Category: HDD

WD7501AAES-60Z2A0, DCM EARNHTJCAB, Western Digital 750GB SATA 3.5 Hard Drive

HDD with Serial Number: WCATR2665814;
Model: WD7501AAES-60Z2A0;
Date: 10 AUG 2010;
DCM: EARNHTJCAB;
Product of: Thailand;
PCB Sticker: 2061-771640-303 01P;
PCB Revision: 2060-771640-003 REV P1;
Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : C3C/3132;
1   : 1   : CE4/3300;
2   : 2   : C2B/3115;
3   : 3   : D32/3378;
ROM F/W version……………………. : 0001002G;
Heads map…………………………. : 0,1,2,3;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0001;
;
;

;

WD7501AAES-60Z2A0, DCM EBRNHTJABB, Western Digital 750GB SATA 3.5 Hard Drive

HDD with Serial Number: WCATR2656512;
Model: WD7501AAES-60Z2A0;
Date: 10 AUG 2010;
DCM: EBRNHTJABB;
Product of: Thailand;
PCB Sticker: 2061-771640-303 01P;
PCB Revision: 2060-771640-003 REV P1;

;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : CEB/3307;
1 : 1 : D0B/3339;
2 : 2 : CFE/3326;
3 : 3 : CEC/3308;

;

ROM F/W version: 0001002G;
Preamp vendor: 0x0001;
Preamp revision: 0x0001;

;

WD7501AAES-60Z2A0, DCM HANNHTJAAB, Western Digital 750GB SATA 3.5 Hard Drive

HDD with Serial Number: WCATR2517610;
Model: WD7501AAES-60Z2A0;
Date: 28 JUL 2010;
DCM: HANNHTJAAB;
Product of: Thailand;
PCB Sticker: 2061-771640-303 01P;
PCB Revision: 2060-771640-003 REV P1;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : C55/3157;
1 : 1 : C19/3097;
2 : 2 : C4F/3151;
3 : 3 : C19/3097;
ROM F/W version……………………. : 0001002G;
Heads map…………………………. : 0,1,2,3;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0001;

HDD with Serial Number: WCATR2486132;
Model: WD7501AAES-60Z2A0;
Date: 28 JUL 2010;
DCM: HANNHTJAAB;
Product of: Thailand;
PCB Sticker: 2061-771640-303 01P;
PCB Revision: 2060-771640-003 REV P1;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : BD3/3027;
1 : 1 : C2B/3115;
2 : 2 : C06/3078;
3 : 3 : C37/3127;
ROM F/W version……………………. : 0001002G;
Heads map…………………………. : 0,1,2,3;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0001;

;

WD7501AAES-60Z2A0, DCM HBNNHTJAAB, Western Digital 750GB SATA 3.5 Hard Drive

HDD with Serial Number: WCATR2745585;
Model: WD7501AAES-60Z2A0;
Date: 17 AUG 2010;
DCM: HBNNHTJAAB;
Product of: Thailand;
PCB Sticker: 2061-771640-303 01P;
PCB Revision: 2060-771640-003 REV P1;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : BAF/2991;
1 : 1 : B8A/2954;
2 : 2 : B95/2965;
3 : 3 : B74/2932;
ROM F/W version……………………. : 0001002G;
Heads map…………………………. : 0,1,2,3;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0001;

;

WD7501AAES-60Z2A0, DCM HBRNHTJAAB, Western Digital 750GB SATA 3.5 Hard Drive

HDD with Serial Number: WCATR3443949;
Model: WD7501AAES-60Z2A0;
Date: 11 SEP 2010;
DCM: HBRNHTJAAB;
Product of: Thailand;
PCB Sticker: 2061-771640-303 ABD2;
PCB Revision: 2060-771640-003 REV P1;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : C49/3145;
1 : 1 : C1D/3101;
2 : 3 : C2D/3117;
ROM F/W version……………………. : 0001002G;
Heads map…………………………. : 0,1,3;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0001;

;

WD7501AAES-75W7A0, DCM EANNHTJCBB, Western Digital 750GB SATA 3.5 Hard Drive

HDD with Serial Number: WCATR2460441;
Model: WD7501AAES-75W7A0;
Date: 03 AUG 2010;
DCM: EANNHTJCBB;
Product of: Thailand;
PCB Sticker: 2061-701640-D02 AB;
PCB Revision: 2060-701640-002 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : D18/3352;
1 : 1 : D3A/3386;
2 : 2 : D2C/3372;
3 : 3 : D32/3378;
ROM F/W version……………………. : 0001002G;
Heads map…………………………. : 0,1,2,3;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0001;

;

WD7501AAES-75W7A0, DCM EARNHTJAAB, Western Digital 750GB SATA 3.5 Hard Drive

HDD with Serial Number: WCATR2607739;
Model: WD7501AAES-75W7A0;
Date: 09 AUG 2010;
DCM: EARNHTJAAB;
Product of: Thailand;
PCB Sticker: 2061-701640-D02 ACD14;
PCB Revision: 2060-701640-002 REV A;
;

HDD with Serial Number: WCATR2456964;
Model: WD7501AAES-75W7A0;
Date: 03 AUG 2010;
DCM: EARNHTJAAB;
Product of: Thailand;
PCB Sticker: 2061-771640-303 01P;
PCB Revision: 2060-771640-003 REV P1;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : C8E/3214;
1 : 1 : C66/3174;
2 : 2 : C90/3216;
3 : 3 : C4A/3146;
ROM F/W version……………………. : 0001002G;
Heads map…………………………. : 0,1,2,3;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0001;

;

WD7501AAES-75W7A0, DCM EARNNTJAAB, Western Digital 750GB SATA 3.5 Hard Drive

HDD with Serial Number: WCATR4126401;
Model: WD7501AAES-75W7A0;
Date: 19 OCT 2010;
DCM: EARNNTJAAB;
Product of: Thailand;
PCB Sticker: 2061-771640-303 ABD2;
PCB Revision: 2060-771640-003 REV P1;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : C5F/3167;
1 : 1 : C28/3112;
2 : 2 : C55/3157;
3 : 3 : C20/3104;
ROM F/W version……………………. : 0001002G;
Heads map…………………………. : 0,1,2,3;
Preamp vendor…………………….. : 0x0001;
Preamp revision……………………. : 0x0001;

;

WD7500KMVW-11ZSMS5, DCM HBMTJBNN, Western Digital 750GB USB 2.5 Hard Drive

HDD with Serial Number: WXG1A7188026;
Model: WD7500KMVW-11ZSMS5;
Date: 16 AUG 2011;
DCM: HBMTJBNN;
Product of: Thailand;
PCB Sticker: 771814-401 02P;
PCB Revision: 2060-771814-001 REV P1;
;

——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : A78/2680;
1   : 1   : B46/2886;
2   : 2   : A7C/2684;
3   : 3   : B72/2930;
4   : 4   : A80/2688;
;
ROM F/W Version: 00550005;
Heads map: 0,1,2,3,4;
Preamp vendor: 0x0001;
Preamp revision: 0x0006

;
