WD10EADS-22M2B0, DCM DGNNNT2MAB, Western Digital 1TB SATA 3.5 Hard Drive

HDD with Serial Number: WCAV57655912;
Model: WD10EADS-22M2B0;
Date: 20 JAN 2010;
DCM: DGNNNT2MAB;
Product of: Thailand;
PCB Sticker: 2061-701640-202 04PD4;
PCB Revision: 2060-701640-002 REV A;
;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : CB4/3252;
1   : 1   : D02/3330;
2   : 2   : C8D/3213;
3   : 3   : D1B/3355;
ROM F/W version……………………. : 0070003G;
Heads map…………………………. : 0,1,2,3;
Preamp vendor……………………. : 0x0000;
Preamp revision………………….. : 0x0002;

;

WD10EADS-22M2B0, DCM DBNNHT2MAB, Western Digital 1TB SATA 3.5 Hard Drive

HDD with Serial Number: WCAV57531947;
Model: WD10EADS-22M2B0;
Date: 20 JAN 2010;
DCM: DBNNHT2MAB;
Product of: Thailand;
PCB Sticker: 2061-701640-202 04PD4;
PCB Revision: 2060-701640-002 REV A;
;

——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : CDC/3292;
1   : 1   : CCE/3278;
2   : 2   : D06/3334;
3   : 3   : CEC/3308;
;
ROM F/W Version: 0070003G;
Heads map: 0,1,2,3;
Preamp vendor: 0x0000;
Preamp revision: 0x0002

;

WD10EADS-22M2B0, DCM DARCHV2MAB, Western Digital 1TB SATA 3.5 Hard Drive

HDD with Serial Number: WCAV52212979;
Model: WD10EADS-22M2B0;
Date: 20 SEP 2009;
DCM: DARCHV2MAB;
Product of: Thailand;
PCB Sticker: 2061-701640-700 02PD2;
PCB Revision: 2060-701640-001 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : B57/2903;
1 : 1 : B16/2838;
2 : 2 : B2B/2859;
3 : 3 : B45/2885;
ROM F/W version……………………. : 0090002A;
Heads map…………………………. : 0,1,2,3;
Preamp vendor……………………. : 0x0000;
Preamp revision………………….. : 0x0002;

;

WD10EADS-22M2B0, DCM DANNHT2MBB, Western Digital 1TB SATA 3.5 Hard Drive

HDD with Serial Number: WCAV56830085;
Model: WD10EADS-22M2B0;
Date: 05 JAN 2010;
DCM: DANNHT2MBB;
Product of: Thailand;
PCB Sticker: 2061-701640-502 02PD1;
PCB Revision: 2060-701640-002 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : CCD/3277;
1 : 1 : C96/3222;
2 : 2 : C9B/3227;
3 : 3 : C97/3223;
ROM F/W version……………………. : 0070003G;
Heads map…………………………. : 0,1,2,3;
Preamp vendor……………………. : 0x0000;
Preamp revision………………….. : 0x0002;

;

WD10EADS-11P8B2, DCM HANCNT2CB, Western Digital 1TB SATA 3.5 Hard Drive

HDD with Serial Number: WMAYN0019864;
Model: WD10EADS-11P8B2;
Date: 15 SEP 2010;
DCM: HANCNT2CB;
Product of: Malaysia;
PCB Sticker: 2061-771640-M03 AA;
PCB Revision: 2060-771640-003 REV P1;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 2 : CAC/3244;
1 : 3 : CEE/3310;
2 : 5 : CEB/3307;
3 : 7 : C9C/3228;
ROM F/W version……………………. : 0015001V;
Heads map…………………………. : 2,3,5,7;
Preamp vendor…………………….. : 0x0000;
Preamp revision…………………… : 0x0002;

;

WD10EADS-11P8B1, DCM HHRYNT2MH, Western Digital 1TB SATA 3.5 Hard Drive

HDD with Serial Number: WMAVU0983747;
Model: WD10EADS-11P8B1;
Date: 06 DEC 2009;
DCM: HHRYNT2MH;
Product of: Malaysia;
PCB Sticker: 2061-701640-402 01PD5;
PCB Revision: 2060-701640-002 REV A;

;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 3 : C48/3144;
1 : 4 : BDF/3039;
2 : 5 : C61/3169;
3 : 6 : C43/3139;
4 : 7 : C71/3185;
ROM F/W version……………………. : 008100BT;
Heads map…………………………. : 3,4,5,6,7;
Preamp vendor……………………. : 0x0000;
Preamp revision………………….. : 0x0002;

;

HDD with Serial Number: WMAVU2011778;
Model: WD10EADS-11P8B1;
Date: 31 JAN 2010;
DCM: HHRYNT2MH;
Product of: Malaysia;
PCB Sticker: 2061-701640-802 01PD2;
PCB Revision: 2060-701640-002 REV A;
Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 2   : CAD/3245;
1   : 3   : CBB/3259;
2   : 4   : C8E/3214;
3   : 6   : CD0/3280;
4   : 7   : C98/3224;
ROM F/W:008000CM;
Heads Map: 2,3,4,6,7;
Preamp vendor: 0x0000;
Preamp revision: 0x0002;

;

WD10EADS-11P8B1, DCM HHRYHT2MH, Western Digital 1TB SATA 3.5 Hard Drive

HDD with Serial Number: WMAVU1467054;
Model: WD10EADS-11P8B1;
Date: 01 JAN 2010;
DCM: HHRYHT2MH;
Product of: Malaysia;
PCB Sticker: 2061-701640-402 04PD2;
PCB Revision: 2060-701640-002 REV A;

;

;
——————————;
Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 2   : CDF/3295;
1   : 3   : CD7/3287;
2   : 4   : CFC/3324;
3   : 5   : D07/3335;
4   : 6   : CDF/3295;
;
ROM F/W: 008000CM;
Heads map: 2,3,4,5,6;
Preamp vendor: 0x0000;
Preamp revision: 0x0002;

;

HDD with Serial Number: WMAVU1004325;
Model: WD10EADS-11P8B1;
Date: 28 NOV 2009;
DCM: HHRYHT2MH;
Product of: Malaysia;
PCB Sticker: 2061-701640-402 04PD2;
PCB Revision: 2060-701640-002 REV A;
Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 2   : C26/3110;
1   : 4   : BD9/3033;
2   : 5   : C69/3177;
3   : 6   : C0C/3084;
4   : 7   : C36/3126;

;

;
ROM F/W: 008100BT;
Heads map: 2,4,5,6,7;
Preamp vendor: 0x0000;
Preamp revision: 0x0002;

;

WD10EADS-11P8B1, DCM HHNYHT2MB, Western Digital 1TB SATA 3.5 Hard Drive

HDD with Serial Number: WMAVU3261312;
Model: WD10EADS-11P8B1;
Date: 24 APR 2010;
DCM: HHNYHT2MB;
Product of: Malaysia;
PCB Sticker: 2061-701640-407 01PD3;
PCB Revision: 2060-701640-007 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 3 : C78/3192;
1 : 4 : D3C/3388;
2 : 5 : C97/3223;
3 : 6 : D0E/3342;
4 : 7 : C98/3224;
ROM F/W version……………………. : 008000E1;
Heads map…………………………. : 3,4,5,6,7;
Preamp vendor……………………… : 0x0000;
Preamp revision……………………. : 0x0002;

;
