Category: HDD

HDD with Serial Number: WCAV55534458;
Model: WD5000AADS-11M2B1;
Date: 12 DEC 2009;
DCM: HGNYHT2MHB;
Product of: Thailand;
PCB Sticker: 2061-701640-802 01PD2;
PCB Revision: 2060-701640-002 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : C8A/3210;
1 : 2 : C75/3189;
2 : 3 : CC3/3267;
ROM F/W version……………………. : 008000CM;
Heads map…………………………. : 0,2,3;
Preamp vendor……………………. : 0x0000;
Preamp revision………………….. : 0x0002;

;

HDD with Serial Number: WCAV9V903253;
Model: WD5000AADS-56S9B1;
Date: 10 NOV 2011;
DCM: HBRNHT2AH;
Product of: Malaysia;
PCB Sticker: 2061-771640-803 AA;
PCB Revision: 2060-771640-003 REV A;

;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : C3A/3130;
1 : 1 : C90/3216;

;

ROM F/W version……………………. : 00780007;
Preamp vendor……………………… : 0x0000;
Preamp revision……………………. : 0x0005;

;

HDD with Serial Number: WCAV90077680;
Model: WD5000AADS-00S9B0;
Date: 12 AUG 2009;
DCM: HGNCHT2CHN;
Product of: Thailand;
PCB Sticker: 2061-701640-E00 02P;
PCB Revision: 2060-701640-000 REV P1;
;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : C8B/3211;
1   : 1   : C36/3126

;

HDD with Serial Number: WCAV53421139;
Model: WD5000AADS-11M2B1;
Date: 30 OCT 2009;
DCM: HGRNNT2MGB;
Product of: Thailand;
PCB Sticker: 2061-701640-402 01PD5;
PCB Revision: 2060-701640-002 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : BF5/3061;
1 : 2 : CC2/3266;
2 : 3 : C6A/3178;
ROM F/W version……………………. : 0080007P;
Heads map…………………………. : 0,2,3;
Preamp vendor……………………… : 0x0000;
Preamp revision……………………. : 0x0002;

;

HDD with Serial Number: WMAV91101745;
Model: WD5000AADS-00S9B0;
Date: 23 DEC 2011;
DCM: HGNNHT2CH;
Product of: Malaysia;
PCB Sticker: 2061-771640-803 AA;
PCB Revision: 2060-771640-003 REV A;
;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : DE1/3553;
1   : 1   : D70/3440;
ROM F/W version……………………. : 0078000J;
Heads map…………………………. : 0,1;
Preamp vendor……………………. : 0x0000;
Preamp revision………………….. : 0x0005;
;
;
;

;

HDD with Serial Number: WCAV53492298;
Model: WD5000AADS-11M2B1;
Date: 26 OCT 2009;
DCM: HHNNHT2MHB;
Product of: Thailand;
PCB Sticker: 2061-701640-402 01PD5;
PCB Revision: 2060-701640-002 REV A;

;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 1   : CEA/3306;
1   : 2   : D39/3385;
2   : 3   : D0A/3338;
ROM F/W version……………………. : 0080007E;
Preamp vendor……………………… : 0x0000;
Preamp revision……………………. : 0x0002;
;
;
;
;

;

HDD with Serial Number: WCAV90209269;
Model: WD5000AADS-00S9B0;
Date: 22 AUG 2009;
DCM: HHNCHT2CGN;
Product of: Thailand;
PCB Sticker: 2061-701640-300 AAD3;
PCB Revision: 2060-701640-001 REV A;
;

ROM F/W version 0010000E;
Heads map   0,1;
Preamp vendor: x0000;
Preamp revision: x0005;
;
Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : D6C/3436;
1   : 1   : C74/3188

;

HDD #1 Specs:;
Serial Number: WMAV51222435;
Model: WD5000AADS-11M2B1;
Date: 09 JAN 2010;
DCM: HHRNHT2CH;
Product of: Malaysia;
PCB Sticker: 2061-701640-802 01PD2;
PCB Revision: 2060-701640-002 REV A;

;

;

HDD with Serial Number: WCASU4434343;
Model: WD5000AACS-00ZUB0;
Date: 26 JUN 2008;
DCM: DGRCHV2CAN;
Product of: Thailand;
PCB Sticker: 2061-701444-K00 AE;
PCB Revision: 2060-701444-004 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 9AA/2474;
1 : 1 : 9B6/2486;
2 : 2 : 988/2440;
3 : 3 : 9AC/2476;
ROM F/W version……………………. : 005C003H;
Heads map…………………………. : 0,1,2,3;
Preamp vendor……………………… : 0x0000;
Preamp revision……………………. : 0x0002;

;

HDD with Serial Number: WCAV9P589974;
Model: WD5000AACS-61M6B2;
Date: 07 JUN 2011;
DCM: HHNNNT2CHN;
Product of: Thailand;
PCB Sticker: 2061-771640-W03 02P;
PCB Revision: 2060-771640-003 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : C0E/3086;
1 : 1 : CE5/3301;
ROM F/W version……………………. : 007700FA;
Heads map…………………………. : 0,1;
Preamp vendor……………………… : 0x0000;
Preamp revision……………………. : 0x0005;

;
