HDD with Serial Number: WCANMK068712;
Model: WD1600JS-22NCB1;
Date: 26 JUN 2007;
DCM: HSBHNT2AHN;
Product of: Thailand;
PCB Sticker: 2061-701335-B00 AT;
PCB Revision: 2060-701335-005 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 4DA/1242;
1 : 1 : 4EE/1262;
2 : 4 : 4EA/1258;
3 : 5 : 4D4/1236;
ROM F/W version……………………. : 101TE;
Heads map…………………………. : 0,1,4,5;
Preamp vendor……………………. : 0x0000;
Preamp revision………………….. : 0x0004;

HDD with Serial Number: WCANMK087556;
Model: WD1600JS-22NCB1;
Date: 26 JUN 2007;
DCM: HSBHNT2AHN;
Product of: Thailand;
PCB Sticker: 2061-701335-B00 AT;
PCB Revision: 2060-701335-005 REV A;
;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : 49C/1180;
1   : 1   : 4B2/1202;
2   : 4   : 4B6/1206;
3   : 5   : 4C4/1220;
ROM F/W version……………………. : 109TE;
Heads map…………………………. : 0,1,4,5;
Preamp vendor……………………. : 0x0000;
Preamp revision…………………. : 0x0004;
;
;
;

;

HDD with Serial Number: WMANM3829462;
Model: WD1600JS-22NCB1;
Date: 14 JUN 2006;
DCM: HSBHCT2CH;
Product of: Malaysia;
PCB Sticker: 2061-701335-B00 AJ;
PCB Revision: 2060-701335-005 REV A;
;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : 4BE/1214;
1   : 1   : 4CE/1230;
2   : 4   : 4AC/1196;
3   : 5   : 4B8/1208;
ROM F/W version……………………. : 101AE;
Heads map…………………………. : 0,1,4,5;
Preamp vendor……………………. : 0x0000;
Preamp revision………………….. : 0x0004;
;
;
;

;

HDD with Serial Number: WCANMF840375;
Model: WD1600JS-22NCB1;
Date: 05 MAY 2007;
DCM: HSBAYT2CHN;
Product of: Thailand;
PCB Sticker: 2061-701335-B00 AR;
PCB Revision: 2060-701335-005 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 43A/1082;
1 : 1 : 42E/1070;
2 : 4 : 446/1094;
3 : 5 : 450/1104;
ROM F/W version……………………. : 105ME;
Heads map…………………………. : 0,1,4,5;
Preamp vendor……………………. : 0x0000;
Preamp revision………………….. : 0x0004;

;

HDD with Serial Number: WCANMK016540;
Model: WD1600JS-22NCB1;
Date: 26 JUN 2007;
DCM: DSBHNT2AHN;
Product of: Thailand;
PCB Sticker: 2061-701335-B00 AT;
PCB Revision: 2060-701335-005 REV A;
;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : 464/1124;
1   : 1   : 478/1144;
2   : 4   : 46C/1132;
3   : 5   : 488/1160;
ROM F/W version……………………. : 109TE;
Heads map…………………………. : 0,1,4,5;
Preamp vendor……………………. : 0x0000;
Preamp revision…………………. : 0x0004;
;
;
;

;

HDD with Serial Number: WCANM5647653;
Model: WD1600JS-22MHB0;
Date: 29 SEP 2006;
DCM: HSCHNTJAHN;
Product of: Thailand;
PCB Sticker: 2061-701335-B00 AJ;
PCB Revision: 2060-701335-005 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 4AC/1196;
1 : 1 : 488/1160;
2 : 4 : 4A4/1188;
3 : 5 : 48E/1166;
ROM F/W version……………………. : 02AEC;
Heads map…………………………. : 0,1,4,5;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0004;

;

HDD with Serial Number: WMANM1476566;
Model: WD1600JS-22MHB0;
Date: 06 OCT 2005;
DCM: HSCANTJCH;
Product of: Malaysia;
PCB Sticker: 2061-701335-800 AG;
PCB Revision: 2060-701335-003 REV B;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 462/1122;
1 : 1 : 45E/1118;
2 : 4 : 456/1110;
3 : 5 : 458/1112;
ROM F/W version……………………. : 029TC;
Heads map…………………………. : 0,1,4,5;
Preamp vendor…………………….. : 0x0001;
Preamp revision…………………… : 0x0004;

;

HDD with Serial Number: WCANM4355231;
Model: WD1600JS-22MHB0;
Date: 25 MAY 2006;
DCM: HSCACT2AA;
Product of: Thailand;
PCB Sticker: 2061-701335-B00 AJ;
PCB Revision: 2060-701335-005 REV A;

;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 484/1156;
1 : 1 : 48E/1166;
2 : 4 : 498/1176;
3 : 5 : 4AA/1194;

;

ROM F/W version……………………. : 02AEC;
Preamp vendor……………………… : 0x0000;
Preamp revision……………………. : 0x0004;

;

HDD with Serial Number: WCANM4661944;
Model: WD1600JS-22MHB0;
Date: 18 JUN 2006;
DCM: HSBHCTJAA;
Product of: Thailand;
PCB Sticker: 2061-701335-B00 AJ;
PCB Revision: 2060-701335-005 REV A;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 470/1136;
1 : 1 : 4A8/1192;
2 : 4 : 490/1168;
3 : 5 : 494/1172;
ROM F/W version……………………. : 02AEC;
Heads map…………………………. : 0,1,4,5;
Preamp vendor…………………….. : 0x0001;
Preamp revision…………………… : 0x0004;

;

HDD with Serial Number: WCANM7465772;
Model: WD1600JS-22MHB0;
Date: 23 OCT 2006;
DCM: HBCHNTJAHN;
Product of: Thailand;
PCB Sticker: 2061-701335-B00 AM;
PCB Revision: 2060-701335-005 REV A;

;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 462/1122;
1 : 1 : 4BE/1214;
2 : 4 : 446/1094;
3 : 5 : 4CE/1230;
;
ROM F/W version……………………. : 022EC;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0004;

;

HDD with Serial Number: WCANL1241498;
Model: WD1600JS-22MHB0;
Date: 29 JAN 2006;
DCM: DSCHCT2AH;
Product of: Thailand;
PCB Sticker: 2061-701335-B00 AF;
PCB Revision: 2060-701335-005 REV A;
;

;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 458/1112;
1 : 3 : 472/1138;
2 : 4 : 460/1120;
3 : 5 : 46A/1130;

;

ROM F/W version: 0276C;
Heads map: 0,3,4,5;
Preamp vendor: 0x0000;
Preamp revision: 0x0004;

;

;

;
