HDD with Serial Number: WX51E1073564;
Model: WD1600BEVT-22ZCT0;
Date: 10 FEB 2010;
DCM: DANTJHBB;
Product of: Thailand;
PCB Sticker: 2061-701499-E00 AD;
PCB Revision: 2060-701499-005 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 995/2453;
1 : 1 : 8DA/2266;
ROM F/W version……………………. : 000800FP;
Heads map…………………………. : 0,1;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0001;

HDD with Serial Number: WXHX08A63544;
Model: WD1600BEVT-22ZCT0;
Date: 30 NOV 2008;
DCM: DANTJHBB;
Product of: Thailand;
PCB Sticker: 2061-701499-500 AF;
PCB Revision: 2060-701499-000 REV A;
;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : 9BE/2494;
1   : 1   : 8F4/2292;
ROM F/W version……………………. : 0008001S;
Heads map…………………………. : 0,1;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0001;
;
;
;

;

HDD with Serial Number: WXJ0EB9DCL03;
Model: WD1600BEVT-22ZCT0;
Date: 06 JAN 2010;
DCM: DANTJABB;
Product of: Thailand;
PCB Sticker: 2061-701499-E00 AD;
PCB Revision: 2060-701499-005 REV A;
;

ROM F/W  0008003P;
Heads map  2,3;
Preamp Vendor: x001;
Preamp revision: x001;
;
Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 2   : 991/2449;
1   : 3   : 97E/2430

;

HDD with Serial Number: WX10E79T4649;
Model: WD1600BEVT-22ZCT0;
Date: 23 AUG 2009;
DCM: DANT2ANB;
Product of: Thailand;
PCB Sticker: 2061-701499-E00 AC;
PCB Revision: 2060-701499-005 REV P1;
;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : 9AD/2477;
1   : 1   : 91D/2333;
ROM F/W version……………………. : 000800F1;
Heads map…………………………. : 0,1;
Preamp vendor……………………. : 0x0002;
Preamp revision………………….. : 0x0001;
;
;
;

;

HDD with Serial Number: WXN1E40HXZ49;
Model: WD1600BEVT-22ZCT0;
Date: 21 AUG 2010;
DCM: DANT2ABB;
Product of: Thailand;
PCB Sticker: 2061-701499-E00 AF;
PCB Revision: 2060-701499-005 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 968/2408;
1 : 1 : 902/2306;
ROM F/W version……………………. : 000800FP;
Heads map…………………………. : 0,1;
Preamp vendor……………………. : 0x0002;
Preamp revision………………….. : 0x0001;

;

HDD with Serial Number: WX21A21M0708;
Model: WD1600BEVT-22A23T0;
Date: 26 FEB 2011;
DCM: HHNTJHKB;
Product of: Thailand;
PCB Sticker: 2061-771672-F04 AD;
PCB Revision: 2060-771672-004 REV A;

;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : AD0/2768;
1 : 1 : A32/2610;
ROM F/W version……………………. : 0016000D;
Heads map…………………………. : 0,1;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0000;

;

HDD with Serial Number: WX81A21V8212;
Model: WD1600BEVT-22A23T0;
Date: 05 MAR 20111;
DCM: HHMTJHBB;
Product of: Thailand;
PCB Sticker: 2061-771672-F04 AD;
PCB Revision: 2060-771672-004 REV A;

ROM F/W version0016000T;
Heads map: 0;
Preamp vendor: 0x0001;
Preamp revision: 0x0000;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : B60/2912;

;

HDD #1 Specs:;
Serial Number: WX41AA053872;
Model: WD1600BEVT-22A23T0;
Date: 20 OCT 2010;
DCM: HHCVJHN;
Product of: Malaysia;
PCB Sticker: 2061-771672-F04 AC;
PCB Revision: 2060-771672-004 REV A;

;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 1   : BE8/3048;

;

ROM F/W version……………………. : 0014003V;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0000;

;

Specifications;
SN: WXH1A6058928;
Model: WD1600BEVT-22A23T0;
Date: 09 JUL 2010;
DCM: HHCTJHBB;
R/N 771672;
Product of: Thailand;
PCB Sticker: 2061-771672-F04 AA;
PCB Revision: 2060-771672-004 REV A;

;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : A14/2580;
1   : 1   : A3B/2619;
ROM F/W version……………………. : 00140036;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0000;
;
;
;
;

;

HDD #1 Specs:;
Serial Number: WXG1A60L1143;
Model: WD1600BEVT-22A23T0;
Date: 05 JUL 2010;
DCM: HHBVJHNB;
Product of: Thailand;
PCB Sticker: 2061-771672-F04 AA;
PCB Revision: 2060-771672-004 REV A;

;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : B68/2920;
ROM F/W version……………………. : 00140036;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0000;
;
;
;
;

;

HDD #2 Specs:;
SN: WXD1A6083921;
Model: WD1600BEVT-22A23T0;
Date: 11 JUL 2010;
DCM: HHBVJHB ;
Product of: Malaysia;
PCB Sticker: 2061-771672-F04 AA;
PCB Revision: 2060-771672-004 REV A;

;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 1   : A7A/2682;
ROM F/W version……………………. : 00140036;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0000;
;
;
HDD #4 Specs:;
SN: WXK1A6045976;
Model: WD1600BEVT-22A23T0;
Date: 07 JUL 2010;
DCM: HHBVJHBB ;
Product of: Thailand;
PCB Sticker: 2061-771672-F04 AA;
PCB Revision: 2060-771672-004 REV A;

;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : C42/3138;
ROM F/W version……………………. : 00140036;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0000;
;
;
;
;

;
