Category: HDD

HDD with Serial Number: WCAMR3136561;
Model: WD3200JB-00KFA0;
Date: 07 AUG 2006;
DCM: DHBACA2CAN;
Product of: Thailand;
PCB Sticker: 2061-701314-A00 AM;
PCB Revision: 2060-701314-003 REV A;

;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 640/1600;
1 : 1 : 68E/1678;
2 : 2 : 644/1604;
3 : 5 : 69C/1692;
4 : 6 : 648/1608;
5 : 7 : 6C8/1736;
ROM F/W version……………………. : 083GJ;
Preamp vendor……………………… : 0x0000;
Preamp revision……………………. : 0x0000;

;

HDD #1 Specs:;
Serial Number: WCAMR3104116;
Model: WD3200JB-00KFA0;
Date: 06 AUG 2006;
DCM: DHBHCAJCHN;
Product of: Thailand;
PCB Revision: 2060-701314-001 REV A;

;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : 6C4/1732;
1   : 1   : 67E/1662;
2   : 2   : 68C/1676;
3   : 3   : 6A8/1704;
4   : 4   : 680/1664;
5   : 5   : 6AC/1708;

;

Preamp Vendor……………………… : 0001;
Preamp Rev………………………… : 0000;
;

;

HDD with Serial Number: WCAMR4285497;
Model: WD3200JB-00KFA0;
Date: 13 JAN 2007;
DCM: DHCACA2CHN;
Product of: Thailand;
PCB Sticker: 2061-701314-A00 AQ;
PCB Revision: 2060-701314-003 REV A;

;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 6AE/1710;
1 : 1 : 6CE/1742;
2 : 2 : 68A/1674;
3 : 5 : 6B6/1718;
4 : 6 : 6CA/1738;
5 : 7 : 6C4/1732 ;
Preamp vendor……………………… : 0x0000;
Preamp revision……………………. : 0x0000;
ROM F/W version……………………. : 083JJ;

;

HDD with Serial Number: WCAMR2939752;
Model: WD3200JB-00KFA0;
Date: 03 JUN 2006;
DCM: DHCHCAJAH;
Product of: Thailand;
PCB Sticker: 2061-701314-A00 AL;
PCB Revision: 2060-701314-002 REV A;
;

;

HDD with Serial Number: WCAMR4509276;
Model: WD3200JB-00KFA0;
Date: 15 MAR 2007;
DCM: DHCHCAJCHN;
Product of: Thailand;
PCB Sticker: 2061-701314-A00 AQ;
PCB Revision: 2060-701314-003 REV A;
;

;

HDD with Serial Number: WCAMR1409782;
Model: WD3200JB-00KFA0;
Date: 04 OCT 2005;
DCM: DSBHCA2CH;
Product of: Thailand;
PCB Sticker: 2061-701314-A00 AF;
PCB Revision: 2060-701314-002 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 63E/1598;
1 : 1 : 696/1686;
2 : 2 : 652/1618;
3 : 5 : 628/1576;
4 : 6 : 5FA/1530;
5 : 7 : 61E/1566;
ROM F/W version……………………. : 0831J;
Heads map…………………………. : 0,1,2,5,6,7;
Preamp vendor……………………. : 0x0000;
Preamp revision………………….. : 0x0000;

;

HDD with Serial Number: WCAMR1105917;
Model: WD3200JB-00KFA0;
Date: 11 AUG 2005;
DCM: DSBHCAJCH;
Product of: Thailand;
PCB Sticker: 2061-701314-A00 AA;
PCB Revision: 2060-701314-001 REV A;
Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 638/1592;
1 : 1 : 67E/1662;
2 : 2 : 5FC/1532;
3 : 3 : 676/1654;
4 : 4 : 620/1568;
5 : 5 : 64C/1612;
ROM F/W version……………………. : 082UJ;
Heads map…………………………. : 0,1,2,3,4,5;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0000;

;

HDD #1 Specs:;
SN: WMAMR1222251;
Model: WD3200JB-00KFA0;
Date: 28 FEB 2005;
DCM: DSCHCAJCH ;
Product of: Malaysia;
PCB Sticker: 2061-701314-A00 AA;
PCB Revision: 2060-701314-001 REV A;

;

;

HDD with Serial Number: WXA1A81E1931;
Model: WD3200BPVT-80JJ5T0;
Date: 04 NOV 2011;
DCM: HEMTJHB;
Product of: Malaysia;
PCB Sticker: 771820-800 AB;
PCB Revision: 2060-771820-000 REV A;
;

ROM F/W 00650046;
Heads map 0,1;
Preamp Vendor: x001;
Preamp revision: x000;
;
Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : B2C/2860;
1   : 1   : B3A/2874

;

HDD with Serial Number: WX71A51Y2418;
Model: WD3200BPVT-80ZEST0;
Date: 25 MAY 2011;
DCM: HHMTJHBB;
Product of: Thailand;
PCB Sticker: 2061-771672-R04 01P;
PCB Revision: 2060-771672-004 REV A;
;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : B21/2849;
1   : 1   : ADA/2778;
ROM F/W version……………………. : 00150033;
Heads map…………………………. : 0,1;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0000;
;
;
;

;
