Category: HDD

Specifications;
SN: WX61E41VA503;
Model: WD7500KMVW-11ZSMS5;
Date: 08 JUL 2011;
DCM: EHMT2HBN ;
Product of: Thailand;
PCB Sticker: 771814-401 02P;
PCB Revision: 2060-771814-001 REV P1;

;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : B7A/2938;
1   : 1   : BAE/2990;
2   : 3   : B86/2950;
3   : 4   : B6C/2924;
4   : 5   : B8E/2958;
;
;

;

HDD with Serial Number: WXC1A9109053;
Model: WD7500KMVW-11ZSMS4;
Date: 01 OCT 2011;
DCM: HBMT2BBN;
Product of: Thailand;
PCB Sticker: 771761-101 ABD3;
PCB Revision: 2060-771761-001 REV P1;
;

——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : B54/2900;
1   : 1   : B88/2952;
2   : 2   : B68/2920;
3   : 4   : B7A/2938;
4   : 5   : BC8/3016;
;
ROM F/W Version: 0008000F;
Heads map: 0,1,2,4,5;
Preamp vendor: 0x0000;
Preamp revision: 0x0006HDD with Serial Number: WXM1A8172831;
Model: WD7500KMVW-11ZSMS4;
Date: 16 SEP 2011;
DCM: HBMT2BBN;
Product of: Thailand;
PCB Sticker: 771761-101 ABD3;
PCB Revision: 2060-771761-001 REV P1;
;

;

HDD with Serial Number: WX11A91L4608;
Model: WD7500KMVW-11ZSMS4;
Date: 19 SEP 2011;
DCM: HBMT2BNB;
Product of: Thailand;
PCB Sticker: 771761-101 ABD3;
PCB Revision: 2060-771761-001 REV P1;
;
Micro Jogs;
;

;

——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : BB6/2998;
1 : 2 : B86/2950;
2 : 3 : BA0/2976;
3 : 4 : B9C/2972;
4 : 5 : B5A/2906;

;

ROM F/W version……………………. : 0008000F;
Preamp vendor……………………… : 0x0000;
Preamp revision……………………. : 0x0006;

;

HDD #1 Specs:;
Serial Number: WX11A91V9744;
Model: WD7500KMVW-11ZSMS4;
Date: 28 SEP 2011;
DCM: HBMT2HBN;
Product of: Thailand;
PCB Sticker: 771761-101 ABD3;
PCB Revision: 2060-771761-001 REV P1;

;

;

HDD with Serial Number: WXA1A1194516;
Model: WD7500KMVW-11ZSMS4;
Date: 01 MAR 2011;
DCM: HBMTJBBN;
Product of: Thailand;
PCB Sticker: 771761-101 05P;
PCB Revision: 2060-771761-001 REV P1;
;

;

Specifications;
SN: WXD1A91X7840;
Model: WD7500KMVW-11ZSMS4;
Date: 11 NOV 2011;
DCM: HHBTJHB ;
Product of: Malaysia;
PCB Sticker: 2061-771761-101 ABD3;
PCB Revision: 2060-771761-001 REV P1;

;

;

Specifications;
SN: WX91A81H8258;
Model: WD7500KMVW-11ZSMS4;
Date: 10 SEP 2011;
DCM: HHMT2BNN;
R/N 771761;
Product of: Thailand;
PCB Sticker: 2061-771761-101 ABD3;
PCB Revision: 2060-771761-001 REV P1;

;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : B90/2960;
1   : 1   : BBE/3006;
2   : 2   : B7C/2940;
3   : 3   : BC4/3012;
4   : 4   : B94/2964;
;
;

;

HDD #1 Specs:;

;

Serial Number: WX11A91W4152;
Model: WD7500KMVW-11ZSMS4;
Date: 05 NOV 2011;
DCM: HHMT2HB;
Product of: Malaysia;
PCB Sticker: 2061-771761-101 ABD3;
PCB Revision: 2060-771761-001 REV P1;

;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : B5A/2906;
1 : 1 : B08/2824;
2 : 2 : B9C/2972;
3 : 3 : B36/2870;
4 : 4 : B7C/2940;

;

ROM F/W version……………………. : 0008000F;
Preamp vendor……………………… : 0x0000;
Preamp revision……………………. : 0x0006;

;

HDD with Serial Number: WXP1A60K4711;
Model: WD7500KMVV-11BG7S0;
Date: 29 JUL 2010;
DCM: HHBTJHBN;
Product of: Thailand;
PCB Sticker: 2061-701675-304 06P;
PCB Revision: 2060-701675-004 REV P1;

;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : CE4/3300;
1   : 1   : D4C/3404;
2   : 2   : D2C/3372;
3   : 3   : D6A/3434;
4   : 4   : D1E/3358;
5   : 5   : D58/3416;
ROM F/W version……………………. : 001400A2;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0006;
;
;
;
;

;

HDD with Serial Number: WX31A90V5605;
Model: WD7500KMVW-11ZSMS0;
Date: 25 SEP 2010;
DCM: HBMTJBBB;
Product of: Thailand;
PCB Sticker: 771737-200 03P;
PCB Revision: 2060-771737-000 REV P1;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : B85/2949;
1 : 1 : B21/2849;
2 : 2 : B81/2945;
3 : 3 : B2C/2860;
4 : 4 : B5F/2911;
5 : 5 : B29/2857;
ROM F/W version……………………. : 0002008A;
Heads map…………………………. : 0,1,2,3,4,5;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0006;

;
