HDD with Serial Number: WXC908J93668;
Model: WD1600BEVT-88ZCT0;
Date: 11 NOV 2008;
DCM: FANT2BNB;
Product of: Thailand;
PCB Sticker: 2061-701499-500 AF;
PCB Revision: 2060-701499-000 REV A;
;
ROM F/W 0008001D;
Heads map 0,1;
Preamp Vendor: x002;
Preamp revision: x001;
;
Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 936/2358;
1 : 1 : 970/2416
;
Specifications;
SN: WX41AA075029;
Model: WD1600BEVT-80A23T0;
Date: 28 OCT 2010 ;
DCM: HHNTJHN ;
Product of: Malaysia;
PCB Sticker: 2061-771672-F04 AC;
PCB Revision: 2060-771672-004 REV A;
;
Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : A49/2633;
1 : 1 : A79/2681;
;
ROM F/W version……………………. : 00160001;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0000;
;
HDD with Serial Number: WXH1A3041518;
Model: WD1600BEVT-80A23T0;
Date: 12 APR 2010;
DCM: HHMTJHB;
Product of: Malaysia;
PCB Sticker: 2061-771672-F04 AA;
PCB Revision: 2060-771672-004 REV A;
;
Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : A76/2678;
1 : 1 : AF2/2802;
;
;
ROM F/W version: 0014001E;
Heads map: 0,1;
Preamp vendor: 0x0001;
Preamp revision: 0x0000;
;
HDD with Serial Number: WXE1A20K3795;
Model: WD1600BEVT-80A23T0;
Date: 15 MAR 2010;
DCM: HHBTJHBB;
Product of: Thailand;
PCB Sticker: 2061-771672-004 03PD2;
PCB Revision: 2060-771672-004 REV A;
;
Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : A4E/2638;
1 : 1 : AB6/2742;
ROM F/W version……………………. : 001400DD;
Heads map…………………………. : 0,1;
Preamp vendor………………….. : 0x0001;
Preamp revision………………… : 0x0000;
;
HDD with Serial Number: WX81A40L2136;
Model: WD1600BEVT-80A23T0;
Date: 26 APR 2010;
DCM: HHBTJABB;
Product of: Thailand;
PCB Sticker: 2061-771672-F04 AA;
PCB Revision: 2060-771672-004 REV A;
;
Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : A5C/2652;
1 : 1 : A54/2644;
ROM F/W version……………………. : 0014001E;
Heads map…………………………. : 0,1;
Preamp vendor…………………….. : 0x0001;
Preamp revision…………………… : 0x0000;
;
HDD with Serial Number: WXH1A3072613;
Model: WD1600BEVT-80A23T0;
Date: 12 APR 2010;
DCM: HEMTJHB;
Product of: Malaysia;
PCB Sticker: 2061-771672-F04 AA;
PCB Revision: 2060-771672-004 REV A;
;
Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : A88/2696;
1 : 1 : A8E/2702;
ROM F/W version……………………. : 0014001E;
Heads map…………………………. : 0,1;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0000;
;
HDD with Serial Number: WX91A40P2753;
Model: WD1600BEVT-80A23T0;
Date: 28 APR 2010;
DCM: HEMTJANB;
Product of: Thailand;
PCB Sticker: 2061-771672-F04 04P;
PCB Revision: 2060-771672-004 REV A;
;
Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : A3A/2618;
1 : 1 : A5E/2654
;
HDD with Serial Number: WX31A10J4407;
Model: WD1600BEVT-80A23T0;
Date: 21 FEB 2010;
DCM: HECTJHBB;
Product of: Thailand;
PCB Sticker: 2061-771672-004 03PD2;
PCB Revision: 2060-771672-004 REV A;
;
Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : A4E/2638;
1 : 1 : A90/2704;
ROM F/W version……………………. : 00140099;
Heads map…………………………. : 0,1;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0000;
;
HDD with Serial Number: WXC1A90C3874;
Model: WD1600BEVT-80A23T0;
Date: 09 OCT 2010;
DCM: HEBTJHB;
Product of: Malaysia;
PCB Sticker: 2061-771672-F04 AA;
PCB Revision: 2060-771672-004 REV A;
;
Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : AAE/2734;
1 : 1 : A8E/2702;
ROM F/W version……………………. : 0014003V;
Heads map…………………………. : 0,1;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0000;
;
HDD with Serial Number: WXG1EB0LNM91;
Model: WD1600BEVT-80A23T0;
Date: 17 JAN 2011;
DCM: EEBTJHKB;
Product of: Thailand;
PCB Revision: 2060-771672-004 REV A;
;
Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : A84/2692;
1 : 1 : AD3/2771;
ROM F/W version……………………. : 0016000D;
Heads map…………………………. : 0,1;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0000;
;
