Category: HDD

HDD with Serial Number: WXE908VK6262;
Model: WD3200BEVT-75ZCT2;
Date: 30 SEP 2008;
DCM: HBCV2ABB;
Product of: Thailand;
PCB Sticker: 2061-701499-500 AE;
PCB Revision: 2060-701499-000 REV A;
;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : 7F9/2041;
1   : 1   : 7FA/2042;
2   : 2   : 7F4/2036;
3   : 3   : 7F4/2036;
ROM F/W version……………………. : 00080014;
Heads map…………………………. : 0,1,2,3;
Premap vendor……………………. : 0x0002;
Preamp revision………………….. : 0x0001;

;

HDD with Serial Number: WXE808KVF242;
Model: WD3200BEVT-75ZCT2;
Date: 01 OCT 2008;
DCM: HHCTJAN;
Product of: Malaysia;
PCB Sticker: 2061-701499-500 AF;
PCB Revision: 2060-701499-000 REV A;
;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : A44/2628;
1   : 1   : 933/2355;
2   : 2   : A26/2598;
3   : 3   : 98B/2443;
ROM F/W version……………………. : 00080014;
Heads map…………………………. : 0,1,2,3;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0001;

;

HDD with Serial Number: WXE908JS3974;
Model: WD3200BEVT-75ZCT2;
Date: 30 SEP 2008;
DCM: HACV2HNB;
Product of: Thailand;
PCB Sticker: 2061-701499-500 AF;
PCB Revision: 2060-701499-000 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 877/2167;
1 : 1 : 81B/2075;
2 : 2 : 841/2113;
3 : 3 : 7BE/1982;
ROM F/W version……………………. : 00080014;
Heads map…………………………. : 0,1,2,3;
Preamp vendor……………………. : 0x0002;
Preamp revision………………….. : 0x0001;

;

HDD with Serial Number: WXE908LH4086;
Model: WD3200BEVT-75ZCT2;
Date: 06 OCT 2008;
DCM: HBCVJBB;
Product of: Malaysia;
PCB Sticker: 2061-701499-600 AG;
PCB Revision: 2060-701499-000 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 7D2/2002;
1 : 1 : 829/2089;
2 : 2 : 7F0/2032;
3 : 3 : 839/2105;
;
;
ROM F/W version: 11.01A11;
Heads map: 0,1,2,3;
Preamp vendor: 0x0001;
Preamp revision: 0x0001;

;

HDD with Serial Number: WXE808DZ8121;
Model: WD3200BEVT-75ZCT2;
Date: 02 OCT 2008;
DCM: HACVJABB;
Product of: Thailand;
PCB Sticker: 2061-701499-500 AF;
PCB Revision: 2060-701499-000 REV A;
;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : 879/2169;
1   : 1   : 7E5/2021;
2   : 2   : 8B5/2229;
3   : 3   : 807/2055;
ROM F/W version……………………. : 00080014;
Heads map…………………………. : 0,1,2,3;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0001;

;

HDD with Serial Number: WX40AB9S9945;
Model: WD3200BEVT-75ZCT2;
Date: 05 DEC 2009;
DCM: HBNT2AB;
Product of: Malaysia;
PCB Sticker: 2061-701499-E00 AD;
PCB Revision: 2060-701499-005 REV A;
;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : 948/2376;
1   : 1   : 8E6/2278;
2   : 2   : 94D/2381;
3   : 3   : 8E7/2279;
ROM F/W version……………………. : 000800FM;
Heads map…………………………. : 0,1,2,3;
Preamp vendor……………………. : 0x0002;
Preamp revision………………….. : 0x0001;
;
;
;

;

HDD with Serial Number: WXE908RU9181;
Model: WD3200BEVT-75ZCT2;
Date: 02 OCT 2008;
DCM: HACVJHNB;
Product of: Thailand;
PCB Sticker: 2061-701499-500 AE;
PCB Revision: 2060-701499-000 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 853/2131;
1 : 1 : 7E7/2023;
2 : 2 : 83D/2109;
3 : 3 : 7F3/2035;
ROM F/W version……………………. : 00080014;
Heads map…………………………. : 0,1,2,3;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0001;

HDD with Serial Number: WXE908TUD015;
Model: WD3200BEVT-75ZCT2;
Date: 01 OCT 2008;
DCM: HACVJHNB;
Product of: Thailand;
PCB Sticker: 2061-701499-500 AF;
PCB Revision: 2060-701499-000 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 82E/2094;
1 : 1 : 7E2/2018;
2 : 2 : 840/2112;
3 : 3 : 806/2054;
ROM F/W version……………………. : 00080014;
Heads map…………………………. : 0,1,2,3;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0001;

;

HDD with Serial Number: WXEY08U6C598;
Model: WD3200BEVT-75ZCT2;
Date: 13 NOV 2008;
DCM: HBNT2HBB;
Product of: Thailand;
PCB Sticker: 2061-701499-500 AF;
PCB Revision: 2060-701499-000 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 948/2376;
1 : 1 : 975/2421;
2 : 2 : 94F/2383;
3 : 3 : 9AE/2478;

;

;
ROM F/W version: 0008001D;
Heads map: 0,1,2,3;
Preamp vendor: 0x0002;
Preamp revision: 0x0001;

;

HDD with Serial Number: WX91A21K5272;
Model: WD3200BEVT-75A23T0;
Date: 10 MAR 2011;
DCM: HHMTJAB;
Product of: Malaysia;
PCB Sticker: 2061-771672-F04 AD;
PCB Revision: 2060-771672-004 REV A;
;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : B04/2820;
1   : 1   : B40/2880;
ROM F/W version……………………. : 0016000T;
Heads map…………………………. : 0,1;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0000;

;

HDD with Serial Number: WXH308621805;
Model: WD3200BEVT-75ZCT1;
Date: 11 JUN 2008;
DCM: DHCVJHNB;
Product of: Thailand;
PCB Sticker: 2061-701499-500 AC;
PCB Revision: 2060-701499-000 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 8B3/2227;
1 : 1 : 850/2128;
2 : 2 : 891/2193;
3 : 3 : 842/2114;
ROM F/W version……………………. : 0008000H;
Heads map…………………………. : 0,1,2,3;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0001;

;
