HDD #1 Specs:;
Serial Number: WMAY01910096;
Model: WD1502FAEX-007BA0;
Date: 06 MAY 2011;
DCM: HARCHV2AB;
Product of: Malaysia;
PCB Sticker: 771624-A03 BH;
PCB Revision: 2060-771624-003 REV A;

;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : B19/2841;
1   : 1   : AA1/2721;
2   : 4   : B25/2853;
3   : 5   : AF9/2809;
4   : 6   : B49/2889;
5   : 7   : B15/2837;

;

ROM F/W version……………………. : 00050063;
Preamp Vendor……………………… : 0000;
Preamp Rev………………………… : 0003;

;

HDD with Serial Number: WMAY02392682;
Model: WD1502FAEX-007BA0;
Date: 30 MAY 2011;
DCM: HARCHV2AA;
Product of: Malaysia;
PCB Sticker: 771624-A03 BH;
PCB Revision: 2060-771624-003 REV A;
;

HDD with Serial Number: WMAY03735669;
Model: WD1502FAEX-007BA0;
Date: 14 OCT 2011;
DCM: HARCHV2AA;
Product of: Malaysia;
PCB Sticker: 771624-A03 BH;
PCB Revision: 2060-771624-003 REV A;
;

ROM F/W version 00050063;
Heads map   1,2,3,5,6,7;
Preamp vendor: x0000;
Preamp revision: x0003;
;
Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 1   : B81/2945;
1   : 2   : AF9/2809;
2   : 3   : B21/2849;
3   : 5   : B3D/2877;
4   : 6   : AD1/2769;
5   : 7   : BA5/2981

;

HDD with Serial Number: WCAY00412505;
Model: WD1502FAEX-007BA0;
Date: 22 SEP 2016;
DCM: HANCHV2AB;
Product of: Thailand;
PCB Sticker: 771624-F03 AD;
PCB Revision: 2060-771624-003 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : ABD/2749;
1 : 1 : A95/2709;
2 : 2 : ADD/2781;
3 : 4 : AA5/2725;
4 : 5 : AA9/2729;
5 : 6 : AF1/2801;
ROM F/W version……………………. : 0005009R;
Heads map…………………………. : 0,1,2,4,5,6;
Preamp vendor……………………… : 0x0000;
Preamp revision……………………. : 0x0003;

;

HDD with Serial Number: WCAY01155698;
Model: WD1502FAEX-007BA0;
Date: 28 MAR 2018;
DCM: HANCHV2AA;
Product of: Thailand;
PCB Sticker: 771624-F03 AED13;
PCB Revision: 2060-771624-003 REV A;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 1 : B25/2853;
1 : 2 : AD1/2769;
2 : 3 : B2D/2861;
3 : 4 : AE9/2793;
4 : 6 : B11/2833;
5 : 7 : B4D/2893;

ROM F/W version: 0005009R;
Heads map: 1,2,3,4,6,7;
Preamp vendor: 0x0000;
Preamp revision: 0x0003;

;

HDD #1 Specs:;
Serial Number: WMAY00957082;
Model: WD1501FASS-00W2B0;
Date: 01 JAN 2011;
DCM: HHMTJHKB;
Product of: Thailand;
PCB Sticker: 771624-A03 BD;
PCB Revision: 2060-771624-003 REV A;

;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : B11/2833;
1   : 1   : AAD/2733;
2   : 3   : A71/2673;
3   : 4   : AE5/2789;
4   : 6   : B01/2817;
5   : 7   : AB9/2745;
Preamp Vendor……………………… : 0000;
Preamp Rev………………………… : 0003;
ROM F/W version……………………. : 00F5000F;
;
;
;
;
;

;

HDD #1 Specs:;
SN: WMAY00870149;
Model: WD1501FASS-00W2B0;
Date: 21 DEC 2010 ;
DCM: HBRCHV2CA ;
Product of: Malaysia;
PCB Sticker: 771624-A03 BD;
PCB Revision: 2060-771624-003 REV A;

;

;

B24Specifications;
SN: WMAY00892759;
Model: WD1501FASS-00W2B0;
Date: 12 JAN 2011;
DCM: HARCNV2CB ;
Product of: Thailand;
PCB Sticker: 771624-A03;
PCB Revision: 2060-771624-003 REV A;

;
;

;

Specifications;
SN: WMAY00666549;
Model: WD1501FASS-00W2B0;
Date: 25 DEC 2010;
DCM: HARCHV2CA ;
Product of: Malaysia;
PCB Sticker: 771624-A03;
PCB Revision: 2060-771624-003 REV A;


Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : BC1/3009;
1   : 1   : A91/2705;
2   : 2   : B9D/2973;
3   : 3   : AC9/2761;
4   : 4   : B95/2965;
5   : 7   : AE5/2789;
ROM F/W version……………………. : 00F5000F;
Preamp vendor……………………… : 0x0000;
Preamp revision……………………. : 0x0003;
;
;
;
;
;
;

HDD with Serial Number: WMAY00606501;
Model: WD1501FASS-00W2B0;
Date: 12 DEC 2010;
DCM: HARCHV2CA;
Product of: Malaysia;
PCB Sticker: 771624-A03 BD;
PCB Revision: 2060-771624-003 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : AF1/2801;
1 : 1 : BA1/2977;
2 : 3 : B35/2869;
3 : 5 : B05/2821;
4 : 6 : AD1/2769;
5 : 7 : B0D/2829;
ROM F/W version……………………. : 00F5000F;
Heads map…………………………. : 0,1,3,5,6,7;
Preamp vendor……………………. : 0x0000;
Preamp revision………………….. : 0x0003;

;

HDD with Serial Number: WMAUR0199795;
Model: WD1501FASS-00U0B0;
Date: 16 MAR 2010;
DCM: HBRCHV2AB;
Product of: Malaysia;
PCB Sticker: 2061-771624-400 AB;
PCB Revision: 2060-771624-001 REV P1;

;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : B80/2944;
1 : 1 : B16/2838;
2 : 2 : B4C/2892;
3 : 3 : AED/2797;
4 : 4 : B88/2952;
5 : 5 : AE6/2790;
6 : 6 : B38/2872;

;

ROM F/W version……………………. : 0006005C;
Preamp vendor……………………… : 0x0000;
Preamp revision……………………. : 0x0003;

;

HDD with Serial Number: WMAUR0242328;
Model: WD1501FASS-00U0B0;
Date: 22 MAR 2010;
DCM: HARCNV2CB;
Product of: Malaysia;
PCB Sticker: 2061-771624-700 AC;
PCB Revision: 2060-771624-001 REV P1;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : ABE/2750;
1 : 1 : AE3/2787;
2 : 2 : A8C/2700;
3 : 3 : AFE/2814;
4 : 4 : A8A/2698;
5 : 5 : AF0/2800;
6 : 7 : AD6/2774;
ROM F/W version……………………. : 0006005C;
Heads map…………………………. : 0,1,2,3,4,5,7;
Preamp vendor……………………… : 0x0000;
Preamp revision……………………. : 0x0003;

;
