WD10EARS-00Z5B1, DCM HARYNT2MAB, Western Digital 1TB SATA 3.5 Hard Drive

HDD with Serial Number: WMAVU2864098;
Model: WD10EARS-00Z5B1;
Date: 27 MAR 2010;
DCM: HARYNT2MAB;
Product of: Thailand;
PCB Sticker: 2061-701640-802 01PD4;
PCB Revision: 2060-701640-002 REV A;

;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 3 : C78/3192;
1 : 4 : CED/3309;
2 : 5 : C70/3184;
3 : 6 : CEE/3310;
4 : 7 : C6C/3180;

;

ROM F/W version……………………. : 008000CR;
Preamp vendor……………………… : 0x0000;
Preamp revision……………………. : 0x0002;

;

WD10EARS-00Z5B1, DCM HARNHT2MA, Western Digital 1TB SATA 3.5 Hard Drive

HDD with Serial Number: WCAVU0485862;
Model: WD10EARS-00Z5B1;
Date: 28 JUN 2010;
DCM: HARNHT2MA;
Product of: Malaysia;
PCB Sticker: 2061-701640-802 01PD2;
PCB Revision: 2060-701640-002 REV A;
;

;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 2 : C63/3171;
1 : 3 : CB1/3249;
2 : 4 : C86/3206;
3 : 5 : CA8/3240;
4 : 6 : BF8/3064;
5 : 7 : C38/3128;

;

ROM F/W version: 0015001R;
Heads map: 2,3,4,5,6,7;
Preamp vendor: 0x0000;
Preamp revision: 0x0002;

;

WD10EARS-00Z5B1, DCM HARNHT2CA, Western Digital 1TB SATA 3.5 Hard Drive

HDD with Serial Number: WMAVU3660309;
Model: WD10EARS-00Z5B1;
Date: 01 OCT 2010;
DCM: HARNHT2CA;
Product of: Malaysia;
PCB Sticker: 2061-771640-B03 AB;
PCB Revision: 2060-771640-003 REV P1;

;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 2   : C23/3107;
1   : 3   : CD5/3285;
2   : 4   : C52/3154;
3   : 5   : CD6/3286;
4   : 6   : C2F/3119;
5   : 7   : CD3/3283;
ROM F/W version……………………. : 0015001V;
Preamp vendor……………………… : 0x0000;
Preamp revision……………………. : 0x0002;
;
;
;
;

;

WD10EARS-00Y5B1, DCM HHRYNT2CB, Western Digital 1TB SATA 3.5 Hard Drive

HDD with Serial Number: WMAV50820205;
Model: WD10EARS-00Y5B1;
Date: 19 DEC 2009;
DCM: HHRYNT2CB;
Product of: Malaysia;
PCB Sticker: 2061-701640-802 01PD2;
PCB Revision: 2060-701640-002 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : CA6/3238;
1 : 1 : C08/3080;
2 : 2 : C54/3156;
3 : 3 : CDD/3293;
ROM F/W version……………………. : 008000CM;
Heads map…………………………. : 0,1,2,3;
Preamp vendor……………………… : 0x0000;
Preamp revision……………………. : 0x0002;

;

WD10EARS-00Y5B1, DCM HHRNNT2MH, Western Digital 1TB SATA 3.5 Hard Drive

HDD with Serial Number: WMAV50587561;
Model: WD10EARS-00Y5B1;
Date: 04 DEC 2009;
DCM: HHRNNT2MH;
Product of: Malaysia;
PCB Sticker: 2061-701640-802 01PD2;
PCB Revision: 2060-701640-002 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : CBD/3261;
1 : 1 : C7A/3194;
2 : 2 : C7D/3197;
3 : 3 : C7F/3199;

;

ROM F/W: 008000CA;
Heads map: 0,1,2,3;
Preamp vendor: 0x0000;
Preamp revision: 0x0002;

;

WD10EARS-00Y5B1, DCM HHNNHT2CH, Western Digital 1TB SATA 3.5 Hard Drive

HDD #1 Specs:;
Serial Number: WMAV50674009;
Model: WD10EARS-00Y5B1;
Date: 13 DEC 2009;
DCM: HHNNHT2CH;
Product of: Malaysia;
PCB Sticker: 2061-701640-802 01PD2;
PCB Revision: 2060-701640-002 REV A;

;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : CE2/3298;
1   : 1   : D05/3333;
2   : 2   : D2A/3370;
3   : 3   : D12/3346;
Preamp Vendor……………………… : 0000;
Preamp Rev………………………… : 0002;
ROM F/W version……………………. : 008000CM;
;
;
;
;
;

;

WD10EARS-00Y5B1, DCM HBRYHT2CA, Western Digital 1TB SATA 3.5 Hard Drive

HDD with Serial Number: WMAV50829285;
Model: WD10EARS-00Y5B1;
Date: 20 DEC 2009;
DCM: HBRYHT2CA;
Product of: Malaysia;
PCB Sticker: 2061-701640-802 01PD2;
PCB Revision: 2060-701640-002 REV A;

;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : CB0/3248;
1 : 1 : CC5/3269;
2 : 2 : D27/3367;
3 : 3 : CC4/3268;

;

ROM F/W version……………………. : 008000CM;
Preamp vendor……………………… : 0x0000;
Preamp revision……………………. : 0x0002;

;
