Category: HDD

HDD with Serial Number: WX90A89K4746;
Model: WD3200BEKT-60F3T1;
Date: 11 SEP 2009;
DCM: HACTJHNB;
Product of: Thailand;
PCB Sticker: 2061-701574-D00 AB;
PCB Revision: 2060-701574-001 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 8F8/2296;
1 : 1 : 90B/2315;
2 : 2 : 92A/2346;
3 : 3 : 933/2355;
ROM F/W version……………………. : 000700FT;
Heads map…………………………. : 0,1,2,3;
Preamp vendor…………………….. : 0x0001;
Preamp revision…………………… : 0x0002;

;

HDD with Serial Number: WXH1A3137964;
Model: WD3200BEKT-60PVMT0;
Date: 25 APR 2011;
DCM: HHCTJABB;
Product of: Thailand;
PCB Sticker: 771692-505 03P;
PCB Revision: 2060-771692-005 REV A;
;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : B2F/2863;
1   : 1   : AF1/2801;
ROM F/W version……………………. : 00030027;
Heads map…………………………. : 0,1;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0000;

;

HDD with Serial Number: WX90AB9H0564;
Model: WD3200BEKT-60V5T1;
Date: 06 DEC 2009;
DCM: HANTJBNB;
Product of: Thailand;
PCB Sticker: 2061-771574-D01 01P;
PCB Revision: 2060-771547-001 REV P1;

;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 8F6/2294;
1 : 1 : 92B/2347;
2 : 2 : 930/2352;
3 : 3 : 93B/2363;

;

ROM F/W version: 0007003T;
Heads map: 0,1,2,3;
Preamp vendor: 0x0001;
Preamp revision: 0x0002;

;

HDD with Serial Number: WXC0A89P4165;
Model: WD3200BEKT-60F3T1;
Date: 23 SEP 2009;
DCM: HANTJANB;
Product of: Thailand;
PCB Sticker: 2061-701574-D00 AB;
PCB Revision: 2060-701574-001 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 941/2369;
1 : 1 : 868/2152;
2 : 2 : 95E/2398;
3 : 3 : 88A/2186;
ROM F/W version……………………. : 000700BT;
Heads map…………………………. : 0,1,2,3;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0002;

;

HDD with Serial Number: WXE1C12K2645;
Model: WD3200BEKT-60PVMT0;
Date: 16 AUG 2012;
DCM: HHCTJAK;
Product of: Malaysia;
PCB Sticker: 771692-806 AE;
PCB Revision: 2060-771692-006 REV A;
;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : B62/2914;
1   : 1   : BAD/2989;
ROM F/W version……………………. : 00040027;
Heads map…………………………. : 0,1;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0000;

;

HDD with Serial Number: WX71A3040275;
Model: WD3200BEKT-60V5T1;
Date: 13 APR 2010;
DCM: HANTJHBB;
Product of: Thailand;
PCB Sticker: 2061-771574-D01 02P;
PCB Revision: 2060-771547-001 REV P1;
;

;

HDD with Serial Number: WX60A89H3248;
Model: WD3200BEKT-60F3T1;
Date: 30 AUG 2009;
DCM: HHCTJHNB;
Product of: Thailand;
PCB Sticker: 2061-701574-D00 AB;
PCB Revision: 2060-701574-001 REV A;

;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 920/2336;
1 : 1 : 8C8/2248;
2 : 2 : 990/2448;
3 : 3 : 8C5/2245;

;

ROM F/W version: 000700FT;
Heads map: 0,1,2,3;
Preamp vendor: 0x0001;
Preamp revision: 0x0002;

;

HDD with Serial Number: WXE1A21K5911;
Model: WD3200BEKT-60PVMT0;
Date: 20 MAR 2011;
DCM: HHCTJAN;
Product of: Malaysia;
PCB Sticker: 771692-505 03P;
PCB Revision: 2060-771692-005 REV A;

;

HDD with Serial Number: WXK1A90V9918;
Model: WD3200BEKT-60V5T1;
Date: 16 OCT 2010;
DCM: HBNTJABB;
Product of: Thailand;
PCB Sticker: 2061-771574-D01 02P;
PCB Revision: 2060-771547-001 REV P1;

;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 8F0/2288;
1 : 1 : 95E/2398;
2 : 2 : 8EE/2286;
3 : 3 : 95A/2394;
ROM F/W version……………………. : 000800BJ;
Heads map…………………………. : 0,1,2,3;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0002;

HDD with Serial Number: WXK1A90V8047;
Model: WD3200BEKT-60V5T1;
Date: 16 OCT 2010;
DCM: HBNTJABB;
Product of: Thailand;
PCB Sticker: 2061-771574-D01 02P;
PCB Revision: 2060-771574-001 REV P1;
;

;

HDD with Serial Number: WXM1E60N1043;
Model: WD3200BEKT-60KA9T0;
Date: 18 AUG 2010;
DCM: EACTJANB;
Product of: Thailand;
PCB Sticker: 2061-771714-002 AA;
PCB Revision: 2060-771714-002 REV P1;
;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : A44/2628;
1   : 2   : A43/2627;
2   : 3   : A31/2609;
ROM F/W version……………………. : 0016000P;
Heads map…………………………. : 0,2,3;
Preamp vendor……………………. : 0x0001;
Preamp revison…………………… : 0x0003;

;
