… : 0x0000;
Preamp revision……………………. : 0x0002;
;
;
;
;

;

HDD with Serial Number: WCASY6679276;
Model: WD5000AAKS-00A7B2;
Date: 11 AUG 2009;
DCM: EGNNNT2CAN;
Product of: Thailand;
PCB Sticker: 2061-701590-L00 AD;
PCB Revision: 2060-701590-000 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : A26/2598;
1 : 2 : 9EA/2538;
2 : 3 : 9B0/2480;
ROM F/W version……………………. : 000500CT;
Heads map…………………………. : 0,2,3;
Preamp vendor……………………. : 0x0000;
Preamp revision………………….. : 0x0002;

;

HDD with Serial Number: WMASY0128397;
Model: WD5000AAKS-00A7B0;
Date: 20 FEB 2008;
DCM: HBNNNV2CA;
Product of: Malaysia;
PCB Sticker: 2061-701537-E00 02P;
PCB Revision: 2060-701537-003 REV A;

;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : 8DF/2271;
1   : 1   : 901/2305;
2   : 2   : 90E/2318;
3   : 3   : 8B9/2233;
ROM F/W version……………………. : 00020035;
Preamp vendor……………………… : 0x0000;
Preamp revision……………………. : 0x0002;
;
;
;
;

;

HDD with Serial Number: WCASY3167269;
Model: WD5000AAKS-00A7B2;
Date: 01 DEC 2008;
DCM: EHRNHTJMHB;
Product of: Thailand;
PCB Sticker: 2061-701590-L00 01P;
PCB Revision: 2060-701590-000 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 9D6/2518;
1 : 1 : A1A/2586;
2 : 2 : 9BE/2494;
3 : 3 : 9F0/2544;
ROM F/W version……………………. : 000500AP;
Heads map…………………………. : 0,1,2,3;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0001;

;

HDD with Serial Number: WCAPW3190833;
Model: WD5000AAKB-00UKA0;
Date: 01 JUL 2007;
DCM: HHRCHV2CHN;
Product of: Thailand;
PCB Sticker: 2061-701508-900 AA;
PCB Revision: 2060-701508-001 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 2 : 65A/1626;
1 : 3 : 68C/1676;
2 : 4 : 6E8/1768;
3 : 5 : 694/1684;
4 : 6 : 69A/1690;
5 : 7 : 69C/1692;
ROM F/W version……………………. : 00210023;
Heads map…………………………. : 2,3,4,5,6,7;
Preamp vendor……………………… : 0x0000;
Preamp revision……………………. : 0x0001;

;

HDD with Serial Number: WCATR2176412;
Model: WD5000AAKS-007AA0;
Date: 23 JUL 2010;
DCM: HBRNHTJABB;
Product of: Thailand;
PCB Sticker: 771640-202 06P;
PCB Revision: 2060-771640-002 REV P2;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : CFB/3323;
1 : 1 : C8B/3211;
2 : 2 : CD2/3282;
ROM F/W version……………………. : 0000004T;
Heads map…………………………. : 0,1,2;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0001;

;
