Category: HDD

HDD with Serial Number: WCAPW4306966;
Model: WD5000AAJB-00UHA0;
Date: 12 AUG 2007;
DCM: HANCHV2AHB;
Product of: Thailand;
PCB Sticker: 2061-701508-100 AB;
PCB Revision: 2060-701508-001 REV A;

;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 2   : 686/1670;
1   : 3   : 64C/1612;
2   : 4   : 682/1666;
3   : 5   : 64C/1612;
4   : 6   : 676/1654;
5   : 7   : 658/1624;
ROM F/W version……………………. : 00210068;
Preamp vendor……………………… : 0x0000;
Preamp revision……………………. : 0x0001;
;
;
;
;

;

HDD with Serial Number: WCAS86319853;
Model: WD5000AAJB-00YRA0;
Date: 25 DEC 2008;
DCM: HHRNNT2CHB;
Product of: Thailand;
PCB Sticker: 2061-701508-100 AD;
PCB Revision: 2060-701508-001 REV A;

;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 2   : AA2/2722;
1   : 3   : A60/2656;
2   : 4   : AA2/2722;
3   : 5   : A50/2640;
4   : 6   : A82/2690;
5   : 7   : A74/2676;
ROM F/W version……………………. : 0058007T;
Preamp vendor……………………… : 0x0000;
Preamp revision……………………. : 0x0002;
;
;
;
;

;

HDD with Serial Number: WCAV9S335881;
Model: WD5000AADS-56S9B1;
Date: 18 JUL 2011;
DCM: HBRNNT2AEN;
Product of: Thailand;
PCB Sticker: 2061-771640-803 AA;
PCB Revision: 2060-771640-003 REV A;

;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : DB4/3508;
1 : 1 : D17/3351;

;

ROM F/W version……………………. : 007700FA;
Preamp vendor……………………… : 0x0000;
Preamp revision……………………. : 0x0005;

;

HDD #1 Specs:;
SN: WCAPW4682596;
Model:WD5000AAJB-00UHA0;
Date: 14 MAY 2008;
DCM: HANCHV2CH ;
Product of: Thailand;
PCB Sticker: 2061-701508-108 AB;
PCB Revision: 2060-701508-001 REV A;

;


Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 2   : 698/1688;
1   : 3   : 680/1664;
2   : 4   : 67C/1660;
3   : 5   : 6A2/1698;
4   : 6   : 688/1672;
5   : 7   : 6EC/1772;
;
;

;

HDD #1 Specs:;
SN: WCAS86319894;
Model: WD5000AAJB-00YRA0;
Date: 25 FEB 2008;
DCM: HHRNNT2MHB ;
Product of: Thailand;
PCB Sticker: 2061-701508-100 AD;
PCB Revision: 2060-701508-001 REV A;

;

;

HDD with Serial Number: WCAV9U906397;
Model: WD5000AADS-56S9B1;
Date: 20 SEP 2011;
DCM: HGNNHT2CHN;
Product of: Thailand;
PCB Sticker: 2061-771640-803 AA;
PCB Revision: 2060-771640-003 REV A;

;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : BD7/3031;
1 : 1 : C44/3140;

;

ROM F/W version……………………. : 00780007;
Preamp vendor……………………… : 0x0000;
Preamp revision……………………. : 0x0005;

;

HDD #1 Specs:;
SN: WCAPW2322961;
Model: WD5000AAJB-00UHA0;
Date: 16 JUN 2007;
DCM: HARCHV2CAB ;
Product of: Thailand;
PCB Sticker: 2061-701508-100 AA;
PCB Revision: 2060-701508-001 REV A;

;

;

HDD with Serial Number: WCAPW4947234;
Model: WD5000AAJB-14UHA0;
Date: 13 SEP 2007;
DCM: DHNCHV2MBB;
Product of: Thailand;
PCB Sticker: 2061-701508-100 AB;
PCB Revision: 2060-701508-001 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 2 : 6A0/1696;
1 : 3 : 69E/1694;
2 : 4 : 678/1656;
3 : 5 : 690/1680;
4 : 6 : 692/1682;
5 : 7 : 686/1670;
ROM F/W version……………………. : 0021007B;
Heads map…………………………. : 2,3,4,5,6,7;
Preamp vendor……………………. : 0x0000;
Preamp revision………………….. : 0x0001;

;

HDD with Serial Number: WMAV91129500;
Model: WD5000AADS-00S9B0;
Date: 20 DEC 2011;
DCM: HHNNHT2CH;
Product of: Malaysia;
PCB Sticker: 2061-771640-803 AA;
PCB Revision: 2060-771640-003 REV A;
;

;

HDD with Serial Number: WCAV54521825;
Model: WD5000AADS-11M2B1;
Date: 21 NOV 2009;
DCM: HHRYNT2MAB;
Product of: Thailand;
PCB Sticker: 2061-701640-402 01PD7;
PCB Revision: 2060-701640-002 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 1 : CCC/3276;
1 : 2 : CF3/3315;
2 : 3 : C6F/3183;
ROM F/W version……………………. : 008000BE;
Heads map…………………………. : 1,2,3;
Preamp vendor……………………. : 0x0000;
Preamp revision………………….. : 0x0002;

;
