Category: HDD

HDD #1 Specs:;
SN: WXF0EA9DJX45;
Model: WD3200BEVS-26VAT0;
Date: 14 DEC 2009;
DCM: DHYT2HNB ;
Product of: Thailand;
PCB Sticker: 2061-701499-E00 AD;
PCB Revision: 2060-701499-005 REV A;

;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : 935/2357;
1   : 1   : 912/2322;
2   : 2   : 91F/2335;
3   : 3   : 91A/2330;

;

ROM F/W version……………………. : 000800FM;
Preamp vendor……………………… : 0x0002;
Preamp revision……………………. : 0x0001;

;

HDD with Serial Number: WXE0E99LHJ76;
Model: WD3200BEVS-08VAT2;
Date: 29 OCT 2009;
DCM: DHNTJBNB;
Product of: Thailand;
PCB Sticker: 2061-701499-E00 AC;
PCB Revision: 2060701499-005 REV A;
;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : 940/2368;
1   : 1   : 8E8/2280;
2   : 2   : 92C/2348;
3   : 3   : 8F7/2295;
ROM F/W version……………………. : 000800FA;
Heads map…………………………. : 0,1,2,3;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0001;

;

HDD with Serial Number: WXEY08H32493;
Model: WD3200BEVS-26VAT0;
Date: 09 NOV 2008;
DCM: HACT2ANB;
Product of: Thailand;
PCB Sticker: 2061-701499-500 AF;
PCB Revision: 2060-701499-000 REV A;

;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 8FC/2300;
1 : 1 : 998/2456;
2 : 2 : 92C/2348;
3 : 3 : 9A6/2470;
ROM F/W version……………………. : 0008000W;
Heads map…………………………. : 0,1,2,3;
Preamp vendor…………………….. : 0x0002;
Preamp revision…………………… : 0x0001;

;

HDD #1 Specs:;
SN: WXE509K56316;
Model: WD3200BEVS-08VAT2;
Date: 11 MAY 2009;
DCM: HACT2HBB ;
Product of: Thailand;
PCB Sticker: 2061-701499-E00 AC;
PCB Revision: 2060-701499-005 REV P1;

;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : 982/2434;
1   : 1   : 8E4/2276;
2   : 2   : 94D/2381;
3   : 3   : 919/2329;
;
;

;

HDD with Serial Number: WXEX08RZK436;
Model: WD3200BEVS-26VAT0;
Date: 08 NOV 2008;
DCM: HACT2HNB;
Product of: Thailand;
PCB Sticker: 2061-701499-500 AF;
PCB Revision: 2060-701499-000 REV A;

;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : A1A/2586;
1 : 1 : AEC/2796;

;

ROM F/W version: 00100018;
Heads map: 0,1;
Preamp vendor: 0x0000;
Preamp revision: 0x0009;

;

HDD with Serial Number: WX10A8985765;
Model: WD3200BEVS-08VAT2;
Date: 26 AUG 2009;
DCM: HANTJABB;
Product of: Thailand;
PCB Sticker: 2061-701499-E00 AC;
PCB Revision: 2060-701499-005 REV P1;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 946/2374;
1 : 1 : 917/2327;
2 : 2 : 948/2376;
3 : 3 : 91B/2331;
ROM F/W version……………………. : 00080031;
Heads map…………………………. : 0,1,2,3;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0001;
;
;

;

HDD with Serial Number: WXE409J51023;
Model: WD3200BEVS-08VAT2;
Date: 11 APR 2009;
DCM: HHCT2BBB;
Product of: Thailand;
PCB Sticker: 2061-701499-E00 AC;
PCB Revision: 2060-701499-005 REV P1;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 985/2437;
1 : 1 : 9AD/2477;
2 : 2 : 992/2450;
3 : 3 : 9C5/2501;
ROM F/W version……………………. : 0008002A;
Heads map…………………………. : 0,1,2,3;
Preamp vendor……………………. : 0x0002;
Preamp revision………………….. : 0x0001;

;

HDD with Serial Number: WX80A6971305;
Model: WD3200BEVS-08VAT2;
Date: 28 JUN 2009;
DCM: HHCTJANB;
Product of: Thailand;
PCB Sticker: 2061-701499-E00 AC;
PCB Revision: 2060-701499-005 REV P1;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 997/2455;
1 : 1 : 8E8/2280;
2 : 2 : 99E/2462;
3 : 3 : 8F8/2296;
ROM F/W version……………………. : 00080030;
Heads map…………………………. : 0,1,2,3;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0001;

;

HDD with Serial Number: WX61A25EDYYX;
Model: WD3200BEKX-66B7WT0;
Date: 07 APR 2015;
DCM: HHNTJHK;
Product of: Malaysia;
PCB Sticker: 771692-C06 AA;
PCB Revision: 2060-771692-006 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : B69/2921;
1 : 1 : ADA/2778;
ROM F/W version……………………. : 0015000H;
Heads map…………………………. : 0,1;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0000;

HDD with Serial Number: WX41A54H5387;
Model: WD3200BEKX-66B7WT0;
Date: 02 SEP 2014;
DCM: HHNTJHK;
Product of: Malaysia;
PCB Sticker: 771692-C06 AA;
PCB Revision: 2060-771692-006 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : B14/2836;
1 : 1 : B14/2836;

;

ROM F/W version:0015000H;
Preamp vendor:0x0001;
Preamp revision:0x0000;

;

HDD #1 Specs:;
Serial Number: WX90A99E9530;
Model: WD3200BEVE-00A0HT0;
Date: 14 OCT 2009;
DCM: HANT2HNB;
Product of: Thailand;
PCB Sticker: 2061-701532-000 AJ;
PCB Revision: 2060-701532-000 REV A;

;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : 932/2354;
1   : 1   : 970/2416;
2   : 2   : 90C/2316;
3   : 3   : 952/2386;
;
;
;

;
