Category: HDD

HDD with Serial Number: WCAPD4551377;
Model: WD3200KS-75PFB0;
Date: 25 MAR 2007;
DCM: DHBHCAJCHN;
Product of: Thailand;
PCB Sticker: 2061-701393-800 AJ;
PCB Revision: 2060-701393-002 REV B;
Heads Map: 0,1,2,3,4,5;
Preamp vendor: 0x0001;
Preamp revision: 0x0000;
Micro Jogs LH0 (1574): 0x000004FA;
Micro Jogs LH1 (1644): 0x00000540;
Micro Jogs LH2 (1552): 0x000004E4;
Micro Jogs LH3 (1706): 0x0000057E;
Micro Jogs LH4 (1564): 0x000004F0;
Micro Jogs LH5 (1762): 0x000005B6;
;

;

HDD with Serial Number: WXF1E8412D02;
Model: WD3200LPCX-24C6HT0;
Date: 30 JAN 2015;
DCM: DHMT2AB;
Product of: Malaysia;
PCB Sticker: 771959-000 AH;
PCB Revision: 2060-771959-000 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 00/0;
1 : 1 : 00/0;
ROM F/W version……………………. : 0006004P;
Heads map…………………………. : 0,1;
Preamp vendor…………………….. : 0x0000;
Preamp revision…………………… : 0x0002;

;

HDD with Serial Number: WCAPD3972450;
Model: WD3200KS-75PFB0;
Date: 30 JAN 2007;
DCM: HHBACA2CAN;
Product of: Thailand;
PCB Sticker: 2061-701393-800 AH;
PCB Revision: 2060-701393-002 REV B;
;

;

HDD with Serial Number: WXF1E84AK9RK;
Model: WD3200LPCX-24C6HT0;
Date: 30 JAN 2015;
DCM: DHMT2AK;
Product of: Malaysia;
PCB Sticker: 771959-000 AH;
PCB Revision: 2060-771959-000 REV A;

;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 00/0;
1 : 1 : 00/0;

;

ROM F/W version……………………. : 0006004P;
Preamp vendor……………………… : 0x0000;
Preamp revision……………………. : 0x0000;

;

HDD with Serial Number: WCAPD3046335;
Model: WD3200KS-75PFB0;
Date: 07 NOV 2006;
DCM: HHBACAJAAN;
Product of: Thailand;
PCB Sticker: 2061-701393-800 AG;
PCB Revision: 2060-701393-002 REV B;
;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : 63E/1598;
1   : 1   : 688/1672;
2   : 2   : 64C/1612;
3   : 3   : 684/1668;
4   : 4   : 64E/1614;
5   : 5   : 684/1668

;

HDD with Serial Number: WXG1EC4FWT4Y;
Model: WD3200LPCX-24C6HT0;
Date: 05 MAR 2015;
DCM: EAKT2AB;
Product of: Malaysia;
PCB Sticker: 771959-000 AH;
PCB Revision: 2060-771959-000 REV A;

;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 00/0;
1 : 1 : 00/0;

;

ROM F/W version……………………. : 0006004P;
Preamp vendor……………………… : 0x0000;
Preamp revision……………………. : 0x0002;

;

HDD with Serial Number: WCAPD4042038;
Model: WD3200KS-75PFB0;
Date: 30 JAN 2007;
DCM: HHBACAJAHN;
Product of: Thailand;
PCB Sticker: 2061-701393-800 AH;
PCB Revision: 2060-701393-002 REV B;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 66C/1644;
1 : 1 : 680/1664;
2 : 2 : 680/1664;
3 : 3 : 676/1654;
4 : 4 : 6BC/1724;
5 : 5 : 63E/1598;
ROM F/W version……………………. : 400SM;
Heads map…………………………. : 0,1,2,3,4,5;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0000;

;

HDD with Serial Number: WXP1E948818Y;
Model: WD3200LPCX-24C6HT0;
Date: 30 JAN 2015;
DCM: EAMT2AB;
Product of: Malaysia;
PCB Sticker: 771959-000 AH;
PCB Revision: 2060-771959-000 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 00/0;
1 : 1 : 00/0;

;

ROM F/W: 0006004P;
Heads map: 0,1;
Preamp vendor: 0x0000;
Preamp revision: 0x0002;

;

HDD with Serial Number: WCAPD1159983;
Model: WD3200JS-60PDB0;
Date: 25 FEB 2006;
DCM: HSCHCAJCH;
Product of: Thailand;
PCB Sticker: 2061-701393-400 AA;
PCB Revision: 2060-701393-002 REV B;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 640/1600;
1 : 1 : 680/1664;
2 : 2 : 65E/1630;
3 : 3 : 69C/1692;
4 : 4 : 652/1618;
5 : 5 : 6BE/1726;
ROM F/W version……………………. : 2119M;
Heads map…………………………. : 0,1,2,3,4,5;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0000;

;

HDD with Serial Number: WCAPD3412155;
Model: WD3200KS-75PFB0;
Date: 08 DEC 2006;
DCM: HHBACAJCAN;
Product of: Thailand;
PCB Sticker: 2061-701393-800 AG;
PCB Revision: 2060-701393-002 REV B;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 658/1624;
1 : 1 : 69E/1694;
2 : 2 : 658/1624;
3 : 3 : 6C6/1734;
4 : 4 : 66E/1646;
5 : 5 : 696/1686;
ROM F/W version……………………. : 400SM;
Heads map…………………………. : 0,1,2,3,4,5;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0000;

;
