HDD with Serial Number: WX41AA5DVUCU;
Model: WD15NMVW-11EDZS2;
Date: 06 NOV 2015;
DCM: HBKTJHKB;
Product of: Thailand;
PCB Sticker: 771961-J01 AC;
PCB Revision: 2060-771961-001 REV B;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 00/0;
1 : 1 : 00/0;
2 : 2 : 00/0;
3 : 3 : 00/0;
4 : 4 : 00/0;
5 : 5 : 00/0;
6 : 6 : 00/0;
7 : 7 : 00/0;
ROM F/W version……………………. : 0021003A;
Heads map…………………………. : 0,1,2,3,4,5,6,7;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0001;

;

HDD with Serial Number: WXE1A95RN5JE;
Model: WD15NMVW-11EDZS2;
Date: 06 NOV 2015;
DCM: HBKTJBKB;
Product of: Thailand;
PCB Sticker: 771961-J01 AC;
PCB Revision: 2060-771961-001 REV B;
;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : 00/0;
1   : 1   : 00/0;
2   : 2   : 00/0;
3   : 3   : 00/0;
4   : 4   : 00/0;
5   : 6   : 00/0;
6   : 7   : 00/0;
ROM F/W version……………………. : 0021003A;
Heads map…………………………. : 0,1,2,3,4,6,7;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0001;
;
;
;

;

HDD with Serial Number: WX41AA5DVAN1;
Model: WD15NMVW-11EDZS2;
Date: 06 NOV 2015;
DCM: HBKTJBBB;
Product of: Thailand;
PCB Sticker: 771961-J01 AC;
PCB Revision: 2060-771961-001 REV B;
;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : 00/0;
1   : 1   : 00/0;
2   : 2   : 00/0;
3   : 3   : 00/0;
4   : 4   : 00/0;
5   : 5   : 00/0;
6   : 6   : 00/0;
ROM F/W version……………………. : 0021003A;
Heads map…………………………. : 0,1,2,3,4,5,6;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0001;

;

HDD with Serial Number: WXH1E85EL1FT;
Model: WD15NMVW-11EDZS2;
Date: 07 NOV 2015;
DCM: EHKTJHBB;
Product of: Thailand;
PCB Sticker: 771961-J01 AC;
PCB Revision: 2060-771961-001 REV B;
;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : 00/0;
1   : 1   : 00/0;
2   : 2   : 00/0;
3   : 3   : 00/0;
4   : 4   : 00/0;
5   : 5   : 00/0;
ROM F/W version……………………. : 0021003A;
Heads map…………………………. : 0,1,2,3,4,5;
Preamp vendor……………………. : 0x0001;
Preamp revision………………….. : 0x0001;

;

HDD with Serial Number: WXD1E252D4HX;
Model: WD15NMVW-11EDZS2;
Date: 04 OCT 2015;
DCM: EBKTJBKB;
Product of: Thailand;
PCB Sticker: 771961-J01 AC;
PCB Revision: 2060-771961-001 REV B;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 00/0;
1 : 1 : 00/0;
2 : 3 : 00/0;
3 : 4 : 00/0;
4 : 5 : 00/0;
5 : 6 : 00/0;
6 : 7 : 00/0;
ROM F/W version……………………. : 0021003A;
Heads map…………………………. : 0,1,3,4,5,6,7;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0001;

;

HDD with Serial Number: WXE1E853PA50;
Model: WD15NMVW-11EDZS2;
Date: 07 NOV 2015;
DCM: EBKTJBBB;
Product of: Thailand;
PCB Sticker: 771961-J01 AC;
PCB Revision: 2060-771961-001 REV B;
;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : 00/0;
1   : 2   : 00/0;
2   : 3   : 00/0;
3   : 5   : 00/0;
4   : 6   : 00/0;
5   : 7   : 00/0;
ROM F/W version……………………. : 0021003A;
Heads map…………………………. : 0,2,3,5,6,7;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0001;
;
;
;
;

;

HDD with Serial Number: WX91E13EZD70;
Model: WD15NMVW-11AV3S4;
Date: 11 MAR 2016;
DCM: EHMTJHK;
Product of: Thailand;
PCB Sticker: 771961-F00 01P;
PCB Revision: 2060-771961-000 REV P1;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 00/0;
1 : 1 : 00/0;
2 : 2 : 00/0;
3 : 3 : 00/0;
4 : 4 : 00/0;
5 : 5 : 00/0;
6 : 6 : 00/0;
ROM F/W version……………………. : 0021003A;
Heads map…………………………. : 0,1,2,3,4,5,6;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0001;

;

HDD with Serial Number: WX91E13LWS80;
Model: WD15NMVW-11AV3S4;
Date: 12 JUN 2015;
DCM: EBMTJBK;
Product of: Thailand;
PCB Sticker: 771961-F00 01P;
PCB Revision: 2060-771961-000 REV P1;

;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 1 : 00/0;
1 : 2 : 00/0;
2 : 3 : 00/0;
3 : 4 : 00/0;
4 : 5 : 00/0;
5 : 6 : 00/0;
6 : 7 : 00/0;

;

ROM F/W version……………………. : 0021002C;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0001;

;

HDD with Serial Number: WX41A64HCLAC;
Model: WD15NMVW-11AV3S3;
Date: 02 MAY 2015;
DCM: HBMTJBK;
Product of: Thailand;
PCB Sticker: 771961-101 AF;
PCB Revision: 2060-771961-001 REV A;

;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 00/0;
1 : 2 : 00/0;
2 : 3 : 00/0;
3 : 4 : 00/0;
4 : 5 : 00/0;
5 : 6 : 00/0;
6 : 7 : 00/0;

;

ROM F/W version……………………. : 0021002C;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0001;

;

HDD with Serial Number: WX61A4401327;
Model: WD15NMVW-11AV3S2;
Date: 01 JUL 2014;
DCM: HHMTJHBB;
Product of: Thailand;
PCB Sticker: 771961-G01 AD;
PCB Revision: 2060-771961-001 REV A;
;

;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : 00/0;
1 : 1 : 00/0;
2 : 2 : 00/0;
3 : 3 : 00/0;
4 : 5 : 00/0;
5 : 6 : 00/0;
6 : 7 : 00/0;

;

ROM F/W version: 0021000R;
Heads map: 0,1,2,3,5,6,7;
Preamp vendor: 0x0001;
Preamp revision: 0x0001;

;
