Category: HDD

HDD with Serial Number: WCAS80868334;
Model: WD5000AAJS-22YFA0;
Date: 12 SEP 2007;
DCM: DHNCHT2MHN;
Product of: Thailand;
PCB Sticker: 2061-701477-100 AC;
PCB Revision: 2060-701477-002 REV A;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 2 : 9CC/2508;
1 : 3 : 9C6/2502;
2 : 4 : 9D8/2520;
3 : 5 : 9E2/2530;
4 : 6 : 9EA/2538;
5 : 7 : 9FA/2554;

ROM F/W version……………………. : 00580041;
Preamp vendor……………………… : 0x0000;
Preamp revision……………………. : 0x0002;

;

HDD with Serial Number: WCAS81112416;
Model: WD5000AAJS-22YFA0;
Date: 24 SEP 2007;
DCM: HBNCNT2MHN;
Product of: Thailand;
PCB Sticker: 2061-701477-100 AC;
PCB Revision: 2060-701477-002 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 2 : AE2/2786;
1 : 3 : A76/2678;
2 : 4 : AC4/2756;
3 : 5 : A8E/2702;
4 : 6 : AD6/2774;
5 : 7 : A82/2690;
ROM F/W version……………………. : 00580076;
Heads map…………………………. : 2,3,4,5,6,7;
Preamp vendor……………………. : 0x0000;
Preamp revision………………….. : 0x0002;

;

HDD with Serial Number: WCAS82241584;
Model: WD5000AAJS-22YFA0;
Date: 21 OCT 2007;
DCM: DHNNHT2CHB;
Product of: Thailand;
PCB Sticker: 2061-701477-100 AD;
PCB Revision: 2060-701477-002 REV A;
;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 2   : A40/2624;
1   : 3   : A36/2614;
2   : 4   : A4E/2638;
3   : 5   : A28/2600;
4   : 6   : A36/2614;
5   : 7   : A16/2582;
ROM F/W version……………………. : 00580076;
Heads map…………………………. : 2,3,4,5,6,7;
Preamp vendor……………………. : 0x0000;
Preamp revision………………….. : 0x0002;

;

HDD #1 Specs:;
Serial Number: WCAS86777365;
Model: WD5000AAJS-22YFA0;
Date: 12 MAR 2008;
DCM: HBNNHT2MBB;
Product of: Thailand;
PCB Sticker: 2061-701444-600 AF;
PCB Revision: 2060-701444-004 REV A;

;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 2 : AB2/2738;
1 : 3 : A96/2710;
2 : 4 : A9E/2718;
3 : 5 : A96/2710;
4 : 6 : AAE/2734;
5 : 7 : A92/2706;

;

ROM F/W version……………………. : 005800A8;
Preamp vendor……………………… : 0x0000;
Preamp revision……………………. : 0x0002;

;

HDD with Serial Number: WCAS81325305;
Model: WD5000AAJS-22YFA0;
Date: 05 OCT 2007;
DCM: DHNNHT2MHB;
Product of: Thailand;
PCB Sticker: 2061-701477-100 AC;
PCB Revision: 2060-701477-002 REV A;

;



;

ROM F/W version……………………. : 00580076;
Preamp vendor……………………… : 0x0000;
Preamp revision……………………. : 0x0002;
Heads map…………………………. : 2,3,4,5,6,7;

;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 2 : AC4/2756;
1 : 3 : A98/2712;
2 : 4 : A84/2692;
3 : 5 : ABA/2746;
4 : 6 : A4E/2638;
5 : 7 : AC0/2752;

;

HDD #1 Specs:;
SN: WCAS86823075;
Model: WD5000AAJS-22YFA0;
Date: 14 MAR 2008;
DCM: HBRNHT2CBB ;
Product of: Thailand;
PCB Sticker: 2061-701444-600 AF;
PCB Revision: 2060-701444-004 REV A;

;
;
;
;
;
;

;

Specifications;
SN: WCAS85321782;
Model: WD5000AAJS-22YFA0;
Date: 17 JAN 2008;
DCM: DHNNNT2AHN ;
Product of: Thailand;
PCB Sticker: 2061-701444-600 AD;
PCB Revision: 2060-701444-004 REV A;

;

;

HDD with Serial Number: WCAS83871742;
Model: WD5000AAJS-22YFA0;
Date: 20 DEC 2007;
DCM: HBRNHT2CHB;
Product of: Thailand;
PCB Sticker: 2061-701477-100 AD;
PCB Revision: 2060-701477-002 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 2 : AC0/2752;
1 : 3 : A84/2692;
2 : 4 : ADC/2780;
3 : 5 : A76/2678;
4 : 6 : AB4/2740;
5 : 7 : A76/2678;
ROM F/W version……………………. : 0058007R;
Heads map…………………………. : 2,3,4,5,6,7;
Preamp vendor……………………. : 0x0000;
Preamp revision………………….. : 0x0002;

;

Specifications:;
Model WD5000AAJS-22TKA0;
SN WCAPW5470484;
Date 25 OCT 2007;
DCM HBNCNV2ABB;
Product of Thailand;
PCB Sticker: 2061-701477-100 AD;
PCB Revision: 2060-701477-002 REV A;

;

HDD with Serial Number: WCAS81365052;
Model: WD5000AAJS-22YFA0;
Date: 03 OCT 2007;
DCM: DHNNNT2MHB;
Product of: Thailand;
PCB Sticker: 2061-701477-100 AC;
PCB Revision: 2060-701477-002 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 2 : A40/2624;
1 : 3 : A68/2664;
2 : 4 : A32/2610;
3 : 5 : A44/2628;
4 : 6 : A26/2598;
5 : 7 : A82/2690;
ROM F/W version……………………. : 00580076;
Heads map…………………………. : 2,3,4,5,6,7;
Preamp vendor………………………. : 0x0000;
Preamp revision…………………….. : 0x0002;

;
