Category: HDD

HDD with Serial Number: WXH208967267;
Model: WD3200BEVT-60ZCT0;
Date: 27 FEB 2008;
DCM: DACVJANB;
Product of: Thailand;
PCB Sticker: 2061-701499-500 AA;
PCB Revision: 2060-701499-000 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 79D/1949;
1 : 1 : 76A/1898;
2 : 2 : 797/1943;
3 : 3 : 76E/1902;
ROM F/W version……………………. : 00030028;
Heads map…………………………. : 0,1,2,3;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0000;

HDD with Serial Number: WXH108128189;
Model: WD3200BEVT-60ZCT0;
Date: 24 FEB 2008;
DCM: DACVJANB;
Product of: Thailand;
PCB Sticker: 2061-701499-500 AA;
PCB Revision: 2060-701499-000 REV A;
;

ROM F/W 000300A8;
Heads map   0,1,2,3;
Preamp Vendor: x001;
Preamp revision: x000;
;
Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : 74D/1869;
1   : 1   : 791/1937;
2   : 2   : 731/1841;
3   : 3   : 794/1940

;

HDD with Serial Number: WXE508KY6265;
Model: WD3200BEVT-60ZCT0;
Date: 15 JUL 2008;
DCM: HBCV2HB;
Product of: Malaysia;
PCB Sticker: 2061-701499-500 AD;
PCB Revision: 2060-701499-000 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 83A/2106;
1 : 1 : 833/2099;
2 : 2 : 85A/2138;
3 : 3 : 838/2104;
ROM F/W version……………………. : 0008000Q;
Heads map…………………………. : 0,1,2,3;
Preamp vendor…………………… : 0x0002;
Preamp revision…………………. : 0x0001;

;

HDD with Serial Number: WXA0AC9N8465;
Model: WD3200BEVT-26ZCT0;
Date: 28 DEC 2009;
DCM: HHOT2HNB;
Product of: Thailand;
PCB Sticker: 2061-701499-E00 AD;
PCB Revision: 2060-701499-005 REV P1;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 979/2425;
1 : 1 : 996/2454;
2 : 2 : 976/2422;
3 : 3 : 985/2437;
ROM F/W version……………………. : 000800FP;
Heads map…………………………. : 0,1,2,3;
Preamp vendor……………………. : 0x0002;
Preamp revision………………….. : 0x0001;

;

HDD with Serial Number: WXHZ07094205;
Model: WD3200BEVT-60ZCT0;
Date: 28 FEB 2008;
DCM: DACVJHNB;
Product of: Thailand;
PCB Sticker: 2061-701499-500 AA;
PCB Revision: 2060-701499-000 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 77A/1914;
1 : 1 : 7A8/1960;
2 : 2 : 77B/1915;
3 : 3 : 772/1906;
ROM F/W version……………………. : 00030028;
Heads map…………………………. : 0,1,2,3;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0000;

;

HDD with Serial Number: WXE408LUA627;
Model: WD3200BEVT-60ZCT0;
Date: 29 APR 2008;
DCM: HBCVJBBB;
Product of: Thailand;
PCB Sticker: 2061-701499-500 AB;
PCB Revision: 2060-701499-000 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 761/1889;
1 : 1 : 77E/1918;
2 : 2 : 77B/1915;
3 : 3 : 7A6/1958;
ROM F/W version……………………. : 0004002F;
Heads map…………………………. : 0,1,2,3;
Preamp vendor…………………….. : 0x0001;
Preamp revision…………………… : 0x0000;

;

HDD with Serial Number: WXEZ08N67982;
Model: WD3200BEVT-60A2310;
Date: 19 DEC 2013;
DCM: HBCTT6VEI;
Product of: Thailand;
PCB Sticker: 771820-900 AF;
PCB Revision: 2060-771820-000 REV A;
;

;

HDD #1 Specs:;
SN: WXH208720717;
Model: WD3200BEVT-60ZCT0;
Date: 05 MAR 2008;
DCM: DHCVJBBB ;
Product of: Thailand;
PCB Sticker: 2061-701499-500 AA;
PCB Revision: 2060-701499-000 REV A;

;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : 758/1880;
1   : 1   : 777/1911;
2   : 2   : 759/1881;
3   : 3   : 797/1943;
;

;

ROM F/W version……………………. : 00030028;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0000;

;

HDD with Serial Number: WXE508KSF800;
Model: WD3200BEVT-60ZCT0;
Date: 30 JUN 2008;
DCM: HBNVJHB;
Product of: Malaysia;
PCB Sticker: 2061-701499-500 AC;
PCB Revision: 2060-701499-000 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 870/2160;
1 : 1 : 855/2133;
2 : 2 : 7F3/2035;
3 : 3 : 850/2128;
ROM F/W version……………………. : 00080007;
Heads map…………………………. : 0,1,2,3;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0001;

;

HDD with Serial Number: WX21A8000427;
Model: WD3200BEVT-24A23T0;
Date: 15 SEP 2010;
DCM: HEMTJHB;
Product of: Malaysia;
PCB Sticker: 2061-771672-F04 AA;
PCB Revision: 2060-771672-004 REV A;
;

;

HDD with Serial Number: WX70E99DU520;
Model: WD3200BEVT-26ZCT0;
Date: 25 OCT 2009;
DCM: DANT2ANB;
Product of: Thailand;
PCB Sticker: 2061-701499-E00 AC;
PCB Revision: 2060-701499-005 REV P1;

;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : 994/2452;
1   : 1   : 95B/2395;
2   : 2   : 980/2432;
3   : 3   : 94B/2379;
ROM F/W version……………………. : 000800FA;
Preamp vendor……………………… : 0x0002;
Preamp revision……………………. : 0x0001;
;
;

;
