HDD with Serial Number: WXEY06584148;
Model: WD1200VE-22KWT0;
Date: 25 NOV 2006;
DCM: HCAJABB;
Product of: Thailand;
PCB Sticker: 2061-701402-200 AC;
PCB Revision: 2060-701402-002 REV B;
;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : 6DB/1755;
1   : 1   : 747/1863;
2   : 2   : 71D/1821;
3   : 3   : 729/1833;
ROM F/W version……………………. : 0002002V;
Heads map…………………………. : 0,1,2,3;
Preamp vendor……………………. : 0x0004;
Preamp revision………………….. : 0x0001;

;

HDD #1 Specs:;
Serial Number: WXCX06063132;
Model: WD1200VE-22KWT0;
Date: 05 DEC 2006;
DCM: FCAJHNB;
Product of: Thailand;
PCB Sticker: 2061-701402-200 AC;
PCB Revision: 2060-701402-002 REV B;

;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : 663/1635;
1   : 1   : 6DD/1757;
2   : 2   : 675/1653;
3   : 3   : 767/1895;

;

ROM F/W version……………………. : 0002002V;
Preamp vendor……………………… : 0x0004;
Preamp revision……………………. : 0x0001;

;

HDD #1 Specs:;
SN: WXEX06103340;
Model: WD1200VE-00KWT0;
Date: 08 SEP 2010;
DCM: HOTJHN ;
Product of: Thailand;
PCB Sticker: 2061-701402-200 AC;
PCB Revision: 2060-701402-002 REV B;

;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : 601/1537;
1   : 1   : 715/1813;
2   : 2   : 621/1569;
3   : 3   : 6C5/1733;
;
;

;

HDD with  Serial Number: WXE706525818;
Model: WD1200VE-00KWT0;
Date: 20 AUG 2006;
DCM: HOTJHBN;
Product of: Thailand;
PCB Sticker: 2061-701402-100 AB;
PCB Revision: 2060-701402-001 REV A;

;

;

HDD with  Serial Number: WXE306797149;
Model: WD1200VE-00KWT0;
Date: 17 APR 2006;
DCM: HOTJBN;
Product of: Thailand;
PCB Sticker: 2061-701402-100 AA;
PCB Revision: 2060-701402-001 REV A;

;

;

HDD with Serial Number: WXE307587276;
Model: WD1200VE-00KWT0;
Date: 12 MAY 2007;
DCM: HOTJBBB;
Product of: Thailand;
PCB Sticker: 2061-701402-200 AC;
PCB Revision: 2060-701402-002 REV B;
;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : 681/1665;
1   : 1   : 6E1/1761;
2   : 2   : 661/1633;
3   : 3   : 721/1825;
ROM F/W version……………………. : 00020034;
Heads map…………………………. : 0,1,2,3;
Preamp vendor……………………. : 0x0004;
Preamp revision………………….. : 0x0001;

;

HDD #1 Specs:;
SN: WXE307G96573;
Model: WD1200VE-00KWT0;
Date: 08 SEP 2010;
DCM: HOTJBB ;
Product of: Thailand;
PCB Sticker: 2061-701402-200 AC;
PCB Revision: 2060-701402-002 REV B;

;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : 6B7/1719;
1   : 1   : 70F/1807;
2   : 2   : 5BB/1467;
3   : 3   : 713/1811;
;
;

;

HDD with  Serial Number: WXEX06334179;
Model: WD1200VE-00KWT0;
Date: 28 NOV 2006;
DCM: HOTJANB;
Product of: Thailand;
PCB Sticker: 2061-701402-200 AC;
PCB Revision: 2060-701402-002 REV B;

;

;

HDD with Serial Number: WXE806820921;
Model: WD1200VE-00KWT0;
Date: 07 SEP 2006;
DCM: HOTJABB;
Product of: Thailand;
PCB Sticker: 2061-701402-200 ABD2;
PCB Revision: 2060-701402-002 REV B;

;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 671/1649;
1 : 1 : 653/1619;
2 : 2 : 69F/1695;
3 : 3 : 699/1689;
ROM F/W version……………………. : 0002002P;
Heads map…………………………. : 0,1,2,3;
Preamp vendor……………………. : 0x0004;
Preamp revision………………….. : 0x0001;

;

HDD #1 Specs:;
Serial Number: WXE706829131;
Model: WD1200VE-00KWT0;
Date: 03 SEP 2010;
DCM: HOTJAB;
Product of: Thailand;
PCB Sticker: 2061-701402-100 AB;
PCB Revision: 2060-701402-001 REV A;

;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : 68F/1679;
1   : 1   : 647/1607;
2   : 2   : 65D/1629;
3   : 3   : 667/1639;

;

ROM F/W version……………………. : 0002002V;
Preamp vendor……………………… : 0x0004;
Preamp revision……………………. : 0x0001;

;
