HDD #1 Specs:;
Serial Number: WCASY6954507;
Model: WD5000AAKB-00H8A0;
Date: 18 AUG 2009;
DCM: DANNNT2MHN;
Product of: Thailand;
PCB Sticker: 2061-701596-500 09P;
PCB Revision: 2060-701596-001 REV P1;
;
Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : A0E/2574;
1 : 1 : A04/2564;
2 : 2 : 9EC/2540;
3 : 3 : A16/2582;
;
ROM F/W version……………………. : 000500BT;
Preamp vendor……………………… : 0x0000;
Preamp revision……………………. : 0x0002;
;
Specifications:;
SN WCAT00941349;
Model WD5000AAKB-00H8A0;
Date 02 MAY 2010;
DCM EGNNNHT2MGB
DCX 4004H0281;
Product of Thailand;
PCB Sticker: 2061-701596-500 10P;
PCB Revision: 2060-701596-001 REV P1;
;
;
HDD #1 Specs:;
SN: WCASY4695782;
Model: WD5000AAKB-00H8A0;
Date: 22 MAR 2009;
DCM: DBRNHV2CHB ;
Product of: Thailand;
PCB Sticker: 2061-701596-500 09P;
PCB Revision: 2060-701596-001 REV A;
;
;
Specifications;
SN: WCASYD539394;
Model: WD5000AAKB-00H8A0;
Date: 04 JUN 2010;
DCM: EHNNHT2MAB ;
Product of: Thailand;
PCB Sticker: 2061-701596-500 10P;
PCB Revision: 2060-701596-001 REV P1;
;
;
HDD with Serial Number: WCASY6284458;
Model: WD5000AAKB-00H8A0;
Date: 14 JUL 2009;
DCM: DHNNHT2MAB;
Product of: Thailand;
PCB Sticker: 2061-701596-500 09P;
PCB Revision: 2060-701596-001 REV P1;
;
Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : A3E/2622;
1 : 1 : A32/2610;
2 : 2 : A38/2616;
3 : 3 : A26/2598;
;
ROM F/W version……………………. : 000500BT;
Preamp vendor……………………… : 0x0000;
Preamp revision……………………. : 0x0002;
;
HDD with Serial Number: WCASY9394608;
Model: WD5000AAKB-00H8A0;
Date: 06 DEC 2009;
DCM: EHNNNT2MAN;
Product of: Thailand;
PCB Sticker: 2061-701596-500 10P;
PCB Revision: 2060-701596-001 REV P1;
;
Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 9D0/2512;
1 : 1 : 9EA/2538;
2 : 2 : 9CA/2506;
3 : 3 : A0E/2574;
ROM F/W version……………………. : 000500DB;
Heads map…………………………. : 0,1,2,3;
Preamp vendor……………………. : 0x0000;
Preamp revision………………….. : 0x0002;
;
HDD with Serial Number: WCASZ0790510;
Model: WD5000AAKB-00H8A0;
Date: 20 JAN 2010;
DCM: DHNNHT2MGN;
Product of: Thailand;
PCB Sticker: 2061-701596-500 10P;
PCB Revision: 2060-701596-001 REV P1;
;
Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : A02/2562;
1 : 1 : 9E8/2536;
2 : 3 : 9E6/2534;
;
ROM F/W version……………………. : 000500DB;
Preamp vendor……………………… : 0x0000;
Preamp revision……………………. : 0x0002;
;
HDD #1 Specs:;
SN: WCASY3291562;
Model: WD5000AAKB-00H8A0;
Date: 11 DEC 2008;
DCM: EHRNNTJMHB ;
Product of: Thailand;
PCB Sticker: 2061-701596-500 06P;
PCB Revision: 2060-701596-001 REV P1;
;
;
HDD with Serial Number: WCAPW3769866;
Model: WD5000AAJS-57TKA0;
Date: 19 JUL 2007;
DCM: HHNCNV2CHB;
Product of: Thailand;
PCB Sticker: 2061-701477-100 04P;
PCB Revision: 2060-701477-002 REV A;
;
Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 2 : 656/1622;
1 : 3 : 664/1636;
2 : 4 : 648/1608;
3 : 5 : 650/1616;
4 : 6 : 674/1652;
5 : 7 : 666/1638;
ROM F/W version……………………. : 0011008P;
Heads map…………………………. : 2,3,4,5,6,7;
Preamp vendor……………………… : 0x0000;
Preamp revision……………………. : 0x0001;
HDD with Serial Number: WCAPW3433432;
Model: WD5000AAJS-57TKA0;
Date: 16 JUL 2007;
DCM: HHNCNV2CHB;
Product of: Thailand;
PCB Sticker: 2061-701477-100 05P;
PCB Revision: 2060-701477-002 REV A;
;
Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 2 : 6C6/1734;
1 : 3 : 692/1682;
2 : 4 : 6C4/1732;
3 : 5 : 67A/1658;
4 : 6 : 6D2/1746;
5 : 7 : 66E/1646;
ROM F/W version……………………. : 0011008P;
Heads map…………………………. : 2,3,4,5,6,7;
Preamp vendor……………………. : 0x0000;
Preamp revision………………….. : 0x0001;
;
HDD with Serial Number: WCASYA861941;
Model: WD5000AAKB-00H8A0;
Date: 02 MAR 2010;
DCM: DHNNHT2MHN;
Product of: Thailand;
PCB Sticker: 2061-701596-500 10P;
PCB Revision: 2060-701596-001 REV P1;
;
Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : A02/2562;
1 : 1 : 9D4/2516;
2 : 2 : 9E6/2534;
3 : 3 : A84/2692;
ROM F/W version……………………. : 000500DB;
Preamp vendor……………………… : 0x0000;
Preamp revision……………………. : 0x0002;
;
;
;
;
;
