Category: HDD

WD3200BEVT-00A23T0, DCM HECVJHBB, Western Digital 320GB SATA 2.5 Hard Drive

HDD with Serial Number: WXF1A60E6603;
Model: WD3200BEVT-00A23T0;
Date: 08 JUL 2010;
DCM: HECVJHBB;
Product of: Thailand;
PCB Sticker: 2061-771672-F04 AA;
PCB Revision: 2060-771672-004 REV A;
;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : B5A/2906;
1   : 1   : AB6/2742;
ROM F/W version……………………. : 00140036;
Heads map…………………………. : 0,1;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0000;

;

WD3200BEVT-00ZAT0, DCM HHCVJBBB, Western Digital 320GB SATA 2.5 Hard Drive

HDD with Serial Number: WX70A6919138;
Model: WD3200BEVT-00ZAT0;
Date: 29 JUL 2009;
DCM: HHCVJBBB;
Product of: Thailand;
PCB Sticker: 2061-701572-400 AB;
PCB Revision: 2060-701572-002 REV A;
;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : 8DC/2268;
1   : 1   : 980/2432;
2   : 2   : 913/2323;
ROM F/W version……………………. : 000900B7;
Heads map…………………………. : 0,1,2;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0002;

;

WD3200BEVT-00A23T0, DCM HEMTJHN, Western Digital 320GB SATA 2.5 Hard Drive

HDD with Serial Number: WX91AB0V6708;
Model: WD3200BEVT-00A23T0;
Date: 14 JAN 2013;
DCM: HEMTJHN;
Product of: Malaysia;
PCB Sticker: 2061-771672-F04 AC;
PCB Revision: 2060-771672-004 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : A86/2694;
1 : 1 : A7E/2686;
ROM F/W version……………………. : 00160029;
Heads map…………………………. : 0,1;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0000;

;

WD3200BEVT-00ZAT0, DCM HHCVJHBB, Western Digital 320GB SATA 2.5 Hard Drive

HDD with Serial Number: WX80A79A0835;
Model: WD3200BEVT-00ZAT0;
Date: 28 JUL 2009;
DCM: HHCVJHBB;
Product of: Thailand;
PCB Sticker: 2061-701572-400 AB;
PCB Revision: 2060-701572-002 REV A;

;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 96D/2413;
1 : 1 : 96E/2414;
2 : 2 : 97C/2428;

;

ROM F/W version:000900B7;
Preamp vendor:0x0001;
Preamp revision:0x0002;

;

HDD with Serial Number: WX31A1017703;
Model: WD3200BEVT-00ZAT0;
Date: 04 FEB 2010;
DCM: HHCVJHBB;
Product of: Thailand;
PCB Sticker: 2061-701572-400 AE;
PCB Revision: 2060-701572-002 REV A;

;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 8FF/2303;
1 : 1 : 8AB/2219;
2 : 2 : 926/2342;

;

ROM F/W version: 00100001;
Heads map: 0,1,2;
Preamp vendor: 0x0001;
Preamp revision: 0x0002;

HDD with Serial Number: WX80A89W0406;
Model: WD3200BEVT-00ZAT0;
Date: 29 AUG 2009;
DCM: HHCVJHBB;
Product of: Thailand;
PCB Sticker: 2061-701572-400 AB;
PCB Revision: 2060-701572-002 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 915/2325;
1 : 1 : 93F/2367;
2 : 2 : 919/2329;

;

ROM F/W: 000900BC;
Heads map: 0,1,2;
Preamp vendor: 0x0001;
Preamp revision: 0x0002;

;

WD3200BEVT-00A23T0, DCM HHBVJAB, Western Digital 320GB SATA 2.5 Hard Drive

HDD with Serial Number: WX61A80S9269;
Model: WD3200BEVT-00A23T0;
Date: 21 JUL 2011;
DCM: HHBVJAB;
Product of: Thailand;
PCB Sticker: 2061-771672-F04 AA;
PCB Revision: 2060-771672-004 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : BD8/3032;
1 : 1 : B12/2834;
ROM F/W version……………………. : 0014003G;
Heads map…………………………. : 0,1;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0000;

;

WD3200BEVT-00ZCT0, DCM DANTJHB, Western Digital 320GB SATA 2.5 Hard Drive

HDD with Serial Number: WX91E30L8998;
Model: WD3200BEVT-00ZCT0;
Date: 27 NOV 2012;
DCM: DANTJHB;
Product of: Thailand;
PCB Sticker: 2061-701499-E00 AF;
PCB Revision: 2060-701499-005 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 8D0/2256;
1 : 1 : 8FE/2302;
2 : 2 : 8E9/2281;
3 : 3 : 916/2326;
ROM F/W version……………………. : 0008003P;
Heads map…………………………. : 0,1,2,3;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0001;

;

WD3200BEVT-00A23T0, DCM HHBVJHB, Western Digital 320GB SATA 2.5 Hard Drive

HDD with Serial Number: WXR1A6018448;
Model: WD3200BEVT-00A23T0;
Date: 30 NOV 2012;
DCM: HHBVJHB;
Product of: Malaysia;
PCB Sticker: 2061-771672-F04 AA;
PCB Revision: 2060-771672-004 REV A;

;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : B6C/2924;
1 : 1 : BB2/2994;
ROM F/W version……………………. : 00160029;
Heads map…………………………. : 0,1;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0000;

;

WD3200BEVT-00ZCT0, DCM DANVJAB, Western Digital 320GB SATA 2.5 Hard Drive

HDD with Serial Number: WXH808368618;
Model: WD3200BEVT-00ZCT0;
Date: 13 OCT 2009;
DCM: DANVJAB;
Product of: Thailand;
PCB Sticker: 2061-701499-500 AD;
PCB Revision: 2060-701499-000 REV A;
;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : 822/2082;
1   : 1   : 7E2/2018;
2   : 2   : 822/2082;
3   : 3   : 7C0/1984;
ROM F/W version……………………. : 0008000W;
Heads map…………………………. : 0,1,2,3;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0001;

;
