WD10TMVV-11A27S2, DCM EHBV2BBB, Western Digital 1TB USB 2.5 Hard Drive

HDD #1 Specs:;
SN: WX70C89K2440;
Model: WD10TMVV-11A27S2;
Date: 20 JAN 2010;
DCM: EHBV2BBB ;
Product of: Thailand;
PCB Sticker: 2061-701675-401 AC;
PCB Revision: 2060-701675-001 REV P1;

;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : C5C/3164;
1   : 1   : C06/3078;
2   : 2   : BD0/3024;
3   : 3   : BF0/3056;
4   : 4   : C58/3160;
5   : 5   : B40/2880;
;
;

;

WD10TMVV-11A27S2, DCM EBBVJBNB, Western Digital 1TB USB 2.5 Hard Drive

HDD with Serial Number: WXB0C9990088;
Model: WD10TMVV-11A27S2;
Date: 06 DEC 2009;
DCM: EBBVJBNB;
Product of: Thailand;
PCB Sticker: 2061-701675-401 AB;
PCB Revision: 2060-701675-001 REV P1;

;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : C0D/3085;
1 : 1 : B06/2822;
2 : 2 : C05/3077;
3 : 3 : BEA/3050;
4 : 4 : C1C/3100;
5 : 5 : BA2/2978;

;

ROM F/W version……………………. : 008100D6;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0006;

;

WD10TMVV-11A27S2, DCM EBBVJBBB, Western Digital 1TB USB 2.5 Hard Drive

HDD with Serial Number: WX70C89C3866;
Model: WD10TMVV-11A27S2;
Date: 09 DEC 2009;
DCM: EBBVJBBB;
Product of: Thailand;
PCB Sticker: 2061-701675-401 AB;
PCB Revision: 2060-701675-001 REV P1;

;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : C7D/3197;
1 : 1 : B8C/2956;
2 : 2 : CBA/3258;
3 : 3 : B8E/2958;
4 : 4 : CCC/3276;
5 : 5 : BD7/3031;

;

ROM F/W version……………………. : 008100CC;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0006;

;

WD10TMVV-11A27S1, DCM HHBVJHBB, Western Digital 1TB USB 2.5 Hard Drive

HDD with Serial Number: WXF0A89Y5209;
Model: WD10TMVV-11A27S1;
Date: 03 NOV 2009;
DCM: HHBVJHBB;
Product of: Thailand;
PCB Sticker: 2061-701675-201 AB;
PCB Revision: 2060-701675-001 REV P1;
;

Micro Jogs;
——————————;
LH : PH : Micro Jog (Hex/Dec);
——————————;
0 : 0 : C80/3200;
1 : 1 : C2D/3117;
2 : 2 : C5D/3165;
3 : 3 : BA1/2977;
4 : 4 : CE8/3304;
5 : 5 : BF3/3059;
ROM F/W version……………………. : 001100CM;
Heads map…………………………. : 0,1,2,3,4,5;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0006;

;

WD10TMVV-11A27S0, DCM HHCVJHBB, Western Digital 1TB USB 2.5 Hard Drive

HDD with Serial Number: WXD0A7988527;
Model: WD10TMVV-11A27S0;
Date: 05 OCT 2009;
DCM: HHCVJHBB;
Product of: Thailand;
PCB Sticker: 2061-701675-201 01PD1;
PCB Revision: 2060-701675-001 REV P1;

;

Micro Jogs;
——————————;
LH  : PH  : Micro Jog (Hex/Dec);
——————————;
0   : 0   : C0F/3087;
1   : 1   : B4A/2890;
2   : 2   : C53/3155;
3   : 3   : B65/2917;
4   : 4   : C09/3081;
5   : 5   : BD1/3025;
ROM F/W version……………………. : 0011008M;
Preamp vendor……………………… : 0x0001;
Preamp revision……………………. : 0x0006;
;
;

;
