WD1001FALS-00J7B0, DCM HBRNHT2CB, Western Digital 1TB SATA 3.5 Hard Drive

HDD with Serial Number: WMATV7700483;
Model: WD1001FALS-00J7B0;
Date: 26 MAY 2010;
DCM: HBRNHT2CB;
Product of: Malaysia;
PCB Sticker: 2061-701567-400 AF;
PCB Revision: 2060-701567-000 REV A;
;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 2   : A13/2579;
1   : 3   : A0A/2570;
2   : 4   : 9D6/2518;
3   : 5   : 9C0/2496;
4   : 6   : 9C0/2496;
5   : 7   : 99D/2461;
ROM F/W version……………………. : 0009009W;
Heads map…………………………. : 2,3,4,5,6,7;
Preamp vendor……………………. : 0x0000;
Preamp revision………………….. : 0x0003;

;
