Category: HDD

HDD with Serial Number: WX61C2251922;
Model: WD3200BPVT-75JJ5T0;
Date: 18 MAR 2012;
DCM: HHMTJAK;
Product of: Malaysia;
PCB Sticker: 771820-900 AF;
PCB Revision: 2060-771820-000 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : B6E/2926;
1 : 1 : B5B/2907;
ROM F/W version……………………. : 00650061;
Heads map…………………………. : 0,1;
Preamp vendor…………………….. : 0x0001;
Preamp revision…………………… : 0x0000;

;

HDD with Serial Number: WX51A2365420;
Model: WD3200BPVT-75JJ5T0;
Date: 06 MAR 2013;
DCM: HHMTJGK;
Product of: Malaysia;
PCB Sticker: 771820-000 AB;
PCB Revision: 2060-771820-000 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : B45/2885;
1 : 1 : BCE/3022;
ROM F/W version……………………. : 0065006P;
Heads map…………………………. : 0,1;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0000;

;

HDD with Serial Number: WX61A8238869;
Model: WD3200BPVT-75JJ5T0;
Date: 16 NOV 2012;
DCM: HHMTJHB;
Product of: Malaysia;
PCB Sticker: 771820-B00 AA;
PCB Revision: 2060-771820-000 REV A;

;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : B52/2898;
1 : 1 : BAF/2991;

;

ROM F/W version……………………. : 0065006P;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0000;

;

HDD with Serial Number: WX31A3312163;
Model: WD3200BPVT-75JJ5T0;
Date: 06 APR 2013;
DCM: HHMTJHK;
Product of: Malaysia;
PCB Sticker: 771820-B00 AB;
PCB Revision: 2060-771820-000 REV A;
;

HDD with Serial Number: WX71A8370487;
Model: WD3200BPVT-75JJ5T0;
Date: 16 OCT 2013;
DCM: HHMTJHK;
Product of: Malaysia;
PCB Sticker: 771820-B00 AH;
PCB Revision: 2060-771820-000 REV A;
;

——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : B40/2880;
1   : 1   : B45/2885;
;
ROM F/W Version: 00650075;
Heads map: 0,1;
Preamp vendor: 0x0001;
Preamp revision: 0x0000

;

HDD with Serial Number: WX41A82L3997;
Model: WD3200BPVT-75JJ5T0;
Date: 11 NOV 2012;
DCM: HHMTJHN;
Product of: Malaysia;
PCB Sticker: 771820-B00 AA;
PCB Revision: 2060-771820-000 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : AF4/2804;
1 : 1 : B0F/2831;
ROM F/W version……………………. : 0065006P;
Heads map…………………………. : 0,1;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0000;

;

HDD with Serial Number: WXS1CB1S1483;
Model: WD3200BPVT-75JJ5T0;
Date: 08 JAN 2012;
DCM: HHMVJHB;
Product of: Malaysia;
PCB Sticker: 771820-900 AB;
PCB Revision: 2060-771820-000 REV A;
;

ROM F/W version 00650046;
Heads map 0,1;
Preamp vendor: x001;
Preamp revision: x000;
;
Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : B08/2824;
1   : 1   : B10/2832

;

HDD with Serial Number: WXU1EB1LFHKU;
Model: WD3200BPVT-75JJ5T0;
Date: 11 NOV 2012;
DCM: SHMTJAB;
Product of: Malaysia;
PCB Sticker: 771820-B00 AA;
PCB Revision: 2060-771820-000 REV A;
Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : B65/2917;
1 : 1 : B98/2968;
ROM F/W version……………………. : 0065006P;
Heads map…………………………. : 0,1;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0000;

;

HDD with Serial Number: WXU1EB1MLHJF;
Model: WD3200BPVT-75JJ5T0;
Date: 11 NOV 2012;
DCM: SHMTJAK;
Product of: Malaysia;
PCB Sticker: 771820-B00 AA;
PCB Revision: 2060-771820-000 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : C87/3207;
1 : 1 : BD6/3030;
ROM F/W version……………………. : 0065006P;
Heads map…………………………. : 0,1;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0000;

HDD with Serial Number: WXC1EC2X8931;
Model: WD3200BPVT-75JJ5T0;
Date: 19 FEB 2013;
DCM: SHMTJAK;
Product of: Malaysia;
PCB Sticker: 771820-B00 AB;
PCB Revision: 2060-771820-000 REV A;
;

ROM F/W :0065006P;
Heads map   0,1;
Preamp Vendor: x001;
Preamp revision: x000;
Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : A7D/2685;
1   : 1   : B8A/2954

;

HDD with Serial Number: WXM1E31RJH49;
Model: WD3200BPVT-24ZEST0;
Date: 05 JUN 2011;
DCM: EHMTJHN;
Product of: Malaysia;
PCB Sticker: 2061-771672-R04 01P;
PCB Revision: 2060-771672-004 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : B77/2935;
1 : 1 : B29/2857;
ROM F/W version……………………. : 00150033;
Heads map…………………………. : 0,1;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0000;

;

HDD with Serial Number: WXA1A81D7327;
Model: WD3200BPVT-35ZEST0;
Date: 03 SEP 2011;
DCM: HEBVJAB;
Product of: Malaysia;
PCB Sticker: 2061-771672-R04 01P;
PCB Revision: 2060-771672-004 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : C0D/3085;
1 : 1 : B96/2966;
ROM F/W version……………………. : 0015003A;
Heads map…………………………. : 0,1;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0000;

;
