Category: HDD

WD3200BEVT-22A23T0, DCM HEBVJHNB, Western Digital 320GB SATA 2.5 Hard Drive

HDD with Serial Number: WX80AA944105;
Model: WD3200BEVT-22A23T0;
Date: 09 DEC 2009;
DCM: HEBVJHNB;
Product of: Thailand;
PCB Sticker: 2061-771672-001 AC;
PCB Revision: 2060-771672-001 REV P1;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : B89/2953;
1 : 1 : AFB/2811;

;

ROM F/W: 001300CB;
Heads map: 0,1;
Preamp vendor: 0x0001;
Preamp revision: 0x0000;

;

WD3200BEVT-22ZCT0, DCM DANTJBBB, Western Digital 320GB SATA 2.5 Hard Drive

HDD with Serial Number: WXR1E30RRM79;
Model: WD3200BEVT-22ZCT0;
Date: 28 JUL 2010;
DCM: DANTJBBB;
Product of: Thailand;
PCB Sticker: 2061-701499-E00 AF;
PCB Revision: 2060-701499-005 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 970/2416;
1 : 1 : 9AC/2476;
2 : 2 : 985/2437;
3 : 3 : 992/2450;
;
ROM F/W version: 000800FP;
Heads map: 0,1,2,3;
Preamp vendor: 0x0001;
Preamp revision: 0x0001;

;

WD3200BEVT-22A23T0, DCM HHBVJAN, Western Digital 320GB SATA 2.5 Hard Drive

HDD with Serial Number: WX71A30W5587;
Model: WD3200BEVT-22A23T0;
Date: 23 MAR 2010;
DCM: HHBVJAN;
Product of: Malaysia;
PCB Sticker: 2061-771672-F04 AA;
PCB Revision: 2060-771672-004 REV A;

;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : C74/3188;
1 : 1 : C1A/3098;

;

ROM F/W version: 001400DD;
Heads map: 0,1;
Preamp vendor: 0x0001;
Preamp revision: 0x0000;

;

WD3200BEVT-22ZCT0, DCM DAOT2ANB, Western Digital 320GB SATA 2.5 Hard Drive

HDD with Serial Number: WXJ0EB9VC575;
Model: WD3200BEVT-22ZCT0;
Date: 04 JAN 2010;
DCM: DAOT2ANB;
Product of: Thailand;
PCB Sticker: 2061-701499-E00 AD;
PCB Revision: 2060-701499-005 REV A;
;

ROM F/W 000800FP;
Heads map   0,1,2,3;
Preamp Vendor: x002;
Preamp revision: x001;
;
;
Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : 91B/2331;
1   : 1   : 944/2372;
2   : 2   : 94E/2382;
3   : 3   : 93D/2365

HDD with Serial Number: WXJ0EB9SN625;
Model: WD3200BEVT-22ZCT0;
Date: 04 JAN 2010;
DCM: DAOT2ANB;
Product of: Thailand;
PCB Sticker: 2061-701499-E00 AD;
PCB Revision: 2060-701499-005 REV A;
;

——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : 8D2/2258;
1   : 1   : 915/2325;
2   : 2   : 8E4/2276;
3   : 3   : 8B2/2226;
;
ROM F/W Version: 000800FP;
Heads map: 0,1,2,3;
Preamp vendor: 0x0002;
Preamp revision: 0x0001

;

WD3200BEVT-22A23T0, DCM HHBVJHB, Western Digital 320GB SATA 2.5 Hard Drive

HDD with Serial Number: WX21A40A4366;
Model: WD3200BEVT-22A23T0;
Date: 20 APR 2010;
DCM: HHBVJHB;
Product of: Malaysia;
PCB Sticker: 2061-771672-F04 AA;
PCB Revision: 2060-771672-004 REV A;

;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : C6A/3178;
1 : 1 : B3A/2874;
ROM F/W version……………………. : 0014001E;
Heads map…………………………. : 0,1;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0000;

;

HDD with Serial Number: WXS1A60H5213;
Model: WD3200BEVT-22A23T0;
Date: 31 JUL 2010;
DCM: HHBVJHB;
Product of: Malaysia;
PCB Sticker: 2061-771672-F04 AA;
PCB Revision: 2060-771672-004 REV A;

;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : B4A/2890;
1   : 1   : AD8/2776;
ROM F/W version……………………. : 00140039;
Heads map…………………………. : 0,1;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0000;
;
;
;

;

WD3200BEVT-22ZCT0, DCM DAYT2ANB, Western Digital 320GB SATA 2.5 Hard Drive

HDD with Serial Number: WXJ0EB9TX807;
Model: WD3200BEVT-22ZCT0;
Date: 04 JAN 2010;
DCM: DAYT2ANB;
Product of: Thailand;
PCB Sticker: 2061-701499-E00 AD;
PCB Revision: 2060-701499-005 REV A;
;

ROM F/W  000800FP;
Heads map  0,1,2,3;
Preamp Vendor: x002;
Preamp revision: x001;
;
Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : 96C/2412;
1   : 1   : 924/2340;
2   : 2   : 942/2370;
3   : 3   : 924/2340

;

WD3200BEVT-22A23T0, DCM HHBVJHBB, Western Digital 320GB SATA 2.5 Hard Drive

HDD with Serial Number: WXE0AC9U5372;
Model: WD3200BEVT-22A23T0;
Date: 02 JAN 2010;
DCM: HHBVJHBB;
Product of: Thailand;
PCB Sticker: 2061-771672-001 AC;
PCB Revision: 2060-771672-001 REV P1;

;

HDD with Serial Number: WXC0AC9J4381;
Model: WD3200BEVT-22A23T0;
Date: 05 JAN 2010;
DCM: HHBVJHBB;
Product of: Thailand;
PCB Sticker: 2061-771672-001 AC;
PCB Revision: 2060-771672-001 REV P1;

;

WD3200BEVT-22ZCT0, DCM DBCVJABB, Western Digital 320GB SATA 2.5 Hard Drive

HDD with Serial Number: WXH208744615;
Model: WD3200BEVT-22ZCT0;
Date: 11 MAR 2008;
DCM: DBCVJABB;
Product of: Thailand;
PCB Sticker: 2061-701499-500 AA;
PCB Revision: 2060-701499-000 REV A;

;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 7C7/1991;
1 : 1 : 801/2049;
2 : 2 : 806/2054;
3 : 3 : 815/2069;

;

ROM F/W version: 00030028;
Heads map: 0,1,2,3;
Preamp vendor: 0x0001;
Preamp revision: 0x0000;

;

WD3200BEVT-11ZCT0, DCM HHNT2HNB, Western Digital 320GB SATA 2.5 Hard Drive

HDD with Serial Number: WX50A89X9627;
Model: WD3200BEVT-11ZCT0;
Date: 25 AUG 2009;
DCM: HHNT2HNB;
Product of: Thailand;
PCB Sticker: 2061-701499-E00 AC;
PCB Revision: 2060-701499-005 REV P1;
;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : 910/2320;
1   : 1   : 932/2354;
2   : 2   : 928/2344;
3   : 3   : 91C/2332;
ROM F/W version……………………. : 00080031;
Heads map…………………………. : 0,1,2,3;
Preamp vendor……………………. : 0x0002;
Preamp revision………………….. : 0x0001;

;
