Category: HDD

HDD #1 Specs:;
SN: WCAPD3054264;
Model: WD3200JS-22PDB0;
Date: 05 NOV 2006;
DCM: HHBACAJCHN ;
Product of: Thailand;
PCB Sticker: 2061-701393-400 AE;
PCB Revision: 2060-701393-002 REV B;

;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : 664/1636;
1   : 1   : 6CC/1740;
2   : 2   : 63E/1598;
3   : 3   : 6DA/1754;
4   : 4   : 674/1652;
5   : 5   : 6A8/1704;
ROM F/W version……………………. : 400RM;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0000;
;
;
;
;

;

HDD with Serial Number: WCAPD1984832;
Model: WD3200JS-60PDB0;
Date: 24 JUL 2006;
DCM: HHBACA2CA;
Product of: Thailand;
PCB Sticker: 2061-701393-400 AC;
PCB Revision: 2060-701393-002 REV B;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 698/1688;
1 : 1 : 698/1688;
2 : 2 : 698/1688;
3 : 5 : 6CE/1742;
4 : 6 : 68C/1676;
5 : 7 : 6A6/1702;

;

ROM F/W version: 211FM;
Preamp vendor: 0x0000;
Preamp revision: 0x0000;

;

HDD with Serial Number: WCAPD4047869;
Model: WD3200JS-00PDB0;
Date: 31 JAN 2007;
DCM: HHBACAJCHN;
Product of: Thailand;
PCB Sticker: 2061-701393-400 AG;
PCB Revision: 2060-701393-002 REV B;
;

;

HDD with Serial Number: WCAPD4211999;
Model: WD3200JS-22PDB0;
Date: 18 FEB 2007;
DCM: HHBHCA2CAN;
Product of: Thailand;
PCB Sticker: 2061-701393-400 AG;
PCB Revision: 2060-701393-002 REV B;
;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : 6C4/1732;
1   : 1   : 6BC/1724;
2   : 2   : 6CE/1742;
3   : 5   : 6A0/1696;
4   : 6   : 704/1796;
5   : 7   : 690/1680

;

HDD with Serial Number: WCAPD3990813;
Model: WD3200JS-60PDB0;
Date: 20 JAN 2007;
DCM: HHBACA2CAN;
Product of: Thailand;
PCB Sticker: 2061-701393-400 AG;
PCB Revision: 2060-701393-002 REV B;
;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : 6B4/1716;
1   : 1   : 6E0/1760;
2   : 2   : 6B2/1714;
3   : 5   : 6B2/1714;
4   : 6   : 6AA/1706;
5   : 7   : 69A/1690;
ROM F/W version……………………. : 400SM;
Heads map…………………………. : 0,1,2,5,6,7;
Preamp vendor……………………. : 0x0000;
Preamp revision………………….. : 0x0000;
;
;
;

;

HDD with Serial Number: WCAPD2124723;
Model: WD3200JS-00PDB0;
Date: 07 AUG 2006;
DCM: HHBHCAJCAN;
Product of: Thailand;
PCB Sticker: 2061-701393-400 AD;
PCB Revision: 2060-701393-002 REV B;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 6A0/1696;
1 : 1 : 670/1648;
2 : 2 : 6BA/1722;
3 : 3 : 690/1680;
4 : 4 : 6B8/1720;
5 : 5 : 656/1622;

;

ROM F/W version:211FM;
Preamp vendor:0x0001;
Preamp revision:0x0000;

;

HDD with Serial Number: WCAPD2947872;
Model: WD3200JS-22PDB0;
Date: 27 OCT 2006;
DCM: HHBHCAJAHN;
Product of: Thailand;
PCB Sticker: 2061-701393-400 AE;
PCB Revision: 2060-701393-002 REV B;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 646/1606;
1 : 1 : 680/1664;
2 : 2 : 662/1634;
3 : 3 : 67A/1658;
4 : 4 : 676/1654;
5 : 5 : 668/1640;
ROM F/W version……………………. : 400RM;
Heads map…………………………. : 0,1,2,3,4,5;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0000;

;

HDD with Serial Number: WCAPD3779776;
Model: WD3200JS-60PDB0;
Date: 11 JAN 2007;
DCM: HHBACAJAHN;
Product of: Thailand;
PCB Sticker: 2061-701393-400 AG;
PCB Revision: 2060-701393-002 REV B;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 6B6/1718;
1 : 1 : 666/1638;
2 : 2 : 662/1634;
3 : 3 : 690/1680;
4 : 4 : 6C6/1734;
5 : 5 : 66A/1642;
ROM F/W version……………………. : 400SM;
Heads map…………………………. : 0,1,2,3,4,5;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0000;

;

HDD #1 Specs:;
SN: WCAMR3156919;
Model: WD3200JB-00KFA0;
Date: 08 SEP 2006;
DCM: HHCHCA2AHN ;
Product of: Thailand;
PCB Sticker: 2061-701314-A00 AP;
PCB Revision: 2060-701314-003 REV A;

;

;

HDD with Serial Number: WCAMR1950508;
Model: WD3200JD-22KLB0;
Date: 22 DEC 2005;
DCM: DSBHCAJCH;
Product of: Thailand;
PCB Sticker: 2061-701336-B00 AF;
PCB Revision: 2060-701336-003 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 5CC/1484;
1 : 1 : 666/1638;
2 : 2 : 63A/1594;
3 : 3 : 634/1588;
4 : 4 : 704/1796;
5 : 5 : 690/1680;
ROM F/W version……………………. : 083AJ;
Heads map…………………………. : 0,1,2,3,4,5;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0000;

;
